Implementing a Log Collector using JBoss Fuse and JBoss Data Grid

<dependency>
<groupId>org.apache.camel</groupId>
<artifactId>camel-stream</artifactId>
</dependency>

The log collector consists of a Camel Route that has the stream component as a file consumer with the scanStream flag set to true. Each line that is written to the file becomes a message.

<from uri="stream:file?fileName=/opt/jboss-datagrid-6.6/standalone/log/server.log&amp;scanStream=true"/>

The second step of the route is the line parsing. The Elastic Stack uses grok to do the parsing. For this stack, we will use a Java Bean Processor to match the line with a predefined JBoss EAP parser regex. The idea is to build plugins for each type of logs that we can just add to the solution like filters or post- or pre-processors. This is the code of my JBossEAPLogParser.java file:

package mx.redhat.demo.fuse;

import java.text.DateFormat;
import java.text.SimpleDateFormat;
import java.util.Date;
import java.util.HashMap;
import java.util.Map;
import java.util.regex.Matcher;
import java.util.regex.Pattern;

import org.apache.camel.Exchange;
import org.apache.camel.Processor;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;

public class JBossEAPLogParser implements Processor {
 private Logger log = LoggerFactory.getLogger(JBossEAPLogParser.class);
 private String pattern = "(?<time>.{12}+) (?<level>.{5}+) \\[(?<class>.+)\\] \\((?<thread>[^\\)]+)\\) (?<message>.+)";
 private Pattern compile = Pattern.compile(pattern);
 private String[] tokens = {
  "time",
  "level",
  "class",
  "thread",
  "message"
 };
 private DateFormat formatter = new SimpleDateFormat("yyyy-MM-dd'T'HH:mm:ss.SSSZ");

 @Override
 public void process(Exchange exchange) throws Exception {
   String payload = exchange.getIn().getBody(String.class);
   log.trace("Processingoad: %s", payload);
   Map < String, String > map = processMessage(payload);
   map.put("messageyload);
    map.put("@timestamprmatter.format(new Date()));
     exchange.getOut().setBody(map);
    }

    public Map < String, String > processMessage(String data) {
     Map < String, String > map = new HashMap < String, String > ();
     Matcher matcher = compile.matcher(data);
     if (matcher.find()) {
      for (String token: tokens) {
       String myNamedGroup = matcher.group(token);
       log.trace("Tokenroup: %s \n", token, myNamedGroup);
       map.put(token, matcher.group(token));
      }
     }
     return map;
    }
   }

The processing of the messages adds a timestamp and more context data such as log level, class, and thread. It can eventually add more options, such as hostname or server name.

The result of the previous step is a map that we now marshall using the Jackson library to produce the JSON object. Don’t forget to add the Maven dependency.

<dependency>
<groupId>org.apache.camel</groupId>
<artifactId>camel-jackson</artifactId>
</dependency>

This is how the route looks:

<route>
<from uri="stream:file?fileName=/opt/jboss-datagrid-6.6/standalone/log/server.log&amp;scanStream=true"/>
<bean beanType="mx.redhat.demo.fuse.JBossEAPLogParser"/>
<marshal>
<json library="Jackson"/>
</marshal>
<to uri="direct:infinispan"/>
</route>

The route then forwards the message to the infinispan route that will insert the payload as String in the data grid using the camel-jbossdatagrid component.

Storing the Logs

There are two main configurations for the data grid. You can use it in the Library mode, where the engine is embedded in the same JVM and the same heap is also used to store the data. The second option available is the Client-Server mode. It is built on top of JBoss EAP and, in this configuration, the engine and the data live on a separate JVM from the application JVM. Use this configuration to get a cluster that scales horizontally and independent from the route.

If you haven’t set up the JBoss Data Grid Server, you can follow the Red Hat Developers blog post.

Before starting the JBoss Data Grid Server cluster, it’s recommended to configure a specific cache to store the data logs. Enabling compatibility mode let us query the stored data using the REST API from any browser or REST client like curl.

To add the cache configuration, you need to edit the clustered.xml file located under the $JDG_HOME/standalone/configuration path.  Under the Infinispan subsystem, add the cache configuration lines after the default cache configuration.

