AutoTable: Your Butler-Like Sharding Config Tool

Background

Sharding is the core feature of Apache ShardingSphere. We guess, your old sharding workflow (without data migration) probably looks like the one below:

How AutoTable Helps

Apache ShardingSphere Version 5.0.0 launched AutoTable, a new method that makes sharding configuration easier for you.

Literally, AutoTable means automated table sharding. When you use AutoTable, you only need to specify the sharding count and the data source. Thanks to AutoTable, you no longer need to worry about actual table distribution. The correct configuration format is shown as follows:

autoTables:
t_order:
# Specify your datasources
actualDataSources: ds_${0..7}
shardingStrategy:
standard:
shardingColumn: order_id
shardingAlgorithmName: mod
shardingAlgorithms:
mod:
type: MOD
props:
# Specify your sharding-count
sharding-count: 32

Due to AutoTable configuration, ShardingSphere is able to recognize that the logic tablet_order has 8 data sources and needs 32 sharding tables, and then it automatically calculates the distribution result: 8 sharding databases* 4 sharding tables. The result is exactly the same.

AutoTable & DistSQL

Now, you know more about AutoTable. However, when you combine AutoTable with DistSQL, the results are even more impressive as it can greatly simplify sharding configuration for you. Unlike the old method, the DistSQL configuration rule works immediately so you no longer need to restart it anymore. Besides, one rule change will never have impact on others.

DistSQL supports three expressions used to manage sharding table rules: create, alter and drop.

# Create a sharding table rule
CREATE SHARDING TABLE RULE t_order (
RESOURCES(resource_0,resource_1),
SHARDING_COLUMN=order_id,TYPE(NAME=hash_mod,PROPERTIES("sharding-count"=4))
);
# Ater a sharding table rule
ALTER SHARDING TABLE RULE t_order (
RESOURCES(resource_0,resource_1),
SHARDING_COLUMN=order_id,TYPE(NAME=hash_mod,PROPERTIES("sharding-count"=10))
);
# Drop a sharding table rule
DROP SHARDING TABLE RULE t_order;

Note: Rule alteration may have impact on old data. In order to fix the problem, we provide ShardingSphere Scaling that allows you to migrate data and makes it more convenient for you to manage distributed data. We are happy to share more about ShardingSphere Scaling in the near future.

FAQ

Can I use AutoTable in ShardingSphere-JDBC?

Yes, you can.

Both ShardingSphere-JDBC and ShardingSphere-Proxy support AutoTable. What’s more, you can also use DistSQL in Proxy for dynamic configuration in order to meet your various access demands.

Which Sharding Algorithms Does AutoTable Support?

AutoTable supports all automatic sharding algorithms:

• MOD: Modulo Sharding Algorithm
• HASH_MOD: Hash Modulo Sharding Algorithm
• VOLUME_RANGE: Volume Based Range Sharding Algorithm
• BOUNDARY_RANGE: Boundary Based Range Sharding Algorithm
• AUTO_INTERVAL: Auto Interval Sharding Algorithm

For more information, please read the Apache ShardingSphere document “Automatic Sharding Algorithm”.

In addition to using built-in algorithms, you can also develop an SPI extension to customize your own sharding algorithm when necessary.

I Have Already Used YAML. Can I Use AutoTable Now?

We don’t recommend you to do that.

If you’re sure that such a switch can make the table distribution result conform to your expectation, you may have a try. Otherwise, please don’t do that.

However, if you want to create a new table, you are welcome to use AutoTable.

What‘s the Best Scenario for AutoTable?

AutoTable aims to be your butler for sharding configuration. All you need to do is to tell it how many shards you need, and then it saves you the trouble of remembering the actual table location and table count.

To use AutoTable, you better configure rules first and then use CREATE TABLE to create tables. Old habits die hard but please change your old habit: create tables first and then configure rules. Now ShardingSphere is more like an access point of your distributed database, instead of middleware.

My Datasource Names Are Non-Contiguous or I Have Too Many Datasource Names. Can I Use AutoTable?

Yes, you can. When you specify your data sources, their names are not required to be continuous. To solve the problem, you can use enumeration-expression and inline-expression at the same time:

CREATE SHARDING TABLE RULE t_order (
RESOURCES('resource_${0..9}',resource_12,resource_15,"resource_$->{17..19}"),
...
);

Can I Use AutoTable and the Old Method Together?

Yes, you can.

For more information, please read: https://github.com/apache/shardingsphere/blob/master/shardingsphere-jdbc/shardingsphere-jdbc-core/src/test/resources/config/config-sharding.yaml
