How to Handle a Variable Number of Parameters in Apache JMeter

DZone's Guide to

How to Handle a Variable Number of Parameters in Apache JMeter

Effectively dealing with parameters and requests is a key part of creating a high-performing application. Read on to learn how to use JMeter to handles params.

Free Resource

If your request has a lot of parameters which are being passed to HTTP, creating a request to manually correlate the data will be a cumbersome process, where we can use scripting capabilities using any of the preprocessors.

I have got almost 484 parameters which have to be correlated, as shown below.

Image title

Capture all the param names and param values using a regular expression extractor and dynamically send the argument with a “key,Value” pair using Sampler with the predefined variable, as shown below:

paramname = <input type=”hidden” name=”(.+?)” value=”[a-z|0-9]+”

paramvalue = value=”([a-z|0-9]+)”

The string which is enclosed in parenthesis () will get stored in a reference name.

In order to capture all the match occurrences, we will use Match, now attributed as “-1,” as below.

Steps:

1. Capture all the param names and param values parameters as above by using a regular expression extractor.

2. Based on the param count we can construct the dynamic parameters using a preprocessor.

3. Add a JSR223 Preprocessor to the HTTP request as below, and delete the parameters from the HTTP request.

The JSR223 PreProcessor allows JSR223 script code to be applied before taking a sample.

The following JSR223 variables are set up for use by the script:

  • log – (Logger) – can be used to write to the log file.
  • Label – the String Label.
  • FileName – the script file name (if any).
  • Parameters – the parameters (as a String).
  • args – the parameters as a String array (split on whitespace).
  • ctx – (JMeterContext) – gives access to the context.
  • vars – (JMeterVariables) – gives read/write access to variables:
    vars.get(key);
    vars.put(key,val);
    vars.putObject("OBJ1",new Object());
    vars.getObject("OBJ2");
  • props – (JMeterProperties – class java.util.Properties) – e.g. props.get(“START.HMS”);props.put(“PROP1″,”1234”);
  • sampler – (Sampler)- gives access to the current sampler.
  • OUT – System.out – e.g. OUT.println(“message”).

For details of all the methods available on each of the above variables, please check the Javadoc.

Using a sampler variable we can access the addArgument method, which passes a name and value, which can be constructed dynamically using the below code:

public void addArgument(String name,
                        String value)
//vars – (JMeterVariables) – gives read/write access to variables

//vars.get(“jmetervariable”) – gets the variable value which is in string format

int count=Integer.parseInt(vars.get(“paramname_matchNr”))

log.info “parameters count” + count

for(int i=1;i<=count;i++){

sampler.addArgument(vars.get(“paramname_” + i),vars.get(“paramvalue_” + i))
}

log.info “completed”

We can verify the request in view results tree as below.

Image titleThis way we can construct a dynamic number of requests using simple variables.

Topics:
jmeter ,performance ,http requests ,parameters

Published at DZone with permission of Manojkumar Tenali. See the original article here.

Opinions expressed by DZone contributors are their own.
