Ktor: a Kotlin Web Framework

DZone 's Guide to

Ktor: a Kotlin Web Framework

Create a simple web server with Ktor.

· Web Dev Zone ·
Free Resource

Ktor is an asynchronous web framework written in and designed for Kotlin. Allowing the more impressive features of Kotlin, such as coroutines, to not only be used but supported. Typically, Spring is my go-to general framework, and usually what I use when I need to put a REST API together. However, after recently attending a London Kotlin meetup where there was a presentation on Ktor, I decided I’d try something new for once. That is how I ended up here, writing a blog post about Ktor. So, this post is a learning experience for both you and me.

Implementation

Dependencies

buildscript {
  ext.kotlin_version = '1.3.41'
  ext.ktor_version = '1.2.2'

  repositories {
    mavenCentral()
  }
  dependencies {
    classpath "org.jetbrains.kotlin:kotlin-gradle-plugin:$kotlin_version"
  }
}

apply plugin: 'java'
apply plugin: 'kotlin'

// might not be needed but my build kept defaulting to Java 12
java {
  disableAutoTargetJvm()
}

// Ktor uses coroutines
kotlin {
  experimental {
    coroutines "enable"
  }
}

compileKotlin {
  kotlinOptions.jvmTarget = "1.8"
}
compileTestKotlin {
  kotlinOptions.jvmTarget = "1.8"
}

dependencies {
  // Kotlin stdlib + test dependencies

  // ktor dependencies
  compile "io.ktor:ktor-server-netty:$ktor_version"
  compile "io.ktor:ktor-jackson:$ktor_version"
  // logback for logging
  compile group: 'ch.qos.logback', name: 'logback-classic', version: '1.2.3'
  // kodein for dependency injection
  compile group: 'org.kodein.di', name: 'kodein-di-generic-jvm', version: '6.3.0'
}


A few things are going on here.

  • Ktor requires a minimum version of Kotlin 1.3, so that coroutines can be leveraged.
  • Dependencies on ktor-server-netty and ktor-jackson are brought in. As the name suggests, this means Netty will be used for this post. Different underlying web servers can be used depending on which you choose to import. Currently, the remaining options are Jetty and Tomcat.
  • Logback is brought in to handle logging. This is not included in the Ktor dependencies and is needed if you plan on doing any sort of logging.
  • Kodein is a dependency injection framework written in Kotlin. I have used it loosely in this post, and due to the size of the code examples, I could probably remove it altogether. The main reason it is there is to provide another chance to use something other than Spring.

Starting the Web Server

With the boring stuff out of the way, I can now run you through implementing a simple web server. The code below is all you need:

fun main() {
  embeddedServer(Netty, port = 8080, module = Application::module).start()
}

fun Application.module() {
  // code that does stuff which is covered later
}


Bam. There you have it. A simple web server running with Ktor and Netty. Ok, yes, it doesn’t really do anything, but we’ll expand on this in the following sections. The code is pretty self-explanatory. The only piece worth highlighting is the Application.module() function. The module parameter of embeddedServer requires an extension function for Application. This is going to be the main function.

In the following sections, we will expand the contents of Application.module, so that your web server actually does something worthwhile.

Routing

At the moment, all incoming requests will be rejected, since there are no endpoints to handle them. By setting up the routing, you can specify valid paths that requests can travel along and the functions that will process the requests when they reach their destinations.

This is done inside of a Routing block (or multiple Routing blocks). Inside of a block, routes to different endpoints are set up:

routing {
  // all routes defined inside are prefixed with "/people"
  route("/people") {
    // get a person
    get("/{id}") {
      val id = UUID.fromString(call.parameters["id"]!!)
      personRepository.find(id)?.let {
        call.respond(HttpStatusCode.OK, it)
      } ?: call.respondText(status = HttpStatusCode.NotFound) { "There is no record with id: $id" }
    }
    // create a person
    post {
      val person = call.receive<Person>()
      val result = personRepository.save(person.copy(id = UUID.randomUUID()))
      call.respond(result)
    }
  }
}


Routing is a little convenience function to make the code flow a little smoother. The context (a.k.a this) inside of routing is of type Routing. Furthermore, the functions route, get, and post are all extension functions of Routing.

Route sets a base path to all its following endpoints. In this scenario, /people.get and post do not specify a path themselves, since the base path is sufficient for their needs. If desired, a path could be added to each one, as in the following example:

routing {
  // get a person
    get("/people/{id}") {
      val id = UUID.fromString(call.parameters["id"]!!)
      personRepository.find(id)?.let {
        call.respond(HttpStatusCode.OK, it)
      } ?: call.respondText(status = HttpStatusCode.NotFound) { "There is no record with id: $id" }
    }
  // create a person
  post("/people) {
    val person = call.receive<Person>()
    val result = personRepository.save(person.copy(id = UUID.randomUUID()))
    call.respond(result)
  }
}


Before you move onto the next section, I want to show you how I actually implemented the routing:

fun Application.module() {
  val personRepository by kodein.instance<PersonRepository>()
  // route requests to handler functions
  routing { people(personRepository) }
}

