Grid Column Behavior: Xamarin XAML vs Micorsoft XAML

DZone's Guide to

Grid Column Behavior: Xamarin XAML vs Micorsoft XAML

· Mobile Zone
Free Resource

Get gorgeous, multi-touch charts for your iOS application with just a few lines of code.

There’s a small detail difference in how rows and columns in a Grid behave in Xamarin Forms vs Microsoft XAML. A small difference but with quite a big impact. Look at the following XAML snippet (Microsoft XAML):

    <Grid Background="Red">
        <Grid.RowDefinitions>
            <RowDefinition Height="50" />
            <RowDefinition Height="*" />
        </Grid.RowDefinitions>

        <Grid Grid.Row="1" Background="Blue">
            <Grid.RowDefinitions>
                <RowDefinition Height="Auto" />
                <RowDefinition Height="300" />
            </Grid.RowDefinitions>
        </Grid>
    </Grid>


At runtime this looks like:


Exactly what we as seasoned XAML developers would expect.

Converted to Xamarin Forms XAML this turns into:

    <Grid BackgroundColor="Red">
      <Grid.RowDefinitions>
        <RowDefinition Height="50" />
        <RowDefinition Height="*" />
      </Grid.RowDefinitions>

      <Grid Grid.Row="1" BackgroundColor="Blue">
        <Grid.RowDefinitions>
          <RowDefinition Height="Auto" />
          <RowDefinition Height="300" />
        </Grid.RowDefinitions>
      </Grid>
    </Grid>


Only difference is the property name to set the background color. However, if we look at this at runtime we see a completely different story.


It looks like the inner Grid isn’t rendered at all. But let’s try to add a Label to the inner Grid.

    <Grid BackgroundColor="Red">
      <Grid.RowDefinitions>
        <RowDefinition Height="50" />
        <RowDefinition Height="*" />
      </Grid.RowDefinitions>

      <Grid Grid.Row="1" BackgroundColor="Blue">
        <Grid.RowDefinitions>
          <RowDefinition Height="Auto" />
          <RowDefinition Height="300" />
        </Grid.RowDefinitions>
        <Label Text="Hello Xamarin!" />
      </Grid>
    </Grid>


So what exactly is going on here? The inner Grid (the blue one) doesn’t specify any columns, that means that by default there’s only one column available. In Microsoft XAML the width of that default column is set to “*” so it takes up all available space. In Xamarin Forms that width is set to “Auto” so it only takes up the space it needs. A subtle difference with a big impact.

To fix this, add a column with “*” as width:

    <Grid BackgroundColor="Red">
      <Grid.RowDefinitions>
        <RowDefinition Height="50" />
        <RowDefinition Height="*" />
      </Grid.RowDefinitions>
      <Grid.ColumnDefinitions>
        <ColumnDefinition Width="*" />
      </Grid.ColumnDefinitions>

      <Grid Grid.Row="1" BackgroundColor="Blue">
        <Grid.RowDefinitions>
          <RowDefinition Height="Auto" />
          <RowDefinition Height="300" />
        </Grid.RowDefinitions>

      </Grid>
    </Grid>


Result:


Conclusion

In this post I’ve shown a difference in implementation between Xamarin Forms XAML and Microsoft XAML and how to fix it.

Note that this sample is based on Xamarin Forms 1.2. Xamarin has stated that they will change the implementation in Forms 1.3 to reflect the Microsoft implementation.
