Are You Using Jenkins the Right Way?
Are You Using Jenkins the Right Way?
Jenkins has a wide variety of uses cases it can fulfill in the Continuous Integration paradigm. Read on for some ideas and examples of these use cases!
Join the DZone community and get the full member experience.Join For Free
Planning to extract out a few microservices from your monolith? Read this free guide to learn the best practice before you get started.
Jenkins is a widely used tool, but not everyone uses it in the same way. While some enjoy its test automation abilities, others take advantage of its full automating capabilities, from the code commit through the build, test and up to deployment. These advanced users are fulfilling the complete continuous integration (CI) vision, which thoroughly facilitates and improves development processes.
How Do You Use Jenkins?
1. Jenkins as a Load Test Automator
Many people use Jenkins as a means to automate and simplify test launching. Instead of manually starting a bunch of scripts, prepare an environment and create an automation in Jenkins. These users don’t think of what they’re doing as part of the CI process, but rather as an easier way of running tests.
While this approach speeds the overall work of the company, we recommend taking advantage of all of Jenkins abilities, to make the whole development process more efficient, improve the product’s quality and shorten the time to release.
2. Jenkins as Part of the CI Process
Developers who use Jenkins to trigger jobs by commits, are taking advantage of all of Jenkins capabilities. There are two ways to do this:
A. The “Spotless House” Approach
In this approach, performance testing is always included in the full testing process. While this might delay build time, as load tests might take a while to be completed compared to the other tests, the result is assured to be of very high quality. Think of this as cleaning your house from top to bottom every day, including sweeping, washing, doing your dishes and scrubbing windows.
B. The “Clean Enough” Approach
In this approach, load testing is performed as part of the downstream job, but without blocking the main CI job. The full, longer, test can be run once in a decided upon time (let’s say once a week) instead of once a day. This enables you to use Jenkins without pausing your work for too long and waiting 1.5 - 2 hours each time. Think of it as doing the dishes and sweeping the floor every day, and cleaning thoroughly once a week.
3. Jenkins With Taurus — Easier Test Config Maintenance
Test config is an important part of load testing, but it can be hard to maintain. Locally, you will have to manually run pre/post test actions. On Jenkins, there is no version control on the “execute shell” section, resulting in lost changes, complicated and clumsy files management or the need to duplicate the work you have already done on your local computer.
This is where Taurus comes in. Taurus facilitates CI style usage, because you can manage all pre/post test actions in one configuration file as part of version control repository. As a result, all changes are saved in one place, and every change in the test config file can automatically trigger Jenkins to run the test with the changes you made. This allows you to work gradually, improve gradually and apply all changes in one place.
Let’s look at this Taurus test config file:
--- services: - module: shellexec prepare: - ssh firstname.lastname@example.org -i keys/a.pem - bash startAgent.sh - wget http://www.openss7.org/repos/csv_files/hosts.csv - sort -R hosts.csv > random_hosts.csv shutdown: - echo "shutdown time is $(date)" >> tmp/bla.txt post-process: - echo "this is a post process" >> tmp/bla.txt - mail -a /taurus/bzt.log -s “my_taurus_log_file“ email@example.com < tmp/bla.txt - module: monitoring server-agent: - address: 126.96.36.199 metrics: - cpu - disks - memory - module: passfail criteria: - class: bzt.modules.monitoring.MonitoringCriteria My Message: CPU on local server>20 for 7s, stop as failed subject: 188.8.131.52/cpu
The shellexec module has commands for three phases:
Preparation — For example, log into a remote machine and run a certain process on it, download a data file and manipulate it to use on your test
Shutdown — A Command that saves the shutdown time to a file
Post-process — For example, email the log file of the test after it finished running
The monitoring module collects health stats from the computer running Taurus. In this case - CPU, disks and memory.
The pass/fail module determines the success of a load test based on runtime criteria. In this case, if the CPU is higher than 20% for 7 seconds, the test stops. Criteria can be changed easily.
Don’t give up on continuous integration and automating your work. For more information on Jenkins, see our free Webinar "Automated Performance Tests in Jenkins CI Environments".
For more information on Taurus, see the Taurus Knowledge Base.