// extracted to a separate extension function to tidy up the code
fun Routing.people(personRepository: PersonRepository) {
  route("/people") {
    // get a person
    get("/{id}") {
      val id = UUID.fromString(call.parameters["id"]!!)
      personRepository.find(id)?.let {
        call.respond(HttpStatusCode.OK, it)
      } ?: call.respondText(status = HttpStatusCode.NotFound) { "There is no record with id: $id" }
    }
    // create a person
    post {
      val person = call.receive<Person>()
      val result = personRepository.save(person.copy(id = UUID.randomUUID()))
      call.respond(result)
    }
  }
}


I extracted the code to a separate function to decrease the contents of Application.module. This is going to be a good idea when you are trying to write a more significant application. Whether how I went about it is the Ktor way or not, is another question. From having a quick look at the Ktor docs, it looks like this is a decent solution. I believe I saw another way to do this, but I would need to spend more time with it.

Contents of a Request Handler

The code that executes when a request is routed to a request handler is obviously pretty important. The function needs to do something after all.

Each handler function executes within the context of a coroutine. I did not really make any use of this fact, since each of the functions I have shown is fully synchronous. For a bit more information on this, the Ktor docs have an async example.

For the remainder of this post, I am going to try and not mention coroutines too much, since they are not particularly important for this simple REST API.

In this section, the get function will be examined a little closer:

get("/{id}") {
  val id = UUID.fromString(call.parameters["id"]!!)
  personRepository.find(id)?.let {
    call.respond(HttpStatusCode.OK, it)
  } ?: call.respondText(status = HttpStatusCode.NotFound) { "There is no record with id: $id" }
}


{id} indicates that a path variable is expected in the request and its value will be stored as id. Multiple path variables can be included, but only one is needed for this example. The value of id is retrieved from call.paremeters, which takes in the name of the variable you want to access.

  • call represents the context of the current request.
  • parameters is a list of the request’s parameters.

Using the id from the path variables, the database searches for the corresponding record. In this scenario, if it exists, the record is returned along with the appropriate 200 OK. If it doesn’t, an error response is returned. Both respond and respondText alter the underlying response of the current call. You could do this manually, for example, by using:

call.response.status(HttpStatusCode.OK)
call.response.pipeline.execute(call, it)


You could do that, but there isn’t any need to, since that is actually just the implementation of respond.respondText has some extra logic but delegates down to response to finalize everything. The final call to execute in this function represents the value returned by the function.

Installing Extra Features

In Ktor, extra features can be plugged in when needed. For example, Jackson JSON parsing can be added to handle and return JSON from your application. Below are the features installed to the example application:

fun Application.module() {
  install(DefaultHeaders) { header(HttpHeaders.Server, "My ktor server") }
  // controls what level the call logging is logged to
  install(CallLogging) { level = Level.INFO }
  // setup jackson json serialisation
  install(ContentNegotiation) { jackson() }
}


  • DefaultHeaders adds a header to every response with the name of the server.
  • CallLogging logs information about outgoing responses and specifies what level to log them at. A logging library needs to be included for this to work. The output will look something like:
    INFO  ktor.application.log - 200 OK: GET - /people/302a1a73-173b-491c-b306-4d95387a8e36
  • ContentNegotiation tells the server to use Jackson for incoming and outbound requests. Remember this required including ktor-jackson as a dependency. You could also use GSON if you prefer.

For a long list of the other features that Ktor includes, here is a handy link to their docs.

Installing features ties all the way back to the routing done earlier. Routing delegates down to install inside its implementation. So you could write:

install(Routing) {
  route("/people") {
    get {
      // implementation
    }
  }
}


Whatever floats your boat, but I’d just stick to using routing. Hopefully, that helped you understand what is going on under the hood, even if it was just a little bit.

A Brief Mention for Kodein

I want to have a very brief look at Kodein, since I used it in this post. Kodein is a dependency injection framework written in Kotlin for Kotlin. Below is the super small amount of DI that I used for the example application:

val kodein = Kodein {
  bind<CqlSession>() with singleton { cassandraSession() }
  bind<PersonRepository>() with singleton { PersonRepository(instance()) }
}
val personRepository by kodein.instance<PersonRepository>()


Inside of the Kodein block, instances of the application’s classes are created. In this scenario, only one instance of each class is needed. Calling singleton denotes this. Instance is a placeholder provided by Kodein to pass into a constructor instead of the actual object.

Outside of the Kodein block, an instance of PersonRepository is retrieved.

Yeah, I know, there isn’t really much point to the use of Kodein here, since I could have replaced it with a single line…

val personRepository = PersonRepository(cassandraSession())


Instead, let’s think about it as a very concise example to understand.

Closing Thoughts

As someone that is extremely biased towards Spring, I found working with Ktor very different from what I am used to. It took me a bit longer than usual to work towards some sample code that I was happy with. That being said, I think the outcome looks ok, and I will need to spend some more time with Ktor to better understand precisely how to get the best out of it. At the moment, I am confident there is a lot more to squeeze out of Ktor. For more information on Ktor, I’ll have to refer you again to their documentation where they have plenty of samples and tutorials.

The code used in this post can be found on my GitHub.
