How to Get Hadoop Up and Running

If you don’t want to have dedicated hardware for quick setup and research, a virtual machine would be the right choice.

Setup Virtual Machine

Step 1: Download Virtual Machine Player

You can download VM Player for free from here.

Go ahead and install on your host OS.

Step 2: Download Virtual Machine

You can download legal CentOs6 image from here.

You can even download Cloudera Quick Start VM, tailored for big data needs.

After downloading, extract it to a suitable place in your host OS.

Step 3: Start Virtual Machine

Click on “Open Virtual Machine”

Select the one you have already extracted

Click on “Play virtual Machine”

You may have to help VM Player, when prompted hit “I copied it”

Login with password “tomtom”

Successful login would show the desktop screen

Setup Java

Step 1: Make sure CentOS system is fully up-to-date

Become super user and run yum update

[tom@localhost ~]$ su
Password:
[root@localhost tom]# yum update

Step 2: Install JDK

[root@localhost tom]# yum search java | grep -i --color 'JDK'

In windows it is one click install process

[root@localhost tom]# yum install java-1.7.0-openjdk-devel.x86_64
[root@localhost tom]# javac -version
javac 1.7.0_55

In CentOS6, JDK gets installed under the following folder

[root@localhost java-1.7.0-openjdk-1.7.0.55.x86_64]# ll /usr/lib/jvm
total 4
lrwxrwxrwx. 1 root root 26 Jun 20 10:29 java -> /etc/alternatives/java_sdk
lrwxrwxrwx. 1 root root 32 Jun 20 10:29 java-1.7.0 -> /etc/alternatives/java_sdk_1.7.0
drwxr-xr-x. 7 root root 4096 Jun 20 10:29 java-1.7.0-openjdk-1.7.0.55.x86_64
lrwxrwxrwx. 1 root root 34 Jun 20 10:29 java-1.7.0-openjdk.x86_64 -> java-1.7.0-openjdk-1.7.0.55.x86_64
lrwxrwxrwx. 1 root root 34 Jun 20 10:29 java-openjdk -> /etc/alternatives/java_sdk_openjdk
lrwxrwxrwx. 1 root root 21 Jun 20 10:29 jre -> /etc/alternatives/jre
lrwxrwxrwx. 1 root root 27 Jun 20 10:29 jre-1.7.0 -> /etc/alternatives/jre_1.7.0
lrwxrwxrwx. 1 root root 38 Jun 20 10:29 jre-1.7.0-openjdk.x86_64 -> java-1.7.0-openjdk-1.7.0.55.x86_64/jre
lrwxrwxrwx. 1 root root 29 Jun 20 10:29 jre-openjdk -> /etc/alternatives/jre_openjdk
<pre>

Setup Hadoop

Step 3: Create new user to run hadoop

[root@localhost ~]# useradd hadoop
[root@localhost ~]# passwd hadoop
Changing password for user hadoop.
New password:
Retype new password:
passwd: all authentication tokens updated successfully.
[root@localhost ~]#

Step 4: Download Hadoop

[tom@localhost ~]$ su hadoop
Password:
[hadoop@localhost ~]$

[hadoop@localhost Downloads]$ wget 'http://apache.arvixe.com/hadoop/common/hadoop-2.2.0/hadoop-2.2.0.tar.gz'
[hadoop@localhost Downloads]$ tar -xvf hadoop-2.2.0.tar.gz

For now we can place hadoop under /usr/share/hadoop folder

</pre>
[root@localhost Downloads]# mkdir /usr/share/hadoop
[root@localhost Downloads]# mv hadoop-2.2.0 /usr/share/hadoop/2.2.0
<pre>

Step 5: Change Ownership

[root@localhost Downloads]# cd /usr/share/hadoop/2.2.0/
[root@localhost share]# chown -R hadoop hadoop
[root@localhost share]# chgrp -R hadoop hadoop

Step 6: Update Environment Variables

[hadoop@localhost ~]$ vi ~/.bash_profile
JAVA_HOME=/usr/lib/jvm/java-1.7.0-openjdk-1.7.0.55.x86_64
HADOOP_HOME=/usr/share/hadoop/2.2.0

export JAVA_HOME
export HADOOP_HOME
export HADOOP_MAPRED_HOME=${HADOOP_HOME}
export HADOOP_COMMON_HOME=${HADOOP_HOME}
export HADOOP_HDFS_HOME=${HADOOP_HOME}
export YARN_HOME=${HADOOP_HOME}
PATH=$PATH:$HOME/bin:$JAVA_HOME/bin:$HADOOP_HOME/bin:$HADOOP_HOME/sbin

export PATH

Things are all easy in Windows

[hadoop@localhost Downloads]$ source ~/.bash_profile

[hadoop@localhost ~]$ vi /usr/share/hadoop/2.2.0/etc/hadoop/hadoop-env.sh
# The java implementation to use.
#export JAVA_HOME=${JAVA_HOME}
export JAVA_HOME=/usr/lib/jvm/java-1.7.0-openjdk-1.7.0.55.x86_64
export HADOOP_COMMON_LIB_NATIVE_DIR=$HADOOP_HOME/lib/native
export HADOOP_OPTS="-Djava.library.path=$HADOOP_HOME/lib"

