De-Virtualization in CoreCLR: Part I

I mentioned that we are doing some work to enable de-virtualization of our code, as well as get ready for CoreCLR changes that will get the JIT to do more de-virtualization.

I was asked (by Maayan) about this, more specifically:

How does manual de-virtualization work? AFAIK, the compiler always emits a CallVirt instruction for non-static method calls, regardless of weather the method is virtual or not (and regardless of weather the class is sealed or not). Are you extending the C# compiler and overriding the emission code? Are you re-JITting the code in runtime (as profilers do using the profiler API)?

And the answer is that Maayan is correct. C# is defined (for various reasons related to ECMA approval process over 15 years ago) to always dispatch methods using CallVirt. But CallVirt is an IL instruction, not an assembly one.

Here is some code for various code, as well as the relevant assembly being generated for it (CoreCLR 1.1, X64, Release). Don’t worry about the assembly, I have detailed explanations below for each part.

/*
 sub         rsp,28h
 mov         rcx,rdx
 mov         r11,7FFABFEA0020h
 cmp         dword ptr [rcx],ecx
 call        qword ptr [r11]
 nop
 add         rsp,28h
 ret
*/
public void Run(IActor d)
{
    d.Exec();
}

/*
 sub         rsp,28h
 mov         rcx,rdx
 mov         rax,qword ptr [rdx]
 mov         rax,qword ptr [rax+40h]
 call        qword ptr [rax+20h]
 nop
 add         rsp,28h
 ret
*/
public void Run(ActorVirtual d)
{
    d.Exec();
}


/*
 sub         rsp,28h
 mov         qword ptr [rsp+38h],rdx
 lea         rcx,[rsp+38h]
 call        00007FFACA4C00E8
 nop
 add         rsp,28h
 ret
*/
public void Run(ActorStruct_NoInline d)
{
    d.Exec();
}

/*
 sub         rsp,28h
 mov         rcx,1EB4DDC3068h
 mov         rcx,qword ptr [rcx]
 call        00007FFACA4B0750
 nop
 add         rsp,28h
 ret
*/
public void Run(ActorStructStruct d)
{
    d.Exec();
}

// all Exec impl, are:

public void Exec()
{
    Console.WriteLine("1");
}

This is a pretty simple (non-inlined) set of methods that are just there to make sure that you can see what ends up actually running. The actual method just ends up calling Console.WriteLine, but that is about it.

Now, let's inspect each of those behaviors one at a time. First, let's look at how an interface dispatch works.

/*
 sub         rsp,28h                 - reserve stack space
 mov         rcx,rdx                 - move incoming parameter to rcx (this pointer for the next call method in this case)
 mov         r11,7FFABFEA0020h       - move virtual stub address to r11
 cmp         dword ptr [rcx],ecx     - ensure that we weren't given null value
 call        qword ptr [r11]         - call the stub with the address of the interface impl obj
 nop
 add         rsp,28h                 - free stack space
 ret
*/
public void Run(IActor d)
{
    d.Exec();
}

/*
rough C# code would be:
  if(d == null) trap();
  StubCallFor_IActor(d); <-- will decide based on type of d how to run it
*/

If you want the gory details, you can look for those in the Book of the Runtime. But basically, we are jumping to a code location that will find the proper code that we need to execute. Note that there is still additional work there to actually route the method to the appropriate place, which is hidden from us by the runtime, JIT, etc.

See the funny CMP method there? It is there to generate a dereference of the address by the CPU, which will cause it raise a trap if the address is invalid, and if the address is 0, the CLR will convert that to a NullReferenceException.

Now, what about a virtual method call? That is actually simpler since is it similar to how I learned it when I worked with C++.

/*
 sub         rsp,28h                   - reserve stack space
 mov         rcx,rdx                   - move the d parameter to rcx, which will serve as the this pointer for the next call

 mov         rax,qword ptr [rdx]       - this two lines can be translated to
 mov         rax,qword ptr [rax+40h]   - rax = *(&d + 64) - which is getting to the virtual method table

 call        qword ptr [rax+20h]       - (rax + 32) (); - invoke a specific method from the virtual method table
                                       - basically
 nop
 add         rsp,28h                   - free stacl space
 ret
*/
public void Run(DisposeImplVirtual d)
{
    d.Exec();
}

/*
rough C# code would be:

    d.MethodTable[4](d);
*/

Basically, at the end of the object, we have a method table pointer, and we dereference that and then another pointer to the specific method we want to invoke. Part of the reason that virtual calls are expensive is exactly this; we have to jump around in memory a lot, and that means that we both have to issue more instructions, and more to the point, we have to touch a lot more memory, which can cause cache lines to be evicted, forcing us to stall.

What about a struct method call? To make things easier, I made sure that it couldn’t be inlined, which generated:

/*
 sub         rsp,28h                  - reserve stack space
 mov         qword ptr [rsp+38h],rdx  - put value of parameter on the stack
 lea         rcx,[rsp+38h]            - put address of the stack in rcx (this for the next call)
 call        00007FFACA4C00E8         - call the method directly
 nop
 add         rsp,28h                  - release stack space
 ret
*/
public void Run(ActorStruct_NoInline d)
{
    d.Exec();
}
view raw

In this case, I’m using an empty struct, so it has as much size as a pointer, which is why you can see it being passed around like it was just a pointer. If I had a bigger struct, I would see very different code.

sub         rsp,28h
mov         rcx,rdx
call        00007FFAC9EE00E8
nop
add         rsp,28h
ret

Why is the code simpler when the struct is bigger? Well, the answer is quite simple; we are looking at the actual method that was called with this parameter, but the job of actually sending the parameter is done by the caller, so we aren’t seeing it here.

What is going on is that as long as your struct is empty or have a single value that is an 4 / 8 bytes long, the CLR can optimize that to be a regular parameter, making it effectively free. In such cases, you can see the struct being passed around in registers (the struct itself, since it is copied, not the address to it).

However, if you have a struct that is composed of multiple fields, that require us to copy each field to the stack before call, which on large stacks can take a bit.

I mentioned that this was done with a struct that we disabled inlining for, what happens if we allow inlining (the default)?

/*
 sub         rsp,28h              - reserve stack space
 mov         rcx,1EB4DDC3068h     - load address of string constants table entry
 mov         rcx,qword ptr [rcx]  - deferefence the relavant string constant position
 call        00007FFACA4B0750     - call WriteLine
 nop
 add         rsp,28h              - free stack space
 ret
*/
public void Run(ActorStruct d)
{
    d.Exec();
}

This looks completely different than anything we have seen so far. And in fact, it is. What we are seeing here is the result of inlining the struct method invocation. Because the compiler was able to figure out what the end target of the call is, and because it is small enough to be inlined, we can skip calling the method entirely and just directly run the code.

As it turns out, this can have a dramatic affect on performance (on both directions, mind), and something that you need to carefully consider when you analyze your application performance.

But the short of it is, the fewer jumps and dereferences we have, the better it is for us. And you can see the various methods (pun intended) that the CLR uses to dispatch them. In my next post, I’ll talk about how we can make use of this behavior.
