Unboxing the eSOMiMX6-micro: NXP i.MX6 System on Module

DZone's Guide to

Unboxing the eSOMiMX6-micro: NXP i.MX6 System on Module

This look at the eSOMiMX6-micro board will guide you through getting it set up on a desktop and some ideal use cases for its components.

· IoT Zone
Free Resource

Download Red Hat’s blueprint for building an open IoT platform—open source from cloud to gateways to devices.

An interesting trend in the industry is SOM (System on Module): a high-performance processor typically running Linux, Windows, or Android with all the memory and necessary power logic on a small module. The key benefit is that I don’t need to worry about the complex ball grid routing and the DDR memory connections/lines: All these problems are solved on a small module, which I can then use in my design. It seems that NXP i.MX application processors are getting popular in this domain, and after looking at the Toradex Colibri modules, I have an i.MX6 module on my desk from e-con Systems:

eSOMiMX6-micro Top Side

eSOMiMX6-micro top side

I’m looking at different ARM Ax modules to be used in an advanced class. Raspberry Pi or Toradex are possible candidates, but this module from e-consystems.com has caught my eye because of its small dimensions. The company has many camera modules in their portfolio, and that’s probably why their base/evaluation/carrier board comes with three (!!!) camera and two display ports beside the HDMI connector:

eSOMiMX6-micro SOM Block Diagram

eSOMiMX6-micro SOM block diagram (Source: e-con_Meissa-I-SOM_User-Manual.pdf)

The SOM module (54×20 mm) is mounted on top of the base board (“Meissa-I”) (80×40 mm).

Module on top of the base board

Module on top of the base board

The bottom side shows the audio connector on the left with the micro SD card socket:

Board Bottom Side

Board bottom side

The module came in a box:

eSOMiMX6 box

eSOMiMX6 box

One box in the box included the power adapter (12V DC, 3.8A, with US plug connector only), a micro USB cable and a mini-HDMI – HDMI cable:

Power Supply

Power supply

The other box had the board, a Laird multi-band PCB antenna, and an 8GB micro SD card:

Board Package

Board package

Powering the board with delivered power supply and connecting it to a display using the delivered HDMI cable:

Powered SOM Module

Powered SOM module

And it happily boots and boots into desktop mode:

Desktop mode

Desktop mode

Well, not that useful without mouse or keyboard. Luckily I had a micro-USB converter cable, so I was able to attach a mouse to the USB OTG port:

Mouse with OTG Adapter Cable

Mouse with OTG adapter cable

With this, things are getting better:

Desktop, next steps

Desktop, next steps

With just one USB port, I recommend to use a joint keyboard+mouse device or using a USB hub to connect multiple USB devices.

There is another USB (Debug) port available:

UART-to-USB Bridge

UART-to-USB bridge

It shows up as Silicon Labs CP210x USB to UART Bridge:

Silicon Labs CP210x USB to UART Bridge

Silicon Labs CP210x USB to UART bridge

Connecting to it with 115200 baud, I can see the boot messages:

Boot Messages

Boot messages

The eSOMiMX6-micro board with the i.MX6 on it is a tiny board. With its camera connectors and Wi-Fi/BLE interface, it is very well suited for battery-operated camera applications. Because the board is rather new, there is not much support material or documentation available for it, so I'll continue to dig through what's there. But at least I was able to get it up and running in about one hour which is not bad. Just make sure you have all the needed extra cables or power plug adapters available was the biggest obstacle.

Happy E-coning!
