Building a Dataset With Blood Donation Stock Data

Overview

I was looking to analyze the blood donation data from Brazilian blood centers. To my surprise, this data is not standardized, nor is there an API to show this information.

So the way I found it was to create a web-scraping to read this information. For this study, I used the Pró-Sangue Foundation of the state of Sao Paulo, Brazil.

The solution was to create a web-scraping to extract this information from the site.

You may also like:  Don’t Panic! PyTorch Data Loaders and Datasets

I have more audacious interest for this study. So an architecture was created using the following technologies:

• Python — (Web-Scraping)
• Nifi — (Pipeline)
• Elasticsearch — (Index)
• Kibana — (Visualization/threshold)

Website of the Pró-sangue foundation of the state of São Paulo:

1. Project Architecture

Architecture used in the project:

2. Dataset

The information I am interested in is the current position of the blood supply with all blood types.

It is possible to do a web-scraping with NiFi, but I found it complex. And thinking of mapping other sites, I decided to use Python with the BeautifulSoup library and Flask for the micro-service.

3. The Web-Scraping Code

The code is available in: https://github.com/edersoncorbari/blood-donation

I extract the information blood-donation/web-scraping/scraping.py.

       b1 = {
            "blood": "O+",
            "status": self.numStatus(
                self.stock.find(
                    id="cphConteudo_Estoque1_Repeater1_lblO_0")['class'][0]),
            "update": self.update,
            "timestamp": self.timestamp}
      ...

      bloods = (b1, b2, b3, b4, b5, b6, b7, b8)
      return json.loads(json.dumps(bloods))

An important factor for Kibana is the standardization of data types. He works best with numbers and dates. So type conversions are done and could be handled by NiFi too, but it gets more complex.

The endpoint (http://127.0.0.1:5000/blood-current-position) will return the information:

[
    {
        "blood": "O+",
        "status": 2,
        "timestamp": "2019-10-07T17:48:24.899Z",
        "update": "2019-10-07T15:15:00.000Z"
    },
    {
        "blood": "A+",
        "status": 2,
        "timestamp": "2019-10-07T17:48:24.899Z",
        "update": "2019-10-07T15:15:00.000Z"
    },
    {
        "blood": "AB+",
        "status": 2,
        "timestamp": "2019-10-07T17:48:24.899Z",
        "update": "2019-10-07T15:15:00.000Z"
    },
    {
        "blood": "B+",
        "status": 2,
        "timestamp": "2019-10-07T17:48:24.899Z",
        "update": "2019-10-07T15:15:00.000Z"
    },
    {
        "blood": "O-",
        "status": 0,
        "timestamp": "2019-10-07T17:48:24.899Z",
        "update": "2019-10-07T15:15:00.000Z"
    },
    {
        "blood": "A-",
        "status": 2,
        "timestamp": "2019-10-07T17:48:24.899Z",
        "update": "2019-10-07T15:15:00.000Z"
    },
    {
        "blood": "AB-",
        "status": 2,
        "timestamp": "2019-10-07T17:48:24.899Z",
        "update": "2019-10-07T15:15:00.000Z"
    },
    {
        "blood": "B-",
        "status": 0,
        "timestamp": "2019-10-07T17:48:24.899Z",
        "update": "2019-10-07T15:15:00.000Z"
    }
]

I now have standardized data.

4. Apache NiFi

With NiFi, we were able to create flow-based programming and then scale up later, creating other clusters.

It makes it much easier to take data from one type of source and send it to another. In this case, read an API-Rest and put the data into Elasticsearch.

5. Kibana

Now with the data in Elasticsearch, we can see in Kibana:

From now on, you can create your visualizations for use in the dashboard or canvas. With a paid version, it is also possible to create thresholds using e-mail, slack, etc.

6. More Information

To run the code and test NiFi with Elastic and Kibana, please look at the documentation in the repository below:

• https://github.com/edersoncorbari/blood-donation

In another tutorial, I will show the graphics.

Thanks!
