Go Full Stack With Java in a Jiffy

DZone's Guide to

Go Full Stack With Java in a Jiffy

Want to learn more about creating a web application that can connect to existing databases? Read this article to learn more about using the Java Stream API for these applications.

· Java Zone ·
Free Resource

Atomist automates your software deliver experience. It's how modern teams deliver modern software.

Ever wanted to quickly create a web application connected to your existing database or build a professional application with short time-to-market requirements? The Java Stream API has unleashed the possibility to write database queries in pure Java.

In this article, we will demonstrate how fast and easy this can be done by leveraging two Java frameworks — Vaadin and Speedment. Because they both use Java Streams, it is easy to connect them together. This means we will end up with a short, concise, and type-safe application.

For this mini-project, we will use the My SQL sample database named "Employees," which provides approximately 160MB of data spread over six separate tables and comprising 4 million records.

The full application code is available at GitHub and you can clone this repository if you want to run the application in your own environment. You will also need trial licenses from both Vaadin and Speedment to use the features used in this article. These are available for free.


The intended end result is a web application where it is possible to analyze gender balance and salary distribution among different departments. The result is displayed graphically, using pure standard Vaadin Charts Java components as depicted in the video below:



Setting Up the Data Model

We are using Speedment Stream ORM to access the database. It is easy to set up any project using the Speedment initializer. Speedment can generate Java classes directly from the database's schema data. After generation, we can create our Speedment instance like this:

Speedment speedment = new EmployeesApplicationBuilder()
                .withUsername("...") // Username need to match database
                .withPassword("...") // Password need to match database
                .build();


Create a Dropdown for Departments

In our web application, we want to have a drop-down list of all departments. It is easy to retrieve the departments from the database as can be seen in this method:

public Stream<Departments> departments() {
    DepartmentsManager depts = speedment.getOrThrow(DepartmentsManager.class);
    return depts.stream();
}


Joining Departments and Employees Together

Now, we are going to create a join relation between Departments and Employees. In the database, there is a many-to-many relation table that connects these tables together named DeptEmpl. First, we create a custom tuple class that will hold our three entries from the joined tables:

public final class DeptEmplEmployeesSalaries {

    private final DeptEmp deptEmp;
    private final Employees employees;
    private final Salaries salaries;

    public DeptEmplEmployeesSalaries(
        DeptEmp deptEmp,
        Employees employees,
        Salaries salaries
    ) {
        this.deptEmp = requireNonNull(deptEmp);
        this.employees = requireNonNull(employees);
        this.salaries = requireNonNull(salaries);
    }

    public DeptEmp deptEmp() { return deptEmp; }

    public Employees employees() { return employees; }

    public Salaries salaries() { return salaries; }

    public static TupleGetter0 deptEmpGetter() {
      return DeptEmplEmployeesSalaries::deptEmp;
    }

    public static TupleGetter1 employeesGetter() {
      return DeptEmplEmployeesSalaries::employees;
    }

    public static TupleGetter2 salariesGetter() {
      return DeptEmplEmployeesSalaries::salaries;
    }
}


The DeptEmplEmployeesSalaries is simply an immutable holder of the three entities, except it has three additional "getter" methods that can be applied to extract the individual entities. Note that they return TupleGetter, which allow joins and aggregations to use optimized versions compared to just using an anonymous lambda or method reference.

Now that we have the custom tuple, we can easily define our join relation:

   private Join joinDeptEmpSal(Departments dept) {
     // The JoinComponent is needed when creating joins
     JoinComponent jc = speedment.getOrThrow(JoinComponent.class);

     return jc.from(DeptEmpManager.IDENTIFIER)
       // Only include data from the selected department
       .where(DeptEmp.DEPT_NO.equal(dept.getDeptNo()))
       // Join in Employees with Employees.EMP_NO equal DeptEmp.EMP_NO
       .innerJoinOn(Employees.EMP_NO).equal(DeptEmp.EMP_NO)
       // Join Salaries with Salaries.EMP_NO) equal Employees.EMP_NO
       .innerJoinOn(Salaries.EMP_NO).equal(Employees.EMP_NO)
       // Filter out historic salary data
       .where(Salaries.TO_DATE.greaterOrEqual(currentDate))
       .build(DeptEmplEmployeesSalaries::new);
   }


When we are building our join expression, we start off by first using the DeptEmp table (as we recall, this is the many-to-many relation table between Departments and Employees). For this table, we apply a where() statement so that we are able to filter out only those many-to-many relations that belong to the department we want to appear in the join.

