jQuery Mobile Lesson 4

DZone's Guide to

jQuery Mobile Lesson 4

In this article, we'll cover using jQuery to develop a mobile app comprised of various data attributes and grid systems.

· Mobile Zone
Free Resource

In this section, we continue talking about using various data attributes, linking external pages, using grid systems, and building collapsible content. Also, we will tell how to make footers, headers, navbars, and so on. Everything is supported with code snippets.

External Pages

Our jQuery Mobile will also handle external pages as well. If you link to a separate page instead of to an ID of a data-role="page" element within the current document, jQuery Mobile will perform an asynchronous fetch of the requested page and integrate it into the current document, allowing it to perform its page management functions.

To add an external page to our previous example code, create a file called ‘expage.html’ and include the markup shown then change the link in markup of the third page
<p><a href="#page1" data-role="button">Go back to First Page</a></p>
to this one
<p><a href="expage.html" data-role="button">Go to external Page</a></p>

Example 22: Linking of an external page

<!DOCTYPE html>
<html>

<head>
    <meta charset="utf-8" /> </head>

<body>
    <p>This content will be ignored.</p>
    <!-- Begin Page 4 -->
    <section id="page4" data-role="page">
        <header data-role="header">
            <h1>jQuery Mobile</h1> </header>
        <div class="content" data-role="content">
            <p>External Page!</p>
            <p><a href="#page1" data-role="button">Go to First Page</a>.</p>
        </div>
        <footer data-role="footer">
            <h1>footer</h1> </footer>
    </section>
    <!-- End Page 4-->
    <h3>This content will be ignored as well.</h3> </body>

</html>

When you preview this script you will see the image to the left but when you navigate from the previous page of the previous script will see the image right.

Overriding Asynchronous Page Fetching

Sometimes you will want to actually load a page normally, rather than having jQuery Mobile fetch it asynchronously and integrate it into the current DOM. You can override the AJAX loading in two ways: specifying a target attribute on a link (such as "_blank") or by specifying a rel="external" attribute on the link.

Aligning Content with a Grid

A grid is just what it sounds like. It is a tool for placing objects to make them align. jQuery Mobile uses a grid system to help with content alignment. This system is useful as it helps to create a cross-device experience that takes the guesswork out of dealing with devices that have different dimensions than you originally planned for.
The grid system in jQuery Mobile allows you to create columns of equal width. To apply the grid system to your content you need to add a class to the container you want to use for the grid and a secondary class to the items inside the container.
Grid container classes are as follows:

  • ui-grid-a creates a two-column grid.
  • ui-grid-b creates a three-column grid.
  • ui-grid-c creates a four-column grid.
  • ui-grid-d creates a five-column grid.

Content classes are as follows:

  • ui-block-a is used on the first block.
  • ui-block-b is used on the second block.
  • ui-block-c is used on the third block.
  • ui-block-d is used on the fourth block.
  • ui-block-e is used on the fifth block.

When using a grid on a container that has elements with content that is wider than the available screen resolution, the content will be moved into a new row in the grid. This helps keep content organized and viewable.

Aligning Buttons and boxes of content on a Page Using a Grid

Example 23: Aligning content with a grid line

<!DOCTYPE html>
<html>

<head>
    <title>Script-Tutorials: Using a grid</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div id="page1" data-role="page">
        <div data-role="header">
            <h1>Using a grid</h1> </div>
        <div data-role="content">
            <div class="ui-grid-a">
                <div class="ui-block-a">
                    <p class="ui-bar ui-bar-b" style="height: 80px;"> This is first in the grid </p>
                </div>
                <div class="ui-block-b">
                    <p class="ui-bar ui-bar-b" style="height: 80px;"> This element is second in a grid </p>
                </div>
                <div class="ui-block-a">
                    <p class="ui-bar ui-bar-b" style="height: 80px;"> By reusing ui-block-a this wraps to a new row. </p>
                </div>
                <div class="ui-block-b">
                    <p class="ui-bar ui-bar-b" style="height: 80px;"> This is the final element in this grid </p>
                </div>
            </div>
            <div class="ui-grid-a">
                <div class="ui-block-a"> <a href="#" data-role="button">Link 1</a> </div>
                <div class="ui-block-b"> <a href="#" data-role="button">Link 2</a> </div>
            </div>
        </div>
        <div data-role="footer">
            <h4>Using a grid to align : jQuery mobile supports</h4> </div>
    </div>
</body>

</html>

Large devices still show content aligned in a grid; the content will just be stretched out to take advantage of the screen space.