Step 7: Test Hadoop

[hadoop@localhost Downloads]$ hadoop version
Hadoop 2.2.0
Subversion https://svn.apache.org/repos/asf/hadoop/common -r 1529768
Compiled by hortonmu on 2013-10-07T06:28Z
Compiled with protoc 2.5.0
From source with checksum 79e53ce7994d1628b240f09af91e1af4
This command was run using /usr/share/hadoop/2.2.0/share/hadoop/common/hadoop-common-2.2.0.jar

Step 8: Fix SSH Issues

If you are getting SSH related issues while starting dfs (name node,data node or yarn), it could be that SSH is not installed or running.

Issue#1:

<h4></h4>
<h4>[hadoop@localhost ~]$ start-dfs.sh</h4>
VM: ssh: Could not resolve hostname VM: Name or service not known

Issue#2:

<h5>[hadoop@localhost Downloads]$ ssh localhost</h5>
ssh: connect to host localhost port 22: Connection refused

Solution

Install SSH server/client

[root@localhost Downloads]$ yum -y install openssh-server openssh-clients

Enable SSH

[root@localhost Downloads] chkconfig sshd on
[root@localhost Downloads] service sshd start
Generating SSH1 RSA host key: [ OK ]
Generating SSH2 RSA host key: [ OK ]
Generating SSH2 DSA host key: [ OK ]
Starting sshd: [ OK ]

[root@localhost Downloads]#
Make sure port 22 is open
[root@localhost Downloads]# netstat -tulpn | grep :22
tcp 0 0 0.0.0.0:22 0.0.0.0:* LISTEN 8662/sshd
tcp 0 0 :::22 :::* LISTEN 8662/sshd

Create empty phrase SSH keys so that you don’t have to enter password manually, while hadoop works

[hadoop@localhost ~]$ ssh-keygen -t dsa -P '' -f ~/.ssh/id_dsa
Generating public/private dsa key pair.
Your identification has been saved in /home/hadoop/.ssh/id_dsa.
Your public key has been saved in /home/hadoop/.ssh/id_dsa.pub.
The key fingerprint is:
08:d6:c1:66:2c:c8:c5:7b:96:d8:cb:fc:8d:19:16:38 hadoop@localhost.localdomain
The key's randomart image is:
+--[ DSA 1024]----+
| . +.o. |
| o o.=. |
| oB.o |
| .o.E.. |
| =.oS. |
| + o |
| o = |
| + . |
| |
+-----------------+

[hadoop@localhost ~]$ cat ~/.ssh/id_dsa.pub >> ~/.ssh/authorized_keys
[hadoop@localhost ~]$ chmod 644 ~/.ssh/authorized_keys
[hadoop@localhost ~]$

Verify that doing SSH does not prompt for password

[hadoop@localhost ~]$ ssh localhost
Last login: Fri Jun 20 15:08:09 2014 from localhost.localdomain
[hadoop@localhost ~]$

Start all Components

[hadoop@localhost Desktop]$ start-all.sh
[hadoop@localhost Desktop]$ jps
3542 NodeManager
3447 ResourceManager
3576 Jps

Hadoop Cluster

HDFS

Running Hadoop in Pseudo-Distributed mode

Step 1: Update core-site.xml

Add the following to core-site.xml

[hadoop@localhost ~]$ vi $HADOOP_HOME/etc/hadoop/core-site.xml

<configuration>
<property>
<name>fs.default.name</name>
<value>hdfs://localhost:9000</value>
<final>true</final>
</property>
</configuration>

Step 2: Update hdfs-site.xml

Add the following to hdfs-site.xml

[hadoop@localhost ~]$ vi $HADOOP_HOME/etc/hadoop/hdfs-site.xml

<configuration>
<property>
<name>dfs.namenode.name.dir</name>
<value>file:/home/hadoop/dfs/name</value>
<final>true</final>
</property>

<property>
<name>dfs.datanode.data.dir</name>
<value>file:/home/hadoop/dfs/data</value>
<final>true</final>
</property>

<property>
<name>dfs.permissions</name>
<value>false</value>
</property>
</configuration>
<pre>