<subsystem
xmlns="urn:infinispan:server:core:6.4" default-cache-container="clustered">
<cache-container name="clustered" default-cache="default" statistics="true">
    ...

<distributed-cache name="logs" mode="ASYNC" segments="20" owners="2" remote-timeout="30000" start="EAGER">
<locking acquire-timeout="30000" concurrency-level="1000" striping="false"/>
<transaction mode="NONE"/>
<compatibility enabled="true"/>
</distributed-cache>
        ...

</subsystem>

The above configuration enables an asynchronous distributed cache (you can check more about clustered modes here) named logs. You can check the specifics of the configuration in the official JBoss Data Grid documentation available on the Red Hat portal.

One of the most interesting features of the client-server mode that we're using is the embedded REST API to put and retrieve the stored data. It opens the possibility to use any client disregarding of the development language if that client supports HTTP communication. The data grid server also includes its own TCP binary client protocol to connect to the grid. It’s called Hot Rod and is the implementation used for the camel-datagrid component. When the compatibility flag is enabled, you can put and retrieve data seamlessly with either API.

To add the camel-jbossdatagrid component, you need to add the Maven dependency and specify the JBoss Data Grid version used.

<dependency>
<groupId>org.apache.camel</groupId>
<artifactId>camel-jbossdatagrid</artifactId>
<version>${jboss.datagrid.version}</version>
</dependency>

The use of the camel-jbossdatagrid component is quite easy. You only need to configure the key and value as message headers. Then, invoke the producer with the hostname:port of any node of the data grid cluster and the desired cache to store the data.

For this example, we will use the Camel message ID as the key and the message payload (as the string) for the value. The cache used is the previously configured logs cache.

 <route>
     <from uri="direct:infinispan"/>
     <setHeader headerName="CamelInfinispanKey">
         <simple>${id}</simple>
     </setHeader>
     <setHeader headerName="CamelInfinispanValue">
         <simple>${bodyAs(String)}</simple>
     </setHeader>
     <to uri="infinispan://localhost?cacheName=logs"/>
 </route>

With this second route, the project is ready to run and start collecting the data grid server logs.

Running the Project

The first thing to do is start the data grid cluster. From the command line, start the clustered version of the server specifying the ports and the node names so that there is no trouble running the cluster on the same machine.

Run node1 with port-offset=0:

$ ${JDG_HOME}/bin/clustered -Djboss.socket.binding.port-offset=0 -Djboss.node.name=node1

Run node2 with port-offset=1:

$ ${JDG_HOME}/bin/clustered -Djboss.socket.binding.port-offset=1 -Djboss.node.name=node2

Run node3 with port-offset=2:

$ ${JDG_HOME}/bin/clustered -Djboss.socket.binding.port-offset=2 -Djboss.node.name=node3

Note: Remember to open the UDP/TCP ports in your test machine so that the nodes are able to join the cluster.

After starting the data grid cluster, you can start the camel route using the camel-maven-plugin. Add the following lines to enable it under the plugins section. If you created the project from the Maven archetype, it will probably be already there. Don’t forget to specify the same version you’re using of Apache Camel.

<plugin>
<groupId>org.apache.camel</groupId>
<artifactId>camel-maven-plugin</artifactId>
<version>${camel.version}</version>
<configuration>
<fileApplicationContextUri>src/main/resources/META-INF/spring/camel-context.xml</fileApplicationContextUri>
</configuration>
</plugin>

This plugin enables the project to run the route as a simple Java application without the need to deploy the bundle to a Java container. In this way, you can run Apache Camel routes from the command line with this command:

$ mvn clean camel:run

The above command will start the Camel context and route to scan the data grid server log file line by line putting the parsed message in the data grid cache. If you check carefully the display log, you will notice that even though only the first node of the cluster is configured in the route, the Hot Rod protocol receives the cluster topology adding the other two nodes to the client pool.