Next, we join in the Employees table and specify a join relation where newly joined table's column Employees.EMP_NO equal DeptEmp.EMP_NO.

After that, we join in the Salaries table and specify another join relation where Salaries.EMP_NO equal Employees.EMP_NO. For this particular join relation, we also apply a where() statement so that we filter out salaries that are current (and not historic, past salaries for an employee).

Finally, we call the build() method and defines the constructor of our DeptEmplEmployeesSalaries class that holds the three entities DeptEmp, Employees, and Salaries.

Counting the Number of Employees for a Department

Armed with the join method above, it is very easy to count the number of Employees for a certain department in the Join stream. This is how we can go about:

public long countEmployees(Departments department) {
    return joinDeptEmpSal(department)
               .stream()
               .count();
}

Calculating a Salary Distribution Aggregation

By using the built-in Speedment Aggregator, we can express aggregations quite easily. The Aggregator can consume regular Java Collections, Java Streams from a single table as well as Join Streams without constructing intermediary Java objects on the heap. This is because it stores all its data structures completely off-heap.

We first start with creating a "result object" in the form of a simple POJO that is going to be used as a bridge between the completed off-heap aggregation and the Java heap world:

public class GenderIntervalFrequency {

    private Employees.Gender gender;
    private int interval;
    private long frequency;

    private void setGender(Employees.Gender gender) { this.gender = gender; }

    private void setInterval(int interval) { this.interval = interval; }

    private void setFrequency(long frequency) { this.frequency = frequency;}

    private Employees.Gender getGender() { return gender; }

    private int getInterval() { return interval; }

    private long getFrequency() { return frequency; }
}


Now that we have the POJO, we are able to build a method that returns an Aggregation like this:

public Aggregation freqAggregation(Departments dept) {
  Aggregator aggregator =
    // Provide a constructor for the "result object"
    Aggregator.builder(GenderIntervalFrequency::new)
    // Create a key on Gender
    .firstOn(DeptEmplEmployeesSalaries.employeesGetter())
        .andThen(Employees.GENDER)
        .key(GenderIntervalFrequency::setGender)

    // Create a key on salary divided by 1,000 as an integer
    .firstOn(DeptEmplEmployeesSalaries.salariesGetter())
        .andThen(Salaries.SALARY.divide(SALARY_BUCKET_SIZE).asInt())
        .key(GenderIntervalFrequency::setInterval)

    // For each unique set of keys, count the number of entitites
    .count(GenderIntervalFrequency::setFrequency)
    .build();

  return joinDeptEmpSal(dept)
    .stream()
    .parallel()
    .collect(aggregator.createCollector());
}


This requires a bit of explanation. When we invoke the Aggregator.builder() method, we provide a constructor of the "result object" that we are using as a bridge between the off-heap and the on-heap world.

After we have a builder, we can start defining our aggregation. Usually, the clearest way is to start off with the keys (i.e. groups) that we are going to use in the aggregation. When we are aggregating results for a join operation, we first need to specify which entity we want to extract our key from. In this case, we want to use the employee's gender, so we invoke .firstOn(eptEmplEmployeesSalaries.employeesGetter()) which will extract the Employees entity from the tuple. Then, we apply .andThen(Employees.GENDER) which, in turn, will extract the gender property from the Employees entity. The key() method takes a method reference for a method that is going to be called once we want to actually read the result of the aggregation.

The second key is specified in a similar way, only here we apply the .firstOn(DeptEmplEmployeesSalaries.salariesGetter()) method to extract the Salaries entity instead of the Employees entity. When we then apply the .andThen() method, we are using an expression to convert the salary so it is divided by 1,000 and seen as an integer. This will create separate income brackets for every thousand dollars in salary.

The count() operator simply says that we want to count the occurrence of each key pair. So, if there are two males that have an income in the 57 bracket (i.e. a salary between 57,000 and 57,999) the count operation will count those two for those keys.

