Developing a Custom Gradle Plugin

Gradle allows you to implement your own plugins in any languages like Java, Groovy, or Kotlin, so you can reuse your build logic, and share it with others, which can be used across many different projects and builds.

In our example, we are going to use Kotlin as the implementation language for a standalone plugin project and Kotlin in the build script plugin examples. In the following example, we will create a plugin with two tasks: task with command-line option and task with extension.

Plugin Setup

Setup build.gradle.kts

Let's create a plugin as a  standalone project so that we can publish it and share it with others, which we are going to package and publish a plugin is to use the Java Gradle Plugin Development Plugin.  It's a is simply a Java project that produces a JAR containing the plugin classes, it's will automatically apply the Java Plugin, add the gradleApi() dependency to the implementation configuration, generate the required plugin descriptors in the resulting JAR file, and configure the Plugin Marker Artifact to be used when publishing.

Here is a simple build script for the project build.gradle.kts:

xxxxxxxxxx

plugins {

    `kotlin-dsl`

    `java-gradle-plugin`

}

group = "com.example"

version = "1.0.0"

repositories {

    mavenCentral()

}

dependencies {

    implementation(kotlin("stdlib-jdk8"))

    compileOnly(gradleApi())

    testImplementation("junit:junit:4.13")

}

tasks {

    compileKotlin {

        kotlinOptions.jvmTarget = "1.8"

    }

    compileTestKotlin {

        kotlinOptions.jvmTarget = "1.8"

    }

}

gradlePlugin {

    (plugins) {

        register("my_plugin") {

            id = "com.example.my_plugin"

            implementationClass = "com.example.MyPlugin"

        }

    }

}

Plugin

To create a Gradle plugin, you need to write a class that implements the Plugin interface. When the plugin is applied to a project, Gradle creates an instance of the plugin class and calls the instance’s Plugin.apply() method.  Handling user input from the script we will do through an extension and command option.

xxxxxxxxxx

package com.example

import org.gradle.api.Plugin

import org.gradle.api.Project

class MyPlugin : Plugin<Project> {

    override fun apply(project: Project) {

        project.extensions.create("greeting", MyExtension::class.java)

        val task = project.tasks.create("hello", MyTask::class.java)

        task.group = "welcome"

    }

}

Create src/resource/META-INF/plugin.properties  file and set reference to your plugin class:

xxxxxxxxxx

implementation-class=com.example.MyPlugin

Extension

For using extension the Gradle Project has an associated ExtensionContainer object that contains all the settings and properties for the plugins that have been applied to the project. You can provide a configuration for your plugin by adding an extension object to this container.  An extension object is simply an object with Java Bean properties that represent the configuration.

xxxxxxxxxx

package com.example

open class MyExtension {

    var message: String? = null

}

Task

Task classes from the Gradle API can be used in specific circumstances, extending DefaultTask is the most common scenario. Annotate the default task action as @TaskAction.

xxxxxxxxxx

package com.example

import org.gradle.api.DefaultTask

import org.gradle.api.tasks.Input

import org.gradle.api.tasks.TaskAction

import org.gradle.api.tasks.options.Option

open class MyTask : DefaultTask() {

    @Input

    @Optional

    @Option(description = "Message from command line", option = "message")

    var message: String? = null

    @TaskAction

    fun run() {

        val extension = project.extensions.findByName("greeting") as MyExtension

        extension.message?.let {

            println("Hello from extension ${extension.message}")

        }

        message?.let {

            println("Hello from command line $message")

        }

    }

}

Test

You can use the ProjectBuilder class to create Project instances to use when you test your plugin implementation.

xxxxxxxxxx

package com.example

import org.gradle.api.Project

import org.gradle.testfixtures.ProjectBuilder

import org.junit.Assert.*

import org.junit.Test

class MyPluginTest {

    @Test

    fun test() {

        val pluginProject: Project = ProjectBuilder.builder().build()

        pluginProject.pluginManager.apply("com.example.my_plugin")

        val task = pluginProject.tasks.findByName("hello")

        assertNotNull(task)

        assertTrue(task is MyTask)

        assertEquals("welcome", task!!.group)

    }

}

Plugin publishing

Register in Gradle Plugin Portal. See more: publishing tutorial

Add the Plugin Publishing Plugin to the project

Add plugin from plugin-publishing (use the latest version):

xxxxxxxxxx

plugins {

    ...

    id("com.gradle.plugin-publish") version "0.12.0"

}

Configure the Plugin Publishing Plugin

Create a pluginBundle block in build.gradle.kts and specify global information regarding your plugin. This helps other people browsing the portal find more information about your plugin and learn how to contribute to its development.

xxxxxxxxxx

pluginBundle {

    website = "https://your_project_web_site"

    vcsUrl = "https://your_project_source"

    tags = listOf("hello", "greeting")

}

Publish your plugin

Run validate plugin command:

./gradlew validatePlugins

Run publishing, if you're not authorized use login command:

./gradlew publishPlugins

Usage

Apply your plugin to project:

xxxxxxxxxx

plugins {

     ...

    id "com.example.my_plugin" version "1.0.0"

}

Output of gradle hello --message = "My Gradle Plugin"

xxxxxxxxxx

> Task :hello

Hello from command line My Gradle plugin

Add extension in your build.gradle:

xxxxxxxxxx

greeting {

    message = "My Gradle plugin"

}

Output of  gradle hello:

xxxxxxxxxx

> Task :hello

Hello from extension My Gradle plugin
