Building an IoT AMQP Backend in Seconds With Rhiot

As AMQP, a message broker protocol used in IoT, becomes more widely-adopted, Rhiot may help you build them rapidly and efficiently.

· IoT Zone
Free Resource

Address your IoT software testing needs – improve quality, security, safety, and compliance across the development lifecycle.

The AMQP is becoming widely adopted as the protocol of choice the communication between an IoT gateway and a data center. If you would like to rapidly create the AMQP backend service that can be immediately ready for your gateways and devices, the Rhiot AMQP quickstart from the Rhiot project will be more than interesting for you.

The AMQP cloudlet quickstart can be used as a base for the fat-jar AMQP microservices (aka cloudlets). If you wanna create a simple backend application capable of exposing AMQP-endpoint and handling the AMQP-based communication, the AMQT cloudlet quickstart is the best way to start your development efforts.

Creating and running the AMQP cloudlet project

In order to create the AMQP cloudlet project execute the following commands:

git clone git@github.com:rhiot/quickstarts.git
cp -r quickstarts/cloudlets/amqp amqp
cd amqp
mvn install

To start the AMQP cloudlet execute the following command:

java -jar target/rhiot-cloudlets-amqp-1.0.0-SNAPSHOT.jar

That is really all you need to expose the AMQP message broker to the external devices and gateways.

You can also build and run it as a Docker image (we love Docker and highly recommend this approach):

TARGET_IMAGE=yourUsername/rhiot-cloudlets-amqp
mvn install docker:build docker:push -Ddocker.image.target=${TARGET_IMAGE}
docker run -it ${TARGET_IMAGE}

AMQP Broker

By default AMQP cloudlet quickstart starts embedded ActiveMQ AMQP broker on 5672 port. If you would like to connect your cloudlet application to the external ActiveMQ broker (instead of starting the embedded one), run the cloudlet with the BROKER_URL environment variable or system property, for example:

java -DBROKER_URL=tcp://amqbroker.example.com:61616 -jar target/rhiot-cloudlets-amqp-1.0.0-SNAPSHOT.jar

...or...

docker run -e BROKER_URL=tcp://amqbroker.example.com:61616 -it yourUsername/rhiot-cloudlets-amqp

Sample Chat Application

The AMQP cloudlet quickstart is in fact a simple chat application. Clients can send the messages to the chat channel by subscribing to the broker and sending the messages to the chat AMQP queue.

$ amqp-client -h localhost -p 5672 --topic chat "Hello, this is the IoT device!"

The clients can subscribe to the chat updates by listening on the chat-updates AMQP topic - whenever the new message has been sent to the chat channel, the clients registered to the chat-updates will receive the updated chat history.

$ amqp-client -h localhost -p 5672 --subscribe --topic chat-updates
Hello, this is the IoT device!
I just wanted to say hello!
Hello, IoT device. Nice to meet you!

The quickstart also exposes the simple REST API that can be used to read the chat history using the HTTP GET request:

$ curl http://localhost:8180/chat
Hello, this is the IoT device!
I just wanted to say hello!
Hello, IoT device. Nice to meet you!

Architectural Overview

When AMQP cloudlet is started with the embedded ActiveMQ broker, the architecture of the example is the following:


When you connect to the external ActiveMQ broker (using BROKER_URL option), the architecture of the example becomes more like the following diagram:

The Quickstart Code

You may be wondering how much code do you need in order to take the advantage of the presented AMQP functionality. Below is all code used by our quickstart to handle the AMQP connectivity:

import io.rhiot.steroids.camel.CamelBootstrap;

import java.util.LinkedList;
import java.util.List;

import static io.rhiot.steroids.activemq.EmbeddedActiveMqBrokerBootInitializer.amqpJmsBridge;
import static org.apache.commons.lang3.StringUtils.join;

public class ChatCloudlet extends CamelBootstrap {

    static final List chat = new LinkedList<>();

    @Override
    public void configure() throws Exception {
        from(amqpJmsBridge("chat")).process(
                exchange -> chat.add(exchange.getIn().getBody(String.class))
        ).process(
                exchange -> exchange.getIn().setBody(join(chat, "\n"))
        ).to(amqpJmsBridge("topic:chat-updates"));
    }

}

And below is the code used to start the REST API mentioned before:

import io.rhiot.steroids.camel.Route;
import org.apache.camel.builder.RouteBuilder;

import static org.apache.commons.lang3.StringUtils.join;

@Route
public class ChatRestApiRoutes extends RouteBuilder {

    @Override
    public void configure() throws Exception {
        restConfiguration().component("netty4-http").host("0.0.0.0").port(8180);

        rest("/chat").get().route().process(
                exchange -> exchange.getIn().setBody(join(ChatCloudlet.chat, "\n"))
        );
    }

}

As you can see, Apache Camel is the first class citizen in the Rhiot world. In order to make Camel connectivity easier, Rhiot comes with static DSL methods like  EmbeddedActiveMqBrokerBootInitializer.amqpJmsBridge which can be used to easily create Camel endpoints associated with a broker used by a quickstart.

Accelerate the delivery of high-quality software in the connected IoT era through an integrated analysis, testing, security, and analytics platform

Topics:
internet of things ,message broker ,amqp ,camel ,activemq
