Agrona's Threadsafe Offheap Buffers

Learn more about the Agrona library, and how to access offheap memory for threadsafe operations.

Download Forrester’s “Vendor Landscape, Application Performance Management” report that examines the evolving role of APM as a key driver of customer satisfaction and business success, brought to you in partnership with BMC.

This blog post continues my ongoing series on the Agrona library by explaining how we offer easy access to offheap memory for threadsafe operations. I should probably caveat before we move on that this is a fairly advanced topic and I don't attempt to explain concepts such as memory barriers - merely outline the features of the API.

The Deficiencies of ByteBuffer

Java provides a byte buffer class to wrap both offheap and onheap memory. Bytebuffers are specifically used in the Java networking stack as a places for data to be read from or written into.

So what's the problem with bytebuffers? Well because they're targeted at their usecase they don't offer support for things like atomic operations. If you want to write an offheap data structure that's concurrently accessed from different processes then byte buffers don't address your needs. An example of the kind of library that you might want to write would be a message queue that one process will read from and another will write to.

Agrona's Buffers

Agrona provides several buffer classes and interfaces in order to overcome these deficiencies. These buffers are used by both the Aeron and SBE libraries.

  1. DirectBuffer - the top level interface that provides the ability to read values from the buffer.
  2. MutableDirectBuffer - extends DirectBuffer adding operations for writing to the buffer.
  3. AtomicBuffer - No it's not a nuclear powered MutableDirectBuffer! This interface adds atomic operations and compare-and-swap semantics.
  4. UnsafeBuffer - a default implementation. The name unsafe isn't supposed to imply that the class shouldn't be used, merely that its backing implementation uses sun.misc.Unsafe.

The decision to split up the buffers, rather than have a single class is motivated by wanting to restrict the access that different system components have to buffers. If a class only needs to read from a buffer, then it shouldn't be allowed to introduce bugs into the system by being allowed to mutate the buffer. Similarly components that are designed to be single threaded shouldn't be allowed to use the Atomic operations.

Wrapping Some Memory

In order to be able to do anything with a buffer, you need to tell it where the buffer is to begin with! This process is called wrapping the underlying memory. All the methods for wrapping memory are called wrap and its possible to wrap a byte[], ByteBuffer or DirectBuffer. You can also specify an offset and length with which to wrap the data structures. For example here is how you wrap a byte[].

        final int offset = 0;
        final int length = 5;
        buffer.wrap(new byte[length], offset, length);

There is one more option for wrapping - which is an address to a memory location. In this case the method takes the base address of the memory and its length. This is to support things like memory allocated via sun.misc.Unsafe or for example a malloc call. Here's an example using Unsafe.

        final int length = 10;
        final long address = unsafe.allocateMemory(length);
        buffer.wrap(address, length);

Wrapping the memory also sets up the capacity of the buffer, which can be accessed via the capacity() method.


So now you've got your buffer of off-heap memory you can read from and write to it. The convention is that each getter starts with the word get and is suffixed with the type of the value that you're trying to get out. You need to provide an address to say where in the buffer to read from. There's also an optional byte order parameter. If the byte order isn't specified then the machine's native order will be used. Here's an example of how to increment a long at the beginning of the buffer:

        final int address = 0;
        long value = buffer.getLong(address, ByteOrder.BIG_ENDIAN);
        buffer.putLong(address, value, ByteOrder.BIG_ENDIAN);

As well as primitive types its possible to get and put bytes from the buffers. In this case the buffer to be read into or from is passed as a parameter. Again a byte[], ByteBuffer or DirectBuffer is supported. For example, here's how you would read data into a byte[].

        final int offsetInBuffer = 0;
        final int offsetInResult = 0;
        final int length = 5;
        final byte[] result = new byte[length];
        buffer.getBytes(offsetInBuffer, result, offsetInResult, length, result);

Concurrent Operations

int and long values can also be read or written with memory ordering semantics. Methods suffixed with Ordered guarantee that they will eventually be set to the value in question, and that value will eventually be visible from another thread doing a volatile read on the value. In other words putLongOrdered automatically performs a store-store memory barrier. get*Volatile and put*Volatile follow the same ordering semantics as reads and writes to variables declared with the volatile keyword would in Java.

More sophisticated memory operations are also possible via the AtomicBuffer. For example there is a compareAndSetLong which will atomically set an updated value at a given index, given the existing value there is an expected value. The getAndAddLong method is a completely atomic way of adding at a given index.

Nothing in life is free, there is a caveat to all this. These guarantees are non-existent if your index isn't word-aligned. Remember, its also possible to tear writes to values over word boundaries on some weak memory architectures, such as ARM and Sparc, see stack overflow for more details on this kind of thing.

Bounds Checking

Bounds checking is one of those thorny issues and topics of ongoing debate. Avoiding bounds checks can result in faster code, but introduces the potential to cause a segfault and bring down the JVM. Agrona's buffers give you the choice to disable bounds checking through the commandline property agrona.disable.bounds.checks, but bounds check by default. This means that their use is safe, but if application profiling of tested code determines that bounds checking is a bottleneck then it can be removed.


Agrona's buffers allow us to easily use offheap memory without the restrictions that Java's existing bytebuffers impose upon us. We're continuing to expand the library which can be downloaded from maven central.

Thanks to Mike Barker, Alex Wilson, Benji Weber, Euan Macgregor, Matthew Cranman for their help reviewing this blog post.
