Building a RESTful API Using LoopBack

Overview

LoopBack, an easy to learn and understand open-source Node.js framework, allows you to create end-to-end REST APIs with less code compared to Express and other frameworks. It allows you to create your basic routes on adding a model into the application.

Data can be accessed from multiple databases such as MySQL, MongoDB, Oracle, MS SQL, PostgreSQL, and so on. In this blog post, let us discuss building a RESTful API using LoopBack and accessing data from MongoDB.

Installing LoopBack

LoopBack can be installed using either API Connect or StrongLoop. To install using StrongLoop, use the below command:

$ sudo npm install -g strongloop

Creating a Sample Project

In this section, let us discuss creating a sample project.

Creating an Application

To create an application, use the below command:

$ slc loopback

Accept the default selection api-server to create the application.

Connecting to the Database

To connect to the database such as MySQL/MongoDB, use the below command:

$ npm install loopback-connector-mongodb–save

Creating a Model

The models are connected to databases via data sources providing create, retrieve, update, and delete (CRUD) functions.

Other backend services such as REST APIs, SOAP web services, and storage services, and so on are generalized as data sources.

To create a model, use the below command:

$ slc loopback:model

Running Application

To run the application, use the below command:

$ node server.js
 $ slc run

Creating a Static HTML Page

To create a static HTML page, perform the following:

• Comment the default root configuration from the following file:

server/boot/root.js
--- disable the code ---
 module.exports = function(server) { // Install a `/` route that returns server status
 var router = server.loopback.Router();
 router.get('/', server.loopback.status());
 server.use(router);
 };

• Add the root configuration from the below file path:

server/middleware.json
...
 "files": {
 "loopback#static": {
 "params": "$!../client"
 }
 },
 ...

The above lines define static middleware, making the application serve files in the client directory as static content. The $! characters indicate that the path is relative to the location of middleware.json.

The page looks similar to the one below:

MongoDB Collection

A collection called studentmodel is created in MongoDB as shown in the below diagram:

Creating a Custom API

To create a custom API to access data from MongoDB [Extend API], perform the following:

• Use the below root configuration file:

common/models/studentmodel.js

• Select data from MongoDB based on the API request using the below command:

Studentmodel.getName = function(shopId, cb) {
 Studentmodel.findById( shopId, function (err, instance) {
 var response = "Name of coffee shop is " + instance.name;
 cb(null, response);
 console.log(response);
 });
 }
Studentmodel.remoteMethod (
 'getName',
 {
 http: {path: '/getname', verb: 'get'},
 accepts: {arg: 'id', type: 'string', http: { source: 'query' } },
 returns: {arg: 'name', type: 'string'}
 }
 );

The screen looks similar to the one shown below:

• Insert data into MongoDB based on the API.

api : /api/studentmodels/addstudent?name=cc&category=fresh
 /** To insert data into mongodb from api **/
Studentmodel.addStudent = function(stuname,stucateg, cb) {
 var newstu = {"name": stuname, "category": stucateg};
 Studentmodel.create( newstu, function (err) {
 var response = "Successfully inserted";
 cb(null, response);
 console.log(response);
 });
 }
Studentmodel.remoteMethod (
 'addStudent',
 {
 http: {path: '/addstudent', verb: 'get'},
 accepts: [{arg: 'name', type: 'string', http: { source: 'query' } },{arg: 'category', type: 'string',
http: { source: 'query' } }],
 returns: {arg: 'response', type: 'string'}
 }
 );

The screen looks similar to the one shown below:

The database table is as follows:

Before Inserting Data Into Database

After Inserting Data Into Database

• Destroy model instance with the specified ID.

api: /api/studentmodels/removestudent?id=591edf53a593f55ec705595c
/** Destroy model instance with the specified ID **/
 Studentmodel.removeStudent = function(stuid, cb) {
 Studentmodel.destroyById( stuid, function (err) {
 var response = "Successfully removed";
 cb(null, response);
 console.log(response);
 });
 }
Studentmodel.remoteMethod (
 'removeStudent',
 {
 http: {path: '/removestudent', verb: 'get'},
 accepts: {arg: 'id', type: 'string', http: { source: 'query' } },
 returns: {arg: 'response', type: 'string'}
 }
 );

The screen looks similar to the one shown below:

The database table is as follows:

Before Deleting Data From Database

After Deleting Data From Database

• Update the model instance with the specified ID. Replace attributes for the model instance whose ID is the first input argument, persist it into the data source, and perform validation before replacing.

api: /api/studentmodels/updateStudent?id=591eddaba593f55ec705595b&name=ccccc&categ=manag

/** Update instance of model with the specified ID **/
 Studentmodel.updateStudent = function(stuid, stuname,stucateg,, cb) {
var newstu = {"name": stuname, "category": stucateg};
 Studentmodel.replaceById( stuid,newstu, function (err) {
 var response = "Successfully removed";
 cb(null, response);
 console.log(response);
 });
 }
Studentmodel.remoteMethod (
 'updateStudent',
 {
 http: {path: '/updatestudent', verb: 'get'},
 accepts: [{arg: 'id', type: 'string', http: { source: 'query' } }, {arg: 'name', type: 'string', http: {
source: 'query' } },{arg: 'category', type: 'string', http: { source: 'query' } }],
 returns: {arg: 'response', type: 'string'}
 }
 );

The screen looks similar to the one shown below:

The database table is as follows:

Before Updating Data Into Database

After Updating Data Into Database