Grids Layout

As we have illustrated in the above example, grid layouts are based on a div structure: create a div to contain the grid, and then add the cell divs inside.
Multiple rows are handled by adding more cell divs, which should be classed so that each column should have its own ui-block class.
The containing div is given a class ui-grid class: ui-grid-a for 2 columns, ui-grid-b for three columns, and so forth, all the way to ui-grid-d for 5 columns.
Cell divs are given ui-block classes based on their order: ui-block-a for the first, ui-block-b for the second, and so forth, all the way up to ui-block-e for the fifth.

Example 24: Grid layout in mobile site using jQuery mobile

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Grid layout with jQuery Mobile</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <section id="page1" data-role="page">
        <header data-role="header">
            <h1>jQuery Mobile</h1> </header>
        <div class="content" data-role="content">
            <h4>2 Colums</h4>
            <div class="ui-grid-b">
                <div class="ui-block-a">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION A</p>
                </div>
                <div class="ui-block-b">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION B</p>
                </div>
            </div>
            <h4>3 Columns</h4>
            <div class="ui-grid-b">
                <div class="ui-block-a">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION A</p>
                </div>
                <div class="ui-block-b">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION B</p>
                </div>
                <div class="ui-block-c">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION C</p>
                </div>
            </div>
            <h4>4 Columns</h4>
            <div class="ui-grid-c">
                <div class="ui-block-a">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION A</p>
                </div>
                <div class="ui-block-b">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION B</p>
                </div>
                <div class="ui-block-c">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION C</p>
                </div>
                <div class="ui-block-d">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION D</p>
                </div>
            </div>
            <h4>5 Columns</h4>
            <div class="ui-grid-d">
                <div class="ui-block-a">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION A</p>
                </div>
                <div class="ui-block-b">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION B</p>
                </div>
                <div class="ui-block-c">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION C</p>
                </div>
                <div class="ui-block-d">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION D</p>
                </div>
                <div class="ui-block-e">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION E</p>
                </div>
            </div>
            <h4>2 Rows of 3 Columns</h4>
            <div class="ui-grid-d">
                <div class="ui-block-a">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION A</p>
                </div>
                <div class="ui-block-b">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION B</p>
                </div>
                <div class="ui-block-c">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION C</p>
                </div>
                <div class="ui-block-a">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION A</p>
                </div>
                <div class="ui-block-b">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION B</p>
                </div>
                <div class="ui-block-c">
                    <p class="ui-bar ui-bar-b" style="height: 40px;">DIVISION C</p>
                </div>
            </div>
        </div>
        <footer data-role="footer">
            <h1>Alignment Grid-layou</h1> </footer>
    </section>
</body>

</html>

Building Collapsible Content

Collapsible content can be hidden or shown with a click or a touch. You probably have already seen this type of behavior on websites before. You may have seen it in the Frequently Asked Questions sections on multiple sites. Usually, on those sites, it is a question or an answer with the title viewable and then a little ‘+’ or ‘-’ next to it to show that it can be opened or closed. This same functionality is built into jQuery Mobile.
To create collapsible content, you just need to add data-role="collapsible" to the containing element that you want to make collapsible.

Example 25: Building a collapsible content

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Collapsible Content</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div id="page1" data-role="page">
        <div data-role="header">
            <h1>Collapsible Content</h1> </div>
        <div data-role="content">
            <div data-role="collapsible">
                <h3>I'm a single collapsible element</h3>
                <p>I'm the content inside of the single collapsible element.</p>
            </div>
            <div data-role="collapsible-set">
                <div data-role="collapsible" data-collapsed="false">
                    <h3>I'm expanded on page load</h3>
                    <p>I am collapsible content that is visible on page load.</p>
                    <p>That's because of the data-collapsed="false" attribute</p>
                </div>
                <div data-role="collapsible">
                    <h3>Expand me I have something to say</h3>
                    <p>I am closed on page load, but still part of an accordion.</p>
                    <div data-role="collapsible">
                        <h3>Wait, are you nested?</h3>
                        <p>Yes! You can even nest your collapsible content!</p>
                    </div>
                </div>
            </div>
        </div>
        <div data-role="footer">
            <h4>Collapsible Content</h4> </div>
    </div>
</body>

</html>

Adding a Header Toolbar

Example 26: Setting up a header

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Header toolbar</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page">
        <div data-role="header">
            <h1>I am a header toolbar</h1> </div>
    </div>
</body>

</html>

Adding a Button to the Header

Example 27: Adding a button to the header

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Header toolbar</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page">
        <div data-role="header" data-position="inline">
            <!-- first link --><a href="#">Purchase</a>
            <h1>I am a header toolbar</h1>
            <!--second link --><a href="#">Apply</a> </div>
    </div>
</body>

</html>

Note that we did not have to apply a data-role to style the link as a button.
The link will be styled as a button automatically when it is inside the header toolbar.
The first link in the header toolbar always defaults to display on the left side of the header toolbar.

