Load Balancing Kubernetes Services with NGINX Plus

Here's how to load balance Kubernetes, an open source system, with NGINX Plus.

Download Forrester’s “Vendor Landscape, Application Performance Management” report that examines the evolving role of APM as a key driver of customer satisfaction and business success, brought to you in partnership with BMC.

Kubernetes is an open source system developed by Google for running and managing containerized microservices-based applications in a cluster. People who use Kubernetes often need to make the services they create in Kubernetes accessible from outside of their Kubernetes cluster.

Although Kubernetes provides built-in solutions for exposing services, described in below, those solutions limit you to Layer 4 load balancing or round-robin HTTP load balancing.

This post shows how to use NGINX Plus as an advanced Layer 7 load-balancing solution for exposing Kubernetes services to the Internet, whether you are running Kubernetes in the cloud or on your own infrastructure.

We’ll assume that you have a basic understanding of Kubernetes (pods, services, replication controllers, and labels) and a running Kubernetes cluster. To learn more about Kubernetes, please visit the official Kubernetes user guide.

Exposing Kubernetes Services with Built-in Solutions

Kubernetes offers several options for exposing services. Two of them – NodePort and LoadBalancer – correspond to a specific type of service. A third option, Ingress API, became available as a beta in Kubernetes release 1.1.


Specifying the service type as NodePort makes the service available on the same port on each Kubernetes node. To expose the service to the Internet, you expose one or more nodes on that port. For high availability, you can expose multiple nodes and use DNS-based load balancing to distribute traffic among them, or you can put the nodes behind a load balancer of your choice.

When incoming traffic hits a node on the port, it gets load balanced among the pods of the service. The load balancing that is done by Kubernetes proxy running on every node is limited to TCP/UDP load balancing.


Specifying the service type as LoadBalancer allocates a cloud load balancer that distributes incoming traffic among the pods of the service.

The LoadBalancer solution is supported only by certain cloud providers and Google Container Engine and not available if you are running Kubernetes on your own infrastructure. Further, Kubernetes only allows you to configure round-robin TCP load balancing, even if the cloud load balancer has advanced features such as session persistence or request mapping.

Ingress API

Creating an Ingress resource enables you to expose services to the Internet at custom URLs (for example, service A at the URL /foo and service B at the URL /bar) and multiple virtual host names (for example, foo.example.com for one group of services and bar.example.com for another group). An Ingress controller consumes an Ingress resource and sets up an external load balancer.

An Ingress controller is not a part of a standard Kubernetes deployment: you need to choose the controller that best fits your needs or implement one yourself, and add it to your Kubernetes cluster. Many controller implementations are expected to appear soon, but for now the only available implementation is the controller for Google Compute Engine HTTP Load Balancer, which works only if you are running Kubernetes on Google Compute Engine or Google Container Engine. Ingress API supports only round-robin HTTP load balancing, even if the actual load balancer supports advanced features.

As of this writing, both the Ingress API and the controller for the Google Compute Engine HTTP Load Balancer are in beta.

Although the solutions mentioned above are simple to set up, and work out of the box, they do not provide any advanced features, especially features related to Layer 7 load balancing.

Exposing Kubernetes Services with NGINX Plus

To integrate NGINX Plus with Kubernetes we need to make sure that the NGINX Plus configuration stays synchronized with Kubernetes, reflecting changes to Kubernetes services, such as addition or deletion of pods. With the open source NGINX software, you manually modify the NGINX configuration file and do a configuration reload. With NGINX Plus, there are two ways to update the configuration dynamically:

  • With APIs – This method uses the NGINX Plus on-the-fly reconfiguration API to add and remove entries for Kubernetes pods in the NGINX Plus configuration, and the Kubernetes API to retrieve the IP addresses of the pods. This method requires us to write some code, and we won’t discuss it in depth here. For details, watch Kelsey Hightower’s webinar, Bringing Kubernetes to the Edge with NGINX Plus, in which he explores the APIs and creates an application that utilizes them.
  • By re-resolving DNS names – This method requires only a proper one-time configuration of NGINX Plus, as described in the following section.