Step 3: Update mapred-site.xml

Add the following to mapred-site.xml

</pre>
[hadoop@localhost ~]$ vi $HADOOP_HOME/etc/hadoop/mapred-site.xml

<configuration>
<property>
<name>mapreduce.framework.name</name>
<value>yarn</value>
</property>
<property>
<name>mapred.system.dir</name>
<value>file:/home/hadoop/mapred/system</value>
<final>true</final>
</property>
<property>
<name>mapred.local.dir</name>
<value>file:/home/hadoop/mapred/local</value>
<final>true</final>
</property>
<property>
<name>mapred.job.tracker</name>
<value>localhost:8021</value>
</property>
</configuration>

Step 3: Update yarn-site.xml

Add the following to yarn-site.xml

[hadoop@localhost ~]$ vi $HADOOP_HOME/etc/hadoop/yarn-site.xml

<configuration>
<!-- Site specific YARN configuration properties -->
<property>
<name>yarn.nodemanager.aux-services</name>
<value>mapreduce_shuffle</value>
</property>
<property>
<name>yarn.resourcemanager.address</name>
<value>localhost:8032</value>
</property>
<property>
<name>yarn.nodemanager.aux-services.mapreduce.shuffle.class</name>
<value>org.apache.hadoop.mapred.ShuffleHandler</value>
</property>
</configuration>

Step 4: Name node format

[hadoop@localhost ~]$ hdfs namenode -format
14/06/20 21:19:34 INFO namenode.NameNode: STARTUP_MSG:
/************************************************************
STARTUP_MSG: Starting NameNode
STARTUP_MSG: host = localhost.localdomain/127.0.0.1
STARTUP_MSG: args = [-format]
STARTUP_MSG: version = 2.2.0
STARTUP_MSG: classpath = /usr/share/hadoop/2.2.0/etc/hadoop:/usr/share/hadoop/2.2.0/share/hadoop/common/lib/mockito-all-1.8.5.jar:/usr/share/hadoop/2.2.0/share/hadoop/common/lib/hadoop-auth-2.2.0.jar *****
STARTUP_MSG: build = https://svn.apache.org/repos/asf/hadoop/common -r 1529768; compiled by 'hortonmu' on 2013-10-07T06:28Z
STARTUP_MSG: java = 1.7.0_55
************************************************************/
14/06/20 21:19:34 INFO namenode.NameNode: registered UNIX signal handlers for [TERM, HUP, INT]
14/06/20 21:19:35 WARN util.NativeCodeLoader: Unable to load native-hadoop library for your platform... using builtin-java classes where applicable
Formatting using clusterid: CID-d9351768-346c-43e4-b0f2-5a182a12ec4a
14/06/20 21:19:36 INFO namenode.HostFileManager: read includes:
HostSet(
)
14/06/20 21:19:36 INFO namenode.HostFileManager: read excludes:
HostSet(
)
14/06/20 21:19:36 INFO blockmanagement.DatanodeManager: dfs.block.invalidate.limit=1000
14/06/20 21:19:36 INFO util.GSet: Computing capacity for map BlocksMap
14/06/20 21:19:36 INFO util.GSet: VM type = 64-bit
14/06/20 21:19:36 INFO util.GSet: 2.0% max memory = 966.7 MB
14/06/20 21:19:36 INFO util.GSet: capacity = 2^21 = 2097152 entries
14/06/20 21:19:36 INFO blockmanagement.BlockManager: dfs.block.access.token.enable=false
14/06/20 21:19:36 INFO blockmanagement.BlockManager: defaultReplication = 3
14/06/20 21:19:36 INFO blockmanagement.BlockManager: maxReplication = 512
14/06/20 21:19:36 INFO blockmanagement.BlockManager: minReplication = 1
14/06/20 21:19:36 INFO blockmanagement.BlockManager: maxReplicationStreams = 2
14/06/20 21:19:36 INFO blockmanagement.BlockManager: shouldCheckForEnoughRacks = false
14/06/20 21:19:36 INFO blockmanagement.BlockManager: replicationRecheckInterval = 3000
14/06/20 21:19:36 INFO blockmanagement.BlockManager: encryptDataTransfer = false
14/06/20 21:19:36 INFO namenode.FSNamesystem: fsOwner = hadoop (auth:SIMPLE)
14/06/20 21:19:36 INFO namenode.FSNamesystem: supergroup = supergroup
14/06/20 21:19:36 INFO namenode.FSNamesystem: isPermissionEnabled = false
14/06/20 21:19:36 INFO namenode.FSNamesystem: HA Enabled: false
14/06/20 21:19:36 INFO namenode.FSNamesystem: Append Enabled: true
14/06/20 21:19:36 INFO util.GSet: Computing capacity for map INodeMap
14/06/20 21:19:36 INFO util.GSet: VM type = 64-bit
14/06/20 21:19:36 INFO util.GSet: 1.0% max memory = 966.7 MB
14/06/20 21:19:36 INFO util.GSet: capacity = 2^20 = 1048576 entries
14/06/20 21:19:36 INFO namenode.NameNode: Caching file names occuring more than 10 times
14/06/20 21:19:36 INFO namenode.FSNamesystem: dfs.namenode.safemode.threshold-pct = 0.9990000128746033
14/06/20 21:19:36 INFO namenode.FSNamesystem: dfs.namenode.safemode.min.datanodes = 0
14/06/20 21:19:36 INFO namenode.FSNamesystem: dfs.namenode.safemode.extension = 30000
14/06/20 21:19:36 INFO namenode.FSNamesystem: Retry cache on namenode is enabled
14/06/20 21:19:36 INFO namenode.FSNamesystem: Retry cache will use 0.03 of total heap and retry cache entry expiry time is 600000 millis
14/06/20 21:19:36 INFO util.GSet: Computing capacity for map Namenode Retry Cache
14/06/20 21:19:36 INFO util.GSet: VM type = 64-bit
14/06/20 21:19:36 INFO util.GSet: 0.029999999329447746% max memory = 966.7 MB
14/06/20 21:19:36 INFO util.GSet: capacity = 2^15 = 32768 entries
14/06/20 21:19:37 INFO common.Storage: Storage directory /home/hadoop/dfs/name has been successfully formatted.
14/06/20 21:19:37 INFO namenode.FSImage: Saving image file /home/hadoop/dfs/name/current/fsimage.ckpt_0000000000000000000 using no compression
14/06/20 21:19:37 INFO namenode.FSImage: Image file /home/hadoop/dfs/name/current/fsimage.ckpt_0000000000000000000 of size 198 bytes saved in 0 seconds.
14/06/20 21:19:37 INFO namenode.NNStorageRetentionManager: Going to retain 1 images with txid >= 0
14/06/20 21:19:37 INFO util.ExitUtil: Exiting with status 0
14/06/20 21:19:37 INFO namenode.NameNode: SHUTDOWN_MSG:
/************************************************************
SHUTDOWN_MSG: Shutting down NameNode at localhost.localdomain/127.0.0.1
************************************************************/