Attaching a Navigation Bar

A navigation toolbar, or navbar, is a widget built into jQuery Mobile that allows you to add navigation links to your page.

Example 28: A page with a navbar inside the header toolbar

The container for the navbar being created as a div element with an attribute of

data-role="navbar"

. Notice how the navbar is attached to the header toolbar by being created inside it. The <ul> element that contains all the links we want inside of the navbar. <li> elements that each contain a link.

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Header toolbar</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page">
        <div data-role="header" data-position="inline">
            <!-- first link --><a href="#">Purchase</a>
            <h1>I am a header toolbar</h1>
            <!--second link --><a href="#">Apply</a>
            <div data-role="navbar">
                <ul>
                    <li><a href="#">Home</a> </li>
                    <li><a href="#">About</a> </li>
                    <li><a href="#">Services</a> </li>
                    <li><a href="#">Blogs</a> </li>
                </ul>
            </div>
        </div>
    </div>
</body>

</html>

Adding a Footer Toolbar

Just like the header toolbar, the footer toolbar is added by adding an attribute of data-role="footer" to a container element.

A Code Snippet for Setting Up a Footer Toolbar:
<div data-role="footer">
<h4>I am a footer toolbar</h4>
</div>

This snippet of code should be as familiar as the header toolbar was, as we have covered it before. Let’s do something new and switch up the footer toolbar by removing the h4 element and replacing it with a few buttons.

Example 29: Adding and aligning buttons using control group in the footer of a page

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Header toolbar</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page">
        <div data-role="header" data-position="inline">
            <!-- first link --><a href="#">Purchase</a>
            <h1>I am a header toolbar</h1>
            <!--second link --><a href="#">Apply</a>
            <div data-role="navbar">
                <ul>
                    <li><a href="#">Home</a> </li>
                    <li><a href="#">About</a> </li>
                    <li><a href="#">Services</a> </li>
                    <li><a href="#">Blogs</a> </li>
                </ul>
            </div>
        </div>
        <!--content -->
        <div data-role="content">
            <h3>CONTENT GOES HERE SHORTLY</h3> </div>
        <!--adding footer to your page with tool bar -->
        <div data-role="footer" class="ui-bar">
            <div data-role="controlgroup" data-type="horizontal"> <a href="#" data-role="button">Features</a> <a href="#" data-role="button">Inquiry</a> <a href="#" data-role="button">Supports</a> </div>
        </div>
    </div>
</body>

</html>

Example 30: Two aligning options that can be used to align the buttons in the footer toolbar are the following snippet of code

Aligning Content with a Grid

<div data-role="footer" class="ui-bar">
    <div class="ui-grid-b">
        <div class="ui-block-a"><a href="#" data-role="button">Features</a> </div>
        <div class="ui-block-b"><a href="#" data-role="button">Inquiry</a> </div>
        <div class="ui-block-c"><a href="#" data-role="button">Supports</a> </div>
    </div>
</div>

Aligning Content with a Control Group


<div data-role="footer" class="ui-bar">
    <div data-role="controlgroup" data-type="horizontal"> <a href="#" data-role="button">Features</a> <a href="#" data-role="button">Inquiry</a> <a href="#" data-role="button">Supports</a> </div>
</div>

Example 31: Using a navbar in the Footer Toolbar

A navigation toolbar, or navbar, is a widget built into jQuery Mobile that allows you to add navigation links to your page. Similar to the built-in grid system, the navbar is capable of containing five columns. To add a navbar to your page, you must use a container element with an attribute of:

data-role="navbar"

Inside the container, you must have an unordered list with each column inside an <li> element.

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Header toolbar</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page">
        <div data-role="header" data-position="inline">
            <!-- first link --><a href="#">Purchase</a>
            <h1>I am a header toolbar</h1>
            <!--second link --><a href="#">Apply</a>
            <div data-role="navbar">
                <ul>
                    <li><a href="#">Home</a> </li>
                    <li><a href="#">About</a> </li>
                    <li><a href="#">Services</a> </li>
                    <li><a href="#">Blogs</a> </li>
                </ul>
            </div>
        </div>
        <!--content -->
        <div data-role="content">
            <h3>CONTENT GOES HERE SHORTLY</h3> </div>
        <!--adding footer to your page with tool bar -->
        <div data-role="footer">
            <div data-role="navbar">
                <ul>
                    <li><a href="#">Features</a> </li>
                    <li><a href="#">Inquiry</a> </li>
                    <li><a href="#">Supports</a> </li>
                </ul>
            </div>
        </div>
    </div>
</body>

</html>

Positioning the Toolbars

Toolbars are generally placed before and after the content section, as is standard in web development. Sometimes though you may find yourself wanting the header and footer to stay visible all the time, especially when you are using a navbar. There are two different ways of doing this. You can either use fixed or full-screen positioning on the toolbar.

