Increase Max Open Files in Elastic Search (OSX)

DZone's Guide to

Increase Max Open Files in Elastic Search (OSX)

Jamie Craane provides insight into increasing the maximum open files within Elasticsearch.

· Integration Zone
Free Resource

Modernize your application architectures with microservices and APIs with best practices from this free virtual summit series. Brought to you in partnership with CA Technologies.

Elastic Search, Logstash and Kibana (ELK) is an end-to-end stack which provides real-time analytics for almost any type of structured or unstructured data.

When importing large amounts of data using Logstash to Elasticsearch (ES), the chances are that ES hit the limits of the maximum files it can open. This limit is seen as an error in the ES logs with the following description: (Too many open files)

To deal with this you can increase the maximum files ES (or any process) may open using the following steps:

1. First step: start ES with the following option: ./elasticsearch -Des.max-open-files. This will show the maximum number of files ES is allowed to open, for example: [2016-02-22 06:44:09,558][INFO ][bootstrap] max_open_files [10240]

2. Now execute the following commands to increase the maximum number of files a process may open:

sudo sysctl -w kern.maxfiles=32000

sudo sysctl -w kern.maxfilesperproc=32000

3. Execute the following commands to set the file limit for the terminal process (this is the terminal window to launch ES in)

ulimit -Sn 32000

ulimit -Hn 32000

For ES 1.7:Start Elastic Search with the following command: ./elasticsearch -Des.max-open-files -XX:-MaxFDLimit=true

For ES 2.2 Execute the following commands:

export ES_JAVA_OPTS=-XX:-MaxFDLimit (this increases the maximum files the JVM is allowed to open by default, see JVM configuration for more information)

and then start ES with the following command: ./elasticsearch -Des.max-open-files (max_open_files should be 32000 now)

Heap Sizes

You may also need to increase the heap size of both Logstash and Elastic Search.

To increase the heap of LogStash execute the following command before launching Logstash: export LS_HEAP_SIZE=2g

To increase the heap of Elastic Search execute the following command before launching ES: export ES_HEAP_SIZE=8g

When importing large files using Logstash, it may benefit to increase the number of workers to speed up the importing process. The default is 1. See the following example of the Elasticsearch output plugin in Logstash:

elasticsearch {
     action => "index"
     hosts => ["localhost"]
     index => "logstash-%{+YYYY.MM.dd}"
     workers => 4
     flush_size => 1000
}

The Integration Zone is proudly sponsored by CA Technologies. Learn from expert microservices and API presentations at the Modernizing Application Architectures Virtual Summit Series.

Topics:
elastisearch ,logstash ,kibana ,elk ,elk stack

Published at DZone with permission of Jamie Craane, DZone MVB. See the original article here.

Opinions expressed by DZone contributors are their own.