Finally, in the line starting with return, the actual computation of the aggregation will take place where the application will aggregate all the thousands of salaries in parallel and return an Aggregation for all the income data in the database. An Aggregation can be thought of as a kind of List with all the keys and values, only that the data is stored off-heap.

Adding In-JVM-Memory Acceleration

By just adding two lines to our application, we can get a high-performance application with in-JVM-memory acceleration.

Speedment speedment = new EmployeesApplicationBuilder()
        .withUsername("...") // Username need to match database
        .withPassword("...") // Password need to match database
        .withBundle(InMemoryBundle.class) // Add in-JVM-acceleration
        .build();

        // Load a snapshot of the database into off-heap JVM-memoory
        speedment.get(DataStoreComponent.class)
            .ifPresent(DataStoreComponent::load);


The InMemoryBundle allows the entire database to be pulled in to the JVM using off-heap memory and then allows Streams and joins to be executed directly from RAM, instead of using the database. This will improve performance and will make the Java application work more deterministically. Having data off-heap also means that data will not affect Java Garbage Collect allowing huge JVMs to be used with no GC impact.

Thanks to the In-memory acceleration, even the biggest department with over 60,000 salaries will be computed in less than 100 ms on my laptop. This will ensure that our UI stays responsive.

Building the UI in Java

Now that the data model is finished, we move on to the visual aspects of the application. As mentioned previously, this is done by utilizing Vaadin, a framework that allows implementation of HTML5 web user interfaces using Java. The Vaadin framework is built on the notion of components, which could be a layout, a button, or anything in between. The components are modeled as objects that can be customized and styled in an abundance of ways.

The image above describes the structure of the GUI we intend to build for our DataModel. It constitutes of nine components, out of which five read information from the database and presented it to the user while the rest are static. Without further ado, let's start configuring the UI.

The Vaadin UI Layer

To integrate Vaadin in the application, we downloaded a starter pack from Vaadin to set up a simple project base. This will automatically generate a UI class which is the base of any Vaadin application.

@Theme("mytheme")
public class EmployeeUI extends UI {

    @Override // Called by the server when the application starts
    protected void init(VaadinRequest vaadinRequest) { }

    // Standard Vaadin servlet which was not modified
    @WebServlet(urlPatterns = "/*", name = "MyUIServlet", asyncSupported = true)
    @VaadinServletConfiguration(ui = EmployeeUI.class, productionMode = false)
    public static class MyUIServlet extends VaadinServlet { }
}


The overridden init() is called from the server when the application is started, hence this is where we soon will state what actions are to be performed when the application is running. EmployeeUI also contains MyUIServlet, which is a standard servlet class used for deployment. No modification was needed for the sake of this application.

Creation of Components

As mentioned above, all of our components will be declared in init(). This is not suggested as a best practice, but it works well for an application with a small scope. Although, we would like to collectively update the majority of the components from a separate method when a new department is selected, meaning those will be declared as instance variables along the way.

Application Title

We start off simple by creating a Label for the title. Since its value will not change, it can be locally declared.

Label appTitle = new Label("Employee Application");
appTitle.setStyleName("h2");


In addition to a value, we give it a style name. Style names allow full control of the appearance of the component. In this case, we use the built-in Vaadin Valo Theme and select a header styling simply by setting the parameter to "h2." This style name can also be used to target the component with custom CSS (for example .h2 { font-family: 'Times New Roman; }).

Text Fields

To view the number of employees and the average salary for the selected department, we use the TextField component. TextField is mainly used for user text input; although, by setting it to read-only, we prohibit any user interaction. Notice how two style names can be used by separating them with a blank space.

noOfEmployees = new TextField("Number of employees"); // Instance variable
noOfEmployees.setReadOnly(true);
// Multiple style names are separated with a blank space
noOfEmployees.setStyleName("huge borderless");


This code is duplicated for the averageSalary TextField, although with a different caption and variable name.

Charts

Charts can easily be created with the Vaadin Charts addon, and just like any other component, a chart Java Object with corresponding properties. For this application, we used the COLUMN chart to view gender balance and an AREASPLINE for the salary distribution.