Using a Fixed Position
When using a fixed position, jQuery Mobile checks the page to see whether the positioned toolbar is already in view. If the toolbar is out of the view, it will be inserted into the document at the top or bottom of the viewable area (depending on whether it is a header or footer toolbar).
To make a toolbar use the fixed position, you need to add data-position="fixed" to the toolbar.

Example 31: Fixed positioned toolbar

The rendered HTML in browser when have not been scrolled:

The rendered HTML in browser when have been scrolled:

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Toolbars with jQuery Mobile</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page">
        <div data-role="header" data-position="fixed"> <a href="#">Buy Me</a>
            <h1>Fixed example</h1><a href="#">Apply Now</a> </div>
        <div data-role="content"> <a href="#" data-role="button">A button!</a>
            <p style="height: 400px;">This has been styled to take up more space</p>
            <p>This way you can see what happens when you scroll down the page</p>
            <p>The toolbars will reappear when you stop scrolling</p>
            <p>You can hide them by clicking or tapping the screen</p>
        </div>
        <div data-role="footer" data-position="fixed">
            <div data-role="navbar">
                <ul>
                    <li><a href="#">Features</a> </li>
                    <li><a href="#">Supports</a> </li>
                    <li><a href="#">Contacts</a> </li>
                </ul>
            </div>
        </div>
    </div>
</body>

</html>

Using a Full-Screen Position
The full-screen position is closely related to the fixed position. The main difference is that the toolbars are placed above the page rather than as a part of it. This can create some navigation problems as links that would normally be available farther down or farther up the page from the toolbars are now sitting directly underneath them.
Full-screen positions are good to use when you are displaying an image gallery or for showing videos. In these instances the controls can be put in the navbar, letting the user open and close the controls when they need them.

To use the full-screen position you need to add data-fullscreen="true" to the div element that also has the attribute of data-role="page". You then need to make sure that both the header and footer toolbars contain data-position="fixed".
From the previous code that reads:
<div data-role="page">
We should change to now read:
<div data-role="page" data-fullscreen="true">

Example 32: Full screen positioned toolbar

Remember that items covered by toolbars using the full-screen position are still accessible by clicking or tapping somewhere on the screen to hide the toolbars.

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Toolbars with jQuery Mobile</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page" data-fullscreen="true">
        <div data-role="header" data-position="fixed"> <a href="#">Buy Me</a>
            <h1>Full Screen </h1><a href="#">Apply Now</a> </div>
        <div data-role="content"> <a href="#" data-role="button">A button!</a>
            <p style="height: 400px;">This has been styled to take up more space</p>
            <p>This way you can see what happens when you scroll down the page</p>
            <p>The toolbars will reappear when you stop scrolling</p>
            <p>You can hide them by clicking or tapping the screen</p>
        </div>
        <div data-role="footer" data-position="fixed">
            <div data-role="navbar">
                <ul>
                    <li><a href="#">Features</a> </li>
                    <li><a href="#">Supports</a> </li>
                    <li><a href="#">Contacts</a> </li>
                </ul>
            </div>
        </div>
    </div>
</body>

</html>


Adding Persistent Navigation

A div element with the attributes of data-role="footer", data-position="fixed", and data-id="rps". The first two attributes are the required setup for creating a footer toolbar and using fixed positioning. The data-id=”rps” keeps navbar visible while the page is transitioning. This works only when the value of the data-id attribute is the same on the current page and the one being transitioned to.

Example 31: Adding persistent navigation

Preview of features.html Preview of supports.html Preview of contacts.html

Inputs and Buttons
In HTML, many types of input elements create buttons. Anytime that you use an input element with an attribute type having a value of submit, reset, button, or image it automatically is styled as a button.
With these input types being automatically styled as buttons, you do not need to add the data-role="button" attribute like you did when using a link-based button. Just in case you were wondering, the button element is also automatically styled as a button and does not require any extra markup.
Example 32: inputs and buttons (form elements)

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Buttons jQuery Mobile</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page">
        <div data-role="header">
            <h1>Buttons / Inputs</h1> </div>
        <div data-role="content">
            <p>Link-based button</p> <a href="#" data-role="button">Link-based</a>
            <p>&lt;button&gt; Element</p>
            <button type="button">Button</button>
            <p>&lt;input type="submit"&gt;</p>
            <input type="submit" value="Submit" />
            <p>&lt;input type="button"&gt;</p>
            <input type="button" value="Button" />
            <p>&lt;input type="reset"&gt;</p>
            <input type="reset" value="Reset" />
            <p>&lt;input type="image"&gt;</p>
            <input type="image" value="Image" /> </div>
    </div>
</body>

</html>

Overriding Button Defaults
By default, buttons are given a certain appearance. While this appearance looks good on most mobile devices, it may not look good when combined with your design. Lucky for us, we can change a good portion of button aesthetics.

