Exploratory Data Analysis in R (Introduction)

Introduction

EDA consists of univariate (1-variable) and bivariate (2-variables) analysis.
In this post, we will review some functions that lead us to the analysis of the first case.

• Step 1 - First approach to data.
• Step 2 - Analyzing categorical variables.
• Step 3 - Analyzing numerical variables.
• Step 4 - Analyzing numerical and categorical at the same time.

Covering some key points in a basic EDA:

• Data types.
• Outliers.
• Missing values.
• Distributions (numerically and graphically) for both, numerical and categorical variables.

Type of Analysis Results

There are two type of result: informative or operative.

• Informative: For example plots, or any long variable summary. We cannot filter data from it, but it gives us a lot of information at once. Most be used at the EDA stage.
• Operative: The results can be used to take an action directly on the data workflow (for example, selecting any variables whose percentage of missing values are below 20%). Most used in the Data Preparation stage.

Getting Set Up

Uncoment in case you don't have any of these libraries:

# install.packages("tidyverse")
# install.packages("funModeling")
# install.packages("Hmisc")

A newer version of funModeling has been released on Ago-1, please update!

Now load the needed libraries...

library(funModeling)
library(tidyverse)
library(Hmisc)

tl;dr (Code)

Run all the functions in this post in one-shot with the following function:

basic_eda <- function(data)
{
  glimpse(data)
  df_status(data)
  freq(data)
  profiling_num(data)
  plot_num(data)
  describe(data)
}

Replace data with your data, and that's it!

basic_eda(my_amazing_data)

Creating the data for this example:

Using the heart_disease data (from funModeling package). We will take only 4 variables for legibility.

data=heart_disease %>% select(age, max_heart_rate, thal, has_heart_disease)

Step 1: The First Approach to the Data

Number of observations (rows) and variables, and a head of the first cases.

glimpse(data)

## Observations: 303
## Variables: 4
## $ age               <int> 63, 67, 67, 37, 41, 56, 62, 57, 63, 53, 57, ...
## $ max_heart_rate    <int> 150, 108, 129, 187, 172, 178, 160, 163, 147,...
## $ thal              <fct> 6, 3, 7, 3, 3, 3, 3, 3, 7, 7, 6, 3, 6, 7, 7,...
## $ has_heart_disease <fct> no, yes, yes, no, no, no, yes, no, yes, yes,...

Getting the metrics about data types, zeros, infinite numbers, and missing values:

df_status(data)

##            variable q_zeros p_zeros q_na p_na q_inf p_inf    type unique
## 1               age       0       0    0 0.00     0     0 integer     41
## 2    max_heart_rate       0       0    0 0.00     0     0 integer     91
## 3              thal       0       0    2 0.66     0     0  factor      3
## 4 has_heart_disease       0       0    0 0.00     0     0  factor      2

df_status returns a table, so it is easy to keep with variables that match certain conditions like:

• Having at least 80% of non-NA values (p_na < 20).
• Having less than 50 unique values (unique <= 50).

TIPS:

• Are all the variables in the correct data type?
• Variables with lots of zeros or NAs?
• Any high cardinality variable?

[Read more here.]

Step 2: Analyzing Categorical Variables

freq function runs for all factor or character variables automatically:

freq(data)

##   thal frequency percentage cumulative_perc
## 1    3       166      54.79              55
## 2    7       117      38.61              93
## 3    6        18       5.94              99
## 4 <NA>         2       0.66             100

##   has_heart_disease frequency percentage cumulative_perc
## 1                no       164         54              54
## 2               yes       139         46             100

## [1] "Variables processed: thal, has_heart_disease"

TIPS:

• If freq receives one variable —freq(data$variable)— it retruns a table. This is useful for treating high cardinality variables (like zip code).
• Export the plots to jpeg format in the current directory: freq(data, path_out = ".")
• Do all the categories make sense?
• Are there lots of missing values?
• Always check the absolute and relative values

[Read more here.]

Step 3: Analyzing Numerical Variables

We will see: plot_num and profiling_num. Both run automatically for all numerical/integer variables:

Graphically

plot_num(data)

Export the plot to jpeg: plot_num(data, path_out = ".")

TIPS:

• Try to identify high-unbalanced variables.
• Visually check any variable with outliers.

[Read more here.]

Quantitatively

profiling_num runs for all numerical/integer variables automatically:

data_prof=profiling_num(data)

##         variable mean std_dev variation_coef p_01 p_05 p_25 p_50 p_75 p_95
## 1            age   54       9           0.17   35   40   48   56   61   68
## 2 max_heart_rate  150      23           0.15   95  108  134  153  166  182
##   p_99 skewness kurtosis iqr        range_98     range_80
## 1   71    -0.21      2.5  13        [35, 71]     [42, 66]
## 2  192    -0.53      2.9  32 [95.02, 191.96] [116, 176.6]

TIPS:

• Try to describe each variable based on its distribution (also useful for reporting).
• Pay attention to variables with high standard deviation.
• Select the metrics that you are most familiar with: data_prof %>% select(variable, variation_coef, range_98): A high value in variation_coef may indictate outliers. range_98 indicates where most of the values are.

[Read more here.]

Step 4: Analyzing Numerical and Categorical at the Same Time

describe from Hmisc package.

library(Hmisc)
describe(data)

## data
##
##  4  Variables      303  Observations
## ---------------------------------------------------------------------------
## age
##        n  missing distinct     Info     Mean      Gmd      .05      .10
##      303        0       41    0.999    54.44     10.3       40       42
##      .25      .50      .75      .90      .95
##       48       56       61       66       68
##
## lowest : 29 34 35 37 38, highest: 70 71 74 76 77
## ---------------------------------------------------------------------------
## max_heart_rate
##        n  missing distinct     Info     Mean      Gmd      .05      .10
##      303        0       91        1    149.6    25.73    108.1    116.0
##      .25      .50      .75      .90      .95
##    133.5    153.0    166.0    176.6    181.9
##
## lowest :  71  88  90  95  96, highest: 190 192 194 195 202
## ---------------------------------------------------------------------------
## thal
##        n  missing distinct
##      301        2        3
##
## Value         3    6    7
## Frequency   166   18  117
## Proportion 0.55 0.06 0.39
## ---------------------------------------------------------------------------
## has_heart_disease
##        n  missing distinct
##      303        0        2
##
## Value        no  yes
## Frequency   164  139
## Proportion 0.54 0.46
## ---------------------------------------------------------------------------

Really useful to get a quick picture of all the variables. But is not as operative as freq and profiling_num when we want to use its results to change our data workflow.

TIPS:

• Check min and max values (outliers).
• Check Distributions (same as before).

[Read more here.]

That's all for now!

----

Pablo Casas.