/* Column chart to view balance between female and male employees at a certain department */
genderChart = new Chart(ChartType.COLUMN);
Configuration genderChartConfig = genderChart.getConfiguration();
genderChartConfig.setTitle("Gender Balance");

// 0 is only used as an init value, chart is populated with data in updateUI()
maleCount = new ListSeries("Male", 0);
femaleCount = new ListSeries("Female", 0);
genderChartConfig.setSeries(maleCount, femaleCount);

XAxis x1 = new XAxis();
x1.setCategories("Gender");
genderChartConfig.addxAxis(x1);

YAxis y1 = new YAxis();
y1.setTitle("Number of employees");
genderChartConfig.addyAxis(y1);


Most of the properties associated with a chart are controlled by its configuration which is retrieved with getConfiguration(). This is then used to add a chart title, two data series, and the axis properties. For the genderChart, a simple ListSeries was used to hold the data because of its simple nature. Although for the salaryChart below, a DataSeries was chosen since it handles a larger and more complicated data sets.

The declaration of the salaryChart is very similar to that of the genderChart. Likewise, the configuration is retrieved and used to add a title and axes.

salaryChart = new Chart(ChartType.AREASPLINE);


Since both charts display data for male and females we decide to use a shared legend that we fix in the upper right corner of the salaryChart.

/* Legend settings */
Legend legend = salaryChartConfig.getLegend();
legend.setLayout(LayoutDirection.VERTICAL);
legend.setAlign(HorizontalAlign.RIGHT);
legend.setVerticalAlign(VerticalAlign.TOP);
legend.setX(-50);
legend.setY(50);
legend.setFloating(true);


Lastly, we add two empty DataSeries, which will be populated with data at a later stage.

// Instance variables to allow update from UpdateUI()
maleSalaryData = new DataSeries("Male");
femaleSalaryData = new DataSeries("Female");
salaryChartConfig.setSeries(maleSalaryData, femaleSalaryData);


Department Selector

The final piece is the department selector that controls the rest of the application.






/* Native Select component to enable selection of Department */
NativeSelect<Departments> selectDepartment = new NativeSelect<>("Select department");
selectDepartment.setItems(DataModel.departments());
selectDepartment.setItemCaptionGenerator(Departments::getDeptName);
selectDepartment.setEmptySelectionAllowed(false);


We implement it as a NativeSelect<T> component that calls departments(), which was previously defined in DataModel, to retrieve a Stream of Departments from the database. Next, we specify what property of Department to display in the dropdown list (default is toString()).

Since we do not allow empty selections, we set the defaultDept to the first element of the Department Stream. Note that the defaultDept is stored as a variable for later use.

/* Default department to use when starting application */
final Departments defaultDept = DataModel.departments().findFirst().orElseThrow(NoSuchElementException::new);
selectDepartment.setSelectedItem(defaultDept);

Adding the Components to the UI

So far, we have only declared the components without adding them to the actual canvas. To be displayed in the application, they all need to be added to the UI. This is usually done by attaching them to a Layout. Layouts are used to create a structured hierarchy and can be nested into one and other.

HorizontalLayout contents = new HorizontalLayout();
contents.setSizeFull();

VerticalLayout menu = new VerticalLayout();
menu.setWidth(350, Unit.PIXELS);

VerticalLayout body = new VerticalLayout();
body.setSizeFull();


As revealed in the code above, three layouts were used for this purpose — one horizontal and two vertical. Once the layouts are defined, we can add the components.

menu.addComponents(appTitle, selectDepartment, noOfEmployees, averageSalary);
body.addComponents(genderChart, salaryChart);
contents.addComponent(menu);
// Body fills the area to the right of the menu
contents.addComponentsAndExpand(body);
// Adds contents to the UI
setContent(contents);


Components appear in the UI in the order they are added. For a VerticalLayout, such as the menu, this means from top to bottom. Notice how the HorizontalLayout contents hold the two VerticalLayout s, placing them next to each other. This is necessary because the UI itself can hold only one component, namely contents which holds all components as one unit.

Reflecting the DataModel in the UI

Now that all visuals are in place, it is time to let them reflect the database content. This means we need to add values to the components by retrieving information from the DataModel. Bridging between our data model and EmployeeUI will be done by handling events from the selectDepartment. This is accomplished by adding a selection listener as follows in init():

selectDepartment.addSelectionListener(e ->
    updateUI(e.getSelectedItem().orElseThrow())
);


Since updateUI() was not yet defined, that is our next task.

private void updateUI(Departments dept) { }


Here is a quick reminder of what we want updateUI() to accomplish. When a new department is selected, we want to calculate and display the total number of employees, the number of males and females, the total average salary, and the salary distribution for males and females for that department.

