Deploy and Roll-back System Configs with Capistrano, mcollective and Puppet - Part 2

DZone's Guide to

Deploy and Roll-back System Configs with Capistrano, mcollective and Puppet - Part 2

Free Resource

“Automated Testing: The Glue That Holds DevOps Together” to learn about the key role automated testing plays in a DevOps workflow, brought to you in partnership with Sauce Labs.

Table of contents for Continuous Delivery of Server Configurations

  1. Turning a 5 Hour Manual Build and Deploy Routine Into a Single Code Commit - Part 1
  2. Part 2
  3. Putting the butler to the test - Part 3

I’ve been playing around with Capistrano over the past few weeks and I’ve recently created a way to use the power of Capistrano’s “deploy” and “rollback” features with Puppet and MCollective to enable me to have complete control over the deployment of my system configurations.We’ll start with Capistrano as it’s the key to all of this – you’ll need the following gems installed:

  • capistrano
  • capistrano-ext
  • railsless-deploy

I’ve taken to having  minimalist cap files so “cd” into your puppet manifests and type the following:


Now edit the Capfile so it looks as follows:

load 'deploy' if respond_to?(:namespace) # cap2 differentiator
require 'capistrano'
require 'rubygems'
require 'railsless-deploy'
load 'config/deploy'

We’re also going to use the ‘multistage’ extension to make sure that we only deploy to our production environment deliberately, so update the config/deploy.rb file and make it look like this:

set :stages, %w[staging production]
set :deploy_to, "/usr/share/puppet/configuration"
set :deploy_via, :export
set :application, "Puppet Manifests"
set :repository, "git://gitserver/puppet.git"
set :scm, :git
set :default_stage, "staging"
set :use_sudo, false

require 'capistrano/ext/multistage'

Note that the stages need to be set before you include the multistage extension otherwise they won’t get setup.

If you now run cap -vT then you should see the following amongst the other tasks:

cap production               # Set the target stage to `production’.
cap staging                     # Set the target stage to `staging’.

This means that we can now run “cap staging deploy” or “cap production deploy” depending on what we want to do.  Note also that we set the default stage to staging so that we have to explicitly state when we want to deploy to production – this will hopefully cut down on any accidental incidents of untested configs making it to the live servers!

Finally, note that we’ve disabled sudo – this makes things more secure (you can’t have your deploy user executing random code on the servers!) and also makes it easier to configure the server (no editing of /etc/sudoers).

The next step is to create the user account on the puppetmaster for deployment.  For simplicity’s sake, we’ll create a user called “deploy”:

root@puppetmaster # useradd -m deploy

And assign it ownership of the puppet manifest directory (/usr/share/puppet/configuration in our case):

root@puppetmaster # chown -Rvf deploy: /usr/share/puppet/configuration

Puppet doesn’t care about write permissions to the manifests/modules directories as far as I can tell so as long as the “puppet” user can read the manifests/modules, we’re all good.

Now setup the access for the user.  I have deliberately not set a password for this account as I use ssh-keys which are not as easily brute forced!

root@puppetmaster # su – deploy

deploy@puppetmaster > vim ~/.ssh/authorized_keys

Place the public SSH key of the user who will be running the “cap production deploy” command into the authorized_keys file listed above.

A quick gotcha: if you’re going to use a staging server with SSH keys, make sure that the key of the user account running “cap production deploy” is on both the gateway server and the puppetmaster, otherwise this will fail!

SSH to the puppetmaster as your deploy user from the account that will be running “cap production deploy” so that you don’t get any SSH-Key errors.

Now setup your config for the staging environment in config/deploy/staging.rb:

set :user, "deploy"
role :web, "staging"
after 'deploy:symlink', 'puppet:run'

and do the same for config/deploy/production.rb:

set :gateway, "deploy@support-gateway"
set :user, "deploy"
set :deploy_via, :copy
role :web, "puppetmaster" # set this to the fully qualified domain name of your puppetmaster
after 'deploy:symlink', 'puppet:run'
after 'deploy:rollback', 'puppet:run'

This means that we can over-ride the “defaults” from deploy.rb for each environment.

You may have noticed the following line:

after ‘deploy:symlink’, ‘puppet:run’

This executes a custom task in a custom namespace once the “current” symlink has been updated to force a puppet run.  The issue at the moment is that this task doesn’t exist yet!

Update config/deploy.rb to look like the following:

set :stages, %w[staging production]
set :application, "Puppet Manifests"
set :repository, "git://localhost/puppet.git"

set :scm, :git

role :web, "puppetmaster" # set this to the fully qualified domain name of your puppetmaster

require 'capistrano/ext/multistage'
require 'mcollective'


class MCProxy
    include MCollective::RPC

    def initialize(agent)
        @agent = rpcclient(agent)

    def runaction(action, args)
        printrpc @agent.send(action, args)

namespace :puppet do
    desc <<-DESC
Run Puppet to pull the latest versions
    task :run do
        puppet = MCProxy.new("puppetd")
        puppet.runaction("runonce",:concurrency => '2')

The important bits to pay attention to are the “require ‘mcollective’ ” (which loads the MCollective libraries) and the MCProxy class (thanks to @ripienaar for helping me with that!).

The MCProxy class enables us to create the puppet:run task and call the “puppetd” agent – note that you could call any agent with any argument you want here, we’re just calling the puppet one.

Now, I’ll leave the rest of the configuration to you (setting up SSH keys/users etc.) however when you now run “cap production deploy” you should see your puppet configs getting checked out of git and SCP’d via the gateway to your puppet master followed by MCollective executing a puppet run across your entire server estate.

The final task is to configure puppet to read the new configs.  I’m assuming that you have all your manifests in one huge repo here, so just update your puppet config to point to the correct directory:

        vardir = /var/lib/puppet
        logdir = /var/log/puppet
        rundir = /var/run/puppet
        ssldir = $vardir/ssl
modulepath = /usr/share/puppet/configuration/current/manifests

If you don’t know Capistrano, “current” is a symlink which gets updated everytime you successfully deploy/rollback.  Puppet won’t let you set /etc/puppet as a symlink, so you have to adapt the configs to point to the “current” release of your configs.

Now do the inital setup:

cap production deploy:setup # creates the directories required

root@puppetmaster # service puppetmaster restart

and deploy the first version of your modules:

cap production deploy

Let me know how you get on…
