Are You Using Jenkins the Right Way?

Jenkins has a wide variety of uses cases it can fulfill in the Continuous Integration paradigm. Read on for some ideas and examples of these use cases!

· DevOps Zone

The DevOps zone is brought to you in partnership with Sonatype Nexus. The Nexus suite helps scale your DevOps delivery with continuous component intelligence integrated into development tools, including Eclipse, IntelliJ, Jenkins, Bamboo, SonarQube and more. Schedule a demo today

Jenkins is a widely used tool, but not everyone uses it in the same way. While some enjoy its test automation abilities, others take advantage of its full automating capabilities, from the code commit through the build, test and up to  deployment. These advanced users are fulfilling the complete continuous integration (CI) vision, which thoroughly facilitates and improves development processes.

How Do You Use Jenkins?

1. Jenkins as a Load Test Automator

Many people use Jenkins as a means to automate and simplify test launching. Instead of manually starting a bunch of scripts, prepare an environment and create an automation in Jenkins. These users don’t think of what they’re doing as part of the CI process, but rather as an easier way of running tests.

While this approach speeds the overall work of the company, we recommend taking advantage of all of Jenkins abilities, to make the whole development process more efficient,  improve the product’s quality and shorten the time to release.

2. Jenkins as Part of the CI Process

Developers who use Jenkins to trigger jobs by commits, are taking advantage of all of Jenkins capabilities. There are two ways to do this:

A. The “Spotless House” Approach

In this approach, performance testing is always included in the full testing process. While this might delay build time, as load tests might take a while to be completed compared to the other tests, the result is assured to be of very high quality. Think of this as cleaning your house from top to bottom every day, including sweeping, washing, doing your dishes and scrubbing windows.

commit, build, test, deploy on jenkins

B. The “Clean Enough” Approach

In this approach, load testing is performed as part of the downstream job, but without blocking the main CI job. The full, longer, test can be run once in a decided upon time (let’s say once a week) instead of once a day. This enables you to use Jenkins without pausing your work for too long and waiting 1.5 - 2 hours each time. Think of it as doing the dishes and sweeping the floor every day, and cleaning thoroughly once a week.

commit, build, sometimes load test, unit test, deploy on jenkins

3. Jenkins With Taurus — Easier Test Config Maintenance

Test config is an important part of load testing, but it can be hard to maintain. Locally, you will have to manually run pre/post test actions. On Jenkins, there is no version control on the “execute shell” section, resulting in lost changes, complicated and clumsy files management or the need to duplicate the work you have already done on your local computer.

This is where Taurus comes in. Taurus facilitates CI style usage, because you can manage all pre/post test actions in one configuration file as part of version control repository. As a result, all changes are saved in one place, and every change in the test config file can automatically trigger Jenkins to run the test with the changes you made. This allows you to work gradually, improve gradually and apply all changes in one place.

Let’s look at this Taurus test config file:



- module: shellexec


  - ssh ubuntu@ -i keys/a.pem

  - bash startAgent.sh

  - wget http://www.openss7.org/repos/csv_files/hosts.csv

  - sort -R hosts.csv > random_hosts.csv


  - echo "shutdown time is $(date)" >> tmp/bla.txt


  - echo "this is a post process" >> tmp/bla.txt

  - mail -a /taurus/bzt.log -s “my_taurus_log_file“ user@example.com < tmp/bla.txt

- module: monitoring


  - address:


    - cpu

    - disks

    - memory

- module: passfail


  - class: bzt.modules.monitoring.MonitoringCriteria

    My Message: CPU on local server>20 for 7s, stop as failed


This test config has three modules: shellexec, monitoring and passfail.

The shellexec module has commands for three phases:

  • Preparation — For example, log into a remote machine and run a certain process on it, download a data file and manipulate it to use on your test

  • Shutdown — A Command that saves the shutdown time to a file

  • Post-process — For example, email the log file of the test after it finished running

The monitoring module collects health stats from the computer running Taurus. In this case - CPU, disks and memory.

The pass/fail module determines the success of a load test based on runtime criteria. In this case, if the CPU is higher than 20% for 7 seconds, the test stops. Criteria can be changed easily.

Don’t give up on continuous integration and automating your work. For more information on Jenkins, see our free Webinar "Automated Performance Tests in Jenkins CI Environments".

For more information on Taurus, see the Taurus Knowledge Base.

The DevOps zone is brought to you in partnership with Sonatype Nexus. Use the Nexus Suite to automate your software supply chain and ensure you're using the highest quality open source components at every step of the development lifecycle. Get Nexus today

jenkins,ci,config,continuous integratinon,use cases

Published at DZone with permission of Guy Salton, DZone MVB. See the original article here.

Opinions expressed by DZone contributors are their own.
