Displaying Google Street View Images in JavaScript

DZone's Guide to

Displaying Google Street View Images in JavaScript

A few days ago a buddy of mine brought me an interesting problem. He was using JavaScript to dynamically display a Google Street View image of a property. Instead of making use of the Google Maps APIs, he simply crafted the URL dynamically based on an address. This worked well, except that in some cases, a Street View image wasn’t available. Read on to hear about the fix we found.

· Web Dev Zone
Free Resource

Learn how to build modern digital experience apps with Crafter CMS. Download this eBook now. Brought to you in partnership with Crafter Software

A few days ago a buddy of mine brought me an interesting problem. He was using JavaScript to dynamically display a Google Street View image of a property. Instead of making use of the Google Maps APIs, he simply crafted the URL dynamically based on an address. Here is a snippet of the code that did this.

$.ajax({
    type: "GET",
    url: 'data/getaddress.cfm',
    data: 'parcelid='+getUrlVars()["parcelid"]+'&GEOID='+getUrlVars()["GEOID"],
    success: function (address) {
        $('#map-canvas').html('<img src="http://maps.googleapis.com/maps/api/streetview?size=500x500'&sensor=false&location='+address+'">');
        }
});

As you can see, the image tag passes parameters for height, width, and address, with the address portion being dynamic. This worked well, except that in some cases, a Street View image wasn’t available:

Bad street view

He wanted to know—was it possible to handle that and do something special when an image wasn’t available? I did some quick research and ran across a Stack Overflow answer by @user1852570 (probably not a real name—just assuming):

How to detect if Google StreetView is available in an address/coordinates

His answer describes using StreetViewService of the Google Maps API. If you follow the link to the Google API example you’ll see that you can request a Street View result and check a result value to see if data was available. I took that initial example and integrated it into a dynamic example like he was using originally. Here is the updated code. As a note—this script expects URL parameters for a location that get translated into longitude and latitude by a back-end service.

<html>
<head>

<script type="text/javascript" src="//ajax.googleapis.com/ajax/libs/jquery/2.1.4/jquery.min.js"></script>
<script>
function getUrlVars() {
    var vars = {};
    var parts = window.location.href.replace(/[?&]+([^=&]+)=([^&]*)/gi, function(m,key,value) {
        vars[key] = value;
    });
    return vars;
}


//credit: http://stackoverflow.com/a/13568401/52160
function initMap() {
    console.log('initMap called');
    var parts = getUrlVars();

    $.get('data/getlatlng.cfm?parcelid='+parts['parcelid']+'&geoid='+parts['GEOID'], function(res) {

        var sv = new google.maps.StreetViewService();

        panorama = new google.maps.StreetViewPanorama(document.getElementById('pano'));

        sv.getPanorama({location: {lat:res.lat, lng:res.lng}, radius: 50}, processSVData)

    },'json');


}

function processSVData(data, status) {
  if (status === google.maps.StreetViewStatus.OK) {
    console.log('ok');
    $('#pano').show();
    panorama.setPano(data.location.pano);

    panorama.setPov({
        heading: 270,
        pitch: 0
    });

    panorama.setVisible(true);

  } else {
    console.error('Street View data not found for this location.');
    $('#pano').hide();
  }
}
</script>

</head>

<body>

<div id="pano" style="width: 550px; height: 350px;"></div>


<script async defer
    src="https://maps.googleapis.com/maps/api/js?key=somekey&callback=initMap">
</script>
</body>
</html>

Things kick off with the Google Maps script tag at the very bottom of the page. It is set to run initMap when done. If you go up to that, we begin by firing off the call to the service to figure out the longitude and latitude of the particular thing we’re looking for. That service isn’t important—just note that it returns a longitude and latitude. As an FYI, the "image url" shortcut allows for generic addresses, like "So and So Elm Street", but the API we’re using requires a longitude and latitude instead.

Next, we create a Street View Panaroma object to display the image. After setting the address, we can use the callback and the google.maps.StreetViewStatus result to see if we had good data. For my friend, he simply wanted to hide the image if nothing was available. Obviously, you could do something else instead.

And, that’s it. Now to be fair, the end result is a bit different. Instead of just an image, we actually have an "embedded" Street View that can be rotated and changed.

Good street view

I believe you could use the API to prevent that if you really wanted to, but I doubt that really matters. You could also skip setting the result at all and just use the initial image URL version on a good result.