...
INFO Refreshing org.springframework.context.support.FileSystemXmlApplicationContext@67692d1f: startup date [Tue Feb 28 13:19:23 CST 2017]; root of context hierarchy
INFO Loading XML bean definitions from file [/home/hguerrer/git/fuse-examples/logging-collector/src/main/resources/META-INF/spring/camel-context.xml]
INFO Pre-instantiating singletons in org.springframework.beans.factory.support.DefaultListableBeanFactory@2edb5eba: defining beans [template,consumerTemplate,camel-1:beanPostProcessor,camel-1]; root of factory hierarchy
INFO Apache Camel 2.17.0.redhat-630224 (CamelContext: camel-1) is starting
INFO JMX is enabled
INFO Loaded 183 type converters
INFO Runtime endpoint registry is in extended mode gathering usage statistics of all incoming and outgoing endpoints (cache limit: 1000)
INFO AllowUseOriginalMessage is enabled. If access to the original message is not needed, then its recommended to turn this option off as it may improve performance.
INFO StreamCaching is not in use. If using streams then its recommended to enable stream caching. See more details at http://camel.apache.org/stream-caching.html
INFO ISPN004006: localhost/127.0.0.1:11222 sent new topology view (id=4, age=0) containing 3 addresses: [/127.0.0.1:11222, /127.0.0.1:11223, /127.0.0.1:11224]
INFO ISPN004014: New server added(/127.0.0.1:11223), adding to the pool.
INFO ISPN004014: New server added(/127.0.0.1:11224), adding to the pool.
INFO ISPN004021: Infinispan version: 6.4.1.Final-redhat-1
INFO Route: route1 started and consuming from: Endpoint[stream://file?fileName=%2Fopt%2FNotBackedUp%2Fjboss-datagrid-6.6.0-server%2Fstandalone%2Flog%2Fserver.log&scanStream=true]
INFO Route: route2 started and consuming from: Endpoint[direct://infinispan]
INFO Total 2 routes, of which 2 are started.
INFO Apache Camel 2.17.0.redhat-630224 (CamelContext: camel-1) started in 1.259 seconds
INFO ISPN004006: /127.0.0.1:11223 sent new topology view (id=4, age=0) containing 3 addresses: [/127.0.0.1:11222, /127.0.0.1:11223, /127.0.0.1:11224]

Because the route uses the Stream component, it will keep running waiting for more input data from the specified file. If you want to stop the route just press CTRL + C.

The easiest way to check that everything ran fine and that the logs were collected is querying the data grid REST API. You only need to open the following URL on your browser or REST client.

http://localhost:8080/rest/logs/

Note: Don’t forget to create a user with the correct REST roles so you can authenticate with the server. Disabling security is not recommended.

You will get a list of the linked keys to the messages stored in the server. Depending on the log size it could take a while to load the page.

If you click on any of the links, you will be able to inspect the JSON data.

If you want to check more information of the data grid server, you can use the Java Monitoring and Management Console (JConsole) to inspect the exposed MBeans on any of the nodes. Statistics are enabled by default.

Some of the statistics you can browse are numberOfEntries and stores. The first refers to the number of entries in the cache and the latter refers to the total number of put operations. You can check other metrics exposed in the MBeans here. Each entry represents a parsed log message.

The data collected is kept in the data grid cluster rebalancing the entries automatically when a node goes down until all the nodes are taken down. You can configure the cache to store the memory content in a database of filesystem in case of a full cluster restart.

Next Steps

Even though it is not complete, you can check the versatility of the solutions to solve this simple task. On following posts, I will try to complete the full process adding the visualization tools needed to query and search the data stored in the grid. One way to go is using JBoss Data Virtualization to do a remote query on the grid and present the data using the included dashboard. The long way is to try the OData wrapper for JBoss Data Grid Library mode and create an OData provider for Dashbuilder. Stay tuned for the follow-up.

Summary

JBoss Fuse and JBoss Data Grid are two powerful products based on popular community projects that can be used to collect, parse, and store application logs. You can use your Apache Camel knowledge to increase the uses cases of the framework. The 160+ included JBoss Fuse components plus the blueprint/Spring DSL simplify the integration tasks with almost zero-code development.

If you want the full detail, you can check out the complete code developed before from my GitHub repo.
