Big Database (Part 1): Scalability

DZone's Guide to

Big Database (Part 1): Scalability

In this article, I summarize the traditional approaches available to provide database scalability, comparing the benefits and drawbacks of each. I

· Database Zone ·
Free Resource

Built by the engineers behind Netezza and the technology behind Amazon Redshift, AnzoGraph is a native, Massively Parallel Processing (MPP) distributed Graph OLAP (GOLAP) database that executes queries more than 100x faster than other vendors.

Despite multiple challenger technologies (i.e. object-oriented databases), the relational databases from Oracle, IBM, and Microsoft have prevailed supreme for over 30 years.

This dominance has, however, been increasingly challenged by a new wave of technology solutions that started with database appliances from Teradata and Nettezza driven by big data requirements. This was followed by open-source NoSQL databases including HBase and Cassandra. Development continued with NewSQL databases including VoltDB and MemSQL, and finally, although not a database, Hadoop HDFS is providing a significant competition as a potential data store.

In this article, I will summarize the traditional approaches available to provide database scalability, comparing the benefits and drawbacks of each. In Part 2, I’ll describe the different database architectures. In the final article, I’ll describe how the new challenger solutions fit into the overall picture.

First, it’s sensible to define some terms.

What Is Scalability?

Most systems don’t run at 100% capacity and must build in headroom to allow for a temporary spike in traffic without a significant drop in performance. However, this does not make them scalable; there’s just spare capacity. Scalability refers to the options available to cope with a long term increase in traffic when there’s no headroom available. The typical options are described as vertical (scale up) or horizontal (scale out).

Scalability vs. Performance

Image title

Although closely correlated, it’s important to treat these separately, as they often require a different approach. System performance refers to the throughput (transactions per minute) or average response time. In my experience, performance improvements are gained using efficient database design, and scalability, during the selection of an appropriate hardware architecture.

In short, you need to build scalability into the hardware architecture and database selection, and can (for the most part) maximize performance later — during the database design and deployment phase. Do this in the wrong sequence, and you’ll find your scalability options to be severely limited.

What Is Elasticity?

Image title

Typically associated with cloud-based solutions (either on-premises or hosted externally), this refers to the ability of the system to rapidly grow or shrink as the processing demands change – often dynamically. This implies manual or automatic hardware allocation on a cluster to best match the resources available to the demands of a given task. Elasticity (and associated cost control) is one of the greatest benefits of cloud-based solutions and can be used to control costs and make more efficient use of machine resources.

Scalability Options

Assuming you need to scale your system, there are two options: scaling up or scaling out.

Image title

The diagram above illustrates a situation where we add disk, memory, or processing capacity to the system, and eventually migrate to a larger hardware platform. Typically, however, neither the benefits nor the costs are linear, and faster disks, processors, and network add significant cost. In addition, as most systems are constrained by a performance bottleneck, increasing capacity in one area often shifts the bottleneck to another and doubling the size of the machine seldom doubles the capacity.

Image title

The scale-out option implies a distributed system whereby additional machines are added to a cluster to provide additional capacity. It's often more likely to yield a linear increase in scalability, although not necessarily increased performance.

The arguments for/against scaling up include:

  • Ease of extension: As a method of providing additional headroom, adding more memory or faster components can extend the life of existing hardware without the need to rearchitect or replace the entire system.
  • Relative hardware cost: As mentioned above, a database platform is a complex system, and although improving one component may help alleviate a performance problem, it’s unlikely that 100% faster processors will provide a doubling in capacity, as it’s likely to move the bottleneck to a different point. This can make the TCO costs relatively expensive in the long run.
  • Need for downtime: Hardware upgrades, especially on single node machines, require downtime to complete, which is often not desirable or even possible in some cases.
  • Cost and effort to re-platform: A highly integrated data warehouse platform with multiple undocumented sources and downstream feeds could take months of planning, migrating, and testing to migrate to a larger machine. Leaving aside the cost of new hardware, the migration can add a significant burden on an already over-stretched IT department — even more so if it’s required again five years down the line.

The arguments for/against scaling out include:

  • Ease of extension: A scale-out solution implies a distributed system, and in many cases, this can be easily extended with additional nodes to add capacity — often with zero downtime and automatic node rebalancing. That’s certainly the case with many NoSQL databases including HBase and Cassandra.
  • Limits of scale: Despite vendor claims to the contrary, both shared disk and shared nothing architectures do (in most cases) have scalability limits. Depending on the solution deployed, adding additional nodes may involve repartitioning the data, which is not a small task.
  • Need to re-architect: Depending upon the existing solution, it may be necessary to rework or re-architect the entire database. This can vary from a relatively straightforward migration from a single node database to a shared disk solution, or a complete migration to an entirely new database and hardware architecture, for example from single node Oracle to an MPP system from Vertica or Greenplum.

Conclusion

As in most aspects of IT, it’s important to start with a clear understanding of the problem and separate the challenges of performance from the bigger, architectural requirement of scalability. Many would love to try out new technologies including NoSQL databases, but (as you’ll see in the next article), these do come with significant drawbacks, although admittedly with truly unlimited scalability.

If expected database growth is more organic, it may be more sensible to consider scaling up the existing hardware platform, although if you’re already running an MPP cluster or you’ve hit the hardware limits, then a scale-out architecture may be more appropriate. Again, you need to be aware of the potentially significant drawbacks.

The most obvious (but important) takeaway, however, is that you can design and tune for performance, but once selected and installed, your options to scale have already been decided. Architect for scalability, and then design and tune for maximum performance.

Thank You

Thanks for reading this far.  If you found this helpful, you can view more articles on Big Data, Cloud Computing, Database Architecture and the future of data warehousing on my web site www.Analytics.Today.
