Database Migration With Flyway

DZone's Guide to

Database Migration With Flyway

Flyway integrates wonderfully with Maven, but one of its biggest assets is the ability to run both SQL migration scripts and Java migration scripts.

Free Resource

Whether you work in SQL Server Management Studio or Visual Studio, Redgate tools integrate with your existing infrastructure, enabling you to align DevOps for your applications with DevOps for your SQL Server databases. Discover true Database DevOps, brought to you in partnership with Redgate.

Flyway is an extremely convenient database migraton tool. First and foremost it integrates wonderfully with Maven. But one of its biggest assets is the ability to run both SQL migration scripts and Java migration scripts.

Let us start with a simple Maven project.

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <groupId>migration</groupId>
    <artifactId>com.gkatzioura</artifactId>
    <version>1.0-SNAPSHOT</version>

    <properties>
        <flyway.version>3.1</flyway.version>
        <mysql.driver.version>5.1.33</mysql.driver.version>
        <database.url>{your jdbc url}</database.url>
        <database.user>{your database user}</database.user>
        <databese.password>{your database password}</databese.password>
    </properties>

    <dependencies>
        <dependency>
            <groupId>org.flywaydb</groupId>
            <artifactId>flyway-core</artifactId>
            <version>${flyway.version}</version>
        </dependency>
    </dependencies>

    <build>
        <plugins>
            <plugin>
                <groupId>org.flywaydb</groupId>
                <artifactId>flyway-maven-plugin</artifactId>
                <version>${flyway.version}</version>
                <configuration>
                    <baselineOnMigrate>true</baselineOnMigrate>
                    <url>${database.url}</url>
                    <user>${database.user}</user>
                    <password>${databese.password}</password>
                </configuration>
                <dependencies>
                    <dependency>
                        <groupId>mysql</groupId>
                        <artifactId>mysql-connector-java</artifactId>
                        <version>${mysql.driver.version}</version>
                    </dependency>
                </dependencies>
            </plugin>
        </plugins>
    </build>
</project>

When you issue through maven

mvn flyway:migrate

Then flyway will will lookup on the db/migration folder of your target to find any migration files. This folder can be changed by altering the content of the locations inside the configuration of the flyway plugin.

For my first migration file I will use sql

The sql file will be located on the db/migration folder which will reside on the maven resources folder.
The name would be V1_1__Create_Persons.sql
Therefore the full path would be src/main/resources/db/migration/V1_1__Create_Persons.sql

CREATE TABLE Persons
(
PersonID bigint(20) NOT NULL AUTO_INCREMENT,
LastName varchar(255),
FirstName varchar(255),
);

The second file would be a java file.

It will be located on the package db.migration folder which will reside on the maven src folder.

The name would be V1_2__Insert_Persons.java

Therefore the full path would be src/main/java/db/migration/V1_2__Insert_Persons.java

package db.migration;

import org.flywaydb.core.api.migration.jdbc.JdbcMigration;

import java.sql.Connection;
import java.sql.Statement;

public class V1_2__Insert_Persons implements JdbcMigration
{

    @Override
    public void migrate(Connection connection) throws Exception
    {
        Statement stmt = connection.createStatement();

        stmt.addBatch("INSERT INTO Persons (FirstName,LastName) VALUES ('Emmanouil','Gkatziouras')");

        stmt.addBatch("INSERT INTO Persons (FirstName,LastName) VALUES ('Do not know','this guy')");

        try {
            stmt.executeBatch();
        }
        finally {
            stmt.close();
        }

    }

}

Since we provide a java file it is wise to call flyway by

mvn clean compile flyway:migrate


It’s easier than you think to extend DevOps practices to SQL Server with Redgate tools. Discover how to introduce true Database DevOps, brought to you in partnership with Redgate