Example 33: creating buttons with rounded and squared corners

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Buttons jQuery Mobile</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page">
        <div data-role="header">
            <h1>Buttons</h1> </div>
        <div data-role="content"> <a href="#" data-role="button" data-corners="false">Squared</a> <a href="#" data-role="button">Rounded</a> <a href="#" data-role="button" data-corners="false">Squared</a> </div>
    </div>
</body>

</html>

Removing the Shadow
Another option you may want to change is the appearance of a drop shadow under your button.
This can be changed by using the data-shadow="false" attribute. You are not limited to using only one data attribute per element. You can combine them to get different styles.
Changing Button Appearance with Data Attributes

Example 34: adding persistent navigation

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Buttons jQuery Mobile</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page">
        <div data-role="header">
            <h1>Buttons</h1> </div>
        <div data-role="content"> <a href="#" data-role="button" data-shadow="false">No Shadow</a> <a href="#" data-role="button">Shadow</a> <a href="#" data-role="button" data-corners="false" data-shadow="false">Squared no Shadow</a> </div>
    </div>
</body>

</html>

Changing the Button Size
Whenever we previously created a button, we didn’t worry about the size of the button. While you may not ever need to change the default size of a button, you may run into a few problems or some unexpected results with the default size.

Example 35: Changing the Default Button Width with a Data Attribute

We added:

data-inline="true"

as an attribute to the element. Adding this attribute causes the button to use only as much space as the content inside it.

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Buttons jQuery Mobile</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page">
        <div data-role="header">
            <h1>Buttons</h1> </div>
        <div data-role="content"> <a href="#" data-role="button">Full Width Button</a> <a href="#" data-role="button" data-inline="true">Inline Button</a> </div>
    </div>
</body>

</html>

Example 36: placing button inline

Both buttons have the attribute:

data-inline="true"

This means that both buttons will appear next to each other. Adding more buttons with the same attribute will continue to line them up next to each other. Buttons will continue to line up next to each other until the maximum width has been reached.

<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Buttons jQuery Mobile</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page">
        <div data-role="header">
            <h1>Buttons</h1> </div>
        <div data-role="content"> <a href="#" data-role="button" data-inline="true">An Inline Button</a> <a href="#" data-role="button" data-inline="true">Also an Inline Button</a> </div>
    </div>
</body>

</html>

Adjusting Button Width and Placement by Using a Grid

Example 37: adjusting width and placing of button by using grid

Image title


<!DOCTYPE html>
<html>

<head>
    <title>Script-tutorials: Buttons jQuery Mobile</title>
    <meta name="viewport" content="width=device-width, initial-scale=1">
    <link rel="stylesheet" href="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.css" />
    <script src="http://code.jquery.com/jquery-1.7.1.min.js"></script>
    <script src="http://code.jquery.com/mobile/1.1.0/jquery.mobile-1.1.0.min.js"></script>
</head>

<body>
    <div data-role="page">
        <div data-role="header">
            <h1>Buttons</h1>
        </div>
        <div data-role="content">
            <div class="ui-grid-a">
                <div class="ui-block-a"><a href="#" data-role="button">Left</a>
                </div>
                <div class="ui-block-b"><a href="#" data-role="button">Right</a>
                </div>
            </div>
        </div>
    </div>
</body>

</html>


In this example, we see a simple two-column grid. A class of  ui-block-a alligns content in the first column of the grid, while a class of a  ui-block-b aligns content in the second column.

Topics:
mobile ,app development ,jquery ,html

Published at DZone with permission of Andrey Prikaznov, DZone MVB. See the original article here.

Opinions expressed by DZone contributors are their own.

THE DZONE NEWSLETTER

Dev Resources & Solutions Straight to Your Inbox

Thanks for subscribing!

Awesome! Check your inbox to verify your email so you can start receiving the latest in tech news and resources.

X

{{ parent.title || parent.header.title}}

{{ parent.tldr }}

{{ parent.urlSource.name }}