[hadoop@localhost ~]$
Step 5: Start Hadoop components
[hadoop@localhost ~]$ start-all.sh
This script is Deprecated. Instead use start-dfs.sh and start-yarn.sh
14/06/20 21:22:54 WARN util.NativeCodeLoader: Unable to load native-hadoop library for your platform... using builtin-java classes where applicable
Starting namenodes on [localhost]
localhost: starting namenode, logging to /usr/share/hadoop/2.2.0/logs/hadoop-hadoop-namenode-localhost.localdomain.out
localhost: starting datanode, logging to /usr/share/hadoop/2.2.0/logs/hadoop-hadoop-datanode-localhost.localdomain.out
Starting secondary namenodes [0.0.0.0]
0.0.0.0: starting secondarynamenode, logging to /usr/share/hadoop/2.2.0/logs/hadoop-hadoop-secondarynamenode-localhost.localdomain.out
14/06/20 21:23:26 WARN util.NativeCodeLoader: Unable to load native-hadoop library for your platform... using builtin-java classes where applicable
starting yarn daemons
resourcemanager running as process 3447. Stop it first.
localhost: nodemanager running as process 3542. Stop it first.

[hadoop@localhost ~]$ jps
3542 NodeManager
5113 DataNode
5481 Jps
5286 SecondaryNameNode
5016 NameNode
3447 ResourceManager

Step 5: Stop Hadoop components

[hadoop@localhost ~]$ stop-all.sh
This script is Deprecated. Instead use stop-dfs.sh and stop-yarn.sh
14/06/20 21:27:55 WARN util.NativeCodeLoader: Unable to load native-hadoop library for your platform... using builtin-java classes where applicable
Stopping namenodes on [localhost]
localhost: stopping namenode
localhost: stopping datanode
Stopping secondary namenodes [0.0.0.0]
0.0.0.0: stopping secondarynamenode
14/06/20 21:28:18 WARN util.NativeCodeLoader: Unable to load native-hadoop library for your platform... using builtin-java classes where applicable
stopping yarn daemons
stopping resourcemanager
localhost: stopping nodemanager
no proxyserver to stop

Windows Issues

Issue #1: JAVA_HOME related issue

Solution : set it differently

Issue #2: Failed to locate winutils binary

Solution : Download this and copy hadoop-common-2.2.0/bin folder and paste them to HADOOP_HOME/bin folder. Alternatively you can build hadoop for your own environment as described here.

Issue #3: “The system cannot find the batch label specified”

Solution :Download unix2dos from here and run on all the hadoop batch files.