Conveniently enough, we designed our DataModel with this in mind, making it easy to collect the information from the database.

We start with the values of the text fields:

final Map<Employees.Gender, Long> counts = DataModel.countEmployees(dept);

noOfEmployees.setValue(String.format("%,d", counts.values().stream().mapToLong(l -> l).sum()));

averageSalary.setValue(String.format("$%,d", DataModel.averageSalary(dept).intValue()));


The sum of the males and females gives the total number of employees. averageSalary() returns a Double which is cast to an int. Both values are formatted as a String before being passed to the text fields.

We can also use the map counts to populate the first graph by retrieving the separate counts for male and female.

final List<DataSeriesItem> maleSalaries = new ArrayList<>();
final List<DataSeriesItem> femaleSalaries = new ArrayList<>();

DataModel.freqAggregation(dept)
   .streamAndClose()
   .forEach(agg -> {
       (agg.getGender() == Gender.F ? femaleSalaries : maleSalaries)
           .add(new DataSeriesItem(agg.getInterval() * 1_000, agg.getFrequency()));
   });


Our DataModel provides an Aggregation that we can think of as a list containing tuples of a gender, a salary, and a corresponding salary frequency (how many persons share that salary). By streaming over the Aggregation, we can separate male and female data in two Lists containing DataSeriesItems. A DataSeriesItem is in this case used like a point with an x- and y-value.

Comparator<DataSeriesItem> comparator = Comparator.comparingDouble((DataSeriesItem dsi) -> dsi.getX().doubleValue());

maleSalaries.sort(comparator);
femaleSalaries.sort(comparator);


Before adding the data to the chart, we sort it in rising order of the x-values. Otherwise, the graph will look very chaotic. Now, our two sorted List<DataSeriesItem> will fit perfectly with the DataSeries of salaryChart.

//Updates salaryChart
maleSalaryData.setData(maleSalaries);
femaleSalaryData.setData(femaleSalaries);
salaryChart.drawChart();


Since we are changing the whole data set rather than just a single point, we set the data for our DataSeries to the Lists of x and y's we just created. Unlike a change in a ListSeries, this will not trigger an update of the chart, meaning we have to force a manual update with drawChart().

Lastly, we need to fill the components with default values when the application starts. This can now be done by calling updateUI(defaultDept) at the end of init().

Styling in Java

Vaadin offers complete freedom when it comes to adding a personal feel to components. Since this is a pure Java application, only the styling options available in their Java framework were used, although CSS styling will naturally give total control of the visuals.

To give our charts a personal touch, we created a class ChartTheme that extends Theme. In the constructor, we defined what properties we would like to change, namely the color of the data series, background, legend, and text.

public class ChartTheme extends Theme {
   public ChartTheme() {
       Color[] colors = new Color[2];
       colors[0] = new SolidColor("#5abf95"); // Light green
       colors[1] = new SolidColor("#fce390"); // Yellow
       setColors(colors);

       getChart().setBackgroundColor(new SolidColor("#3C474C"));
       getLegend().setBackgroundColor(new SolidColor("#ffffff"));

       Style textStyle = new Style();
       textStyle.setColor(new SolidColor("#ffffff")); // White text
       setTitle(textStyle);
   }
}


Then, the theme was applied to all charts by adding this row to init():

ChartOptions.get().setTheme(new ChartTheme());


Conclusion

We have used Speedment to interface the database and Vaadin to interface the end user. The only code needed in between is just a few Java Streams constructs that declaratively describe the application logic, which grants minimal time to market and cost of maintenance.

Feel free to fork this repo from GitHub and start experimenting on your own.

Get the open source Atomist Software Delivery Machine and start automating your delivery right there on your own laptop, today!

Topics:
vaadin framework 8 ,speedment ,java ,java 8 ,ui ,stream ,tutorial

Published at DZone with permission of

Opinions expressed by DZone contributors are their own.

{{ parent.title || parent.header.title}}

{{ parent.tldr }}

{{ parent.urlSource.name }}