Utilizing DNS-Based Reconfiguration

We assume that you already have a running Kubernetes cluster and a host with the kubectl utility available for managing the cluster; for instructions, see the Kubernetes getting started guide for your cluster type. You also need to have built an NGINX Plus Docker image, and instructions are available in this blog post.

Here is an outline of what we’ll do:

  1. Configure an NGINX Plus pod to expose and load balance the service that we’re creating in Step 2.
  2. Create a simple service that serves static web pages.
  3. Scale the service up and down and watch how NGINX Plus gets automatically reconfigured.

Notes: We tested the solution described in this blog with Kubernetes 1.0.6 running on Google Compute Engine and a local Vagrant setup, which is what we are using below.

In commands, values that might be different for your Kubernetes setup appear in italics.

Configuring the NGINX Plus Pod

We are putting NGINX Plus in a Kubernetes pod on a node that we expose to the Internet. Our pod is created by a replication controller, which we are also setting up. Our Kubernetes-specific NGINX Plus configuration file resides in a folder shared between the NGINX Plus pod and the node, which makes it simpler to maintain.

Choosing the Node That Hosts the NGINX Plus Pod

To designate the node where the NGINX Plus pod runs, we add a label to that node. We get the list of all nodes by running:

$ kubectl get nodes
NAME         LABELS                              STATUS   Kubernetes.io/hostname=   Ready   Kubernetes.io/hostname=   Ready   Kubernetes.io/hostname=   Ready

We choose the first node and add a label to it by running:

$ kubectl label node role=nginxplus

Configuring the Replication Controller for the NGINX Plus Pod

We are not creating an NGINX Plus pod directly, but rather through a replication controller. We configure the replication controller for the NGINX Plus pod in a Kubernetes declaration file called nginxplus-rc.yaml.

  • We set the number of replicas to one, which means Kubernetes makes sure that one NGINX Plus pod is always running: if the pod fails, it is replaced by a new pod.
  • In the nodeSelector field we specify that the NGINX Plus pod is created on a node labeled with role: nginxplus.
  • Our NGINX Plus container exposes two ports, 80 and 8080, and we set up a mapping between them and ports 80 and 8080 on the node.
  • Our NGINX Plus container also shares the /etc/nginx/conf.d folder that resides on the node. As explained further in below, sharing the folder lets us reconfigure NGINX Plus without rebuilding the container image.
apiVersion: v1
kind: ReplicationController
  name: nginxplus-rc
  replicas: 1
    app: nginxplus
        app: nginxplus
        role: nginxplus
      - name: nginxplus
        image: nginxplus
          - name: http
            containerPort: 80
            hostPort: 80
          - name: http-alt
            containerPort: 8080
            hostPort: 8080
          - mountPath: "/etc/nginx/conf.d"
            name: etc-nginx-confd
        - hostPath:
            path: "/etc/nginx/conf.d"
          name: etc-nginx-confd

Making the NGINX Plus Docker Image Available on the Node

As we said above, we already built an NGINX Plus Docker image. Now we make it available on the node. For simplicity, we do not use a private Docker repository, and we just manually load the image onto the node.

On the host where we built the Docker image, we run the following command to save the image into a file:

$ docker save -o nginxplus.tar nginxplus

We transfer nginxplus.tar to the node, and run the following command on the node to load the image from the file:

$ docker load -i nginxplus.tar

Configuring NGINX Plus

In the NGINX Plus container’s /etc/nginx folder, we are retaining the default main nginx.conf configuration file that comes with NGINX Plus packages. The include directive in the default file reads in other configuration files from the /etc/nginx/conf.d folder. As specified in the for the NGINX Plus replication controller (nginxplus-rc.yaml), we’re sharing the /etc/nginx/conf.d folder on the NGINX Plus node with the container. The sharing means we can make changes to configuration files stored in the folder (on the node) without having to rebuild the NGINX Plus Docker image, which we would have to do if we created the folder directly in the container. We put our Kubernetes-specific configuration file (backend.conf) in the shared folder.

First, let’s create the /etc/nginx/conf.d folder on the node.

$ mkdir /etc/nginx/conf.d

Then we create the backend.conf file there and include these directives:

  • resolver – Defines the IP address of the Kubernetes DNS resolver, using the default IP address, The valid parameter tells NGINX Plus to re-resolve any DNS name every five seconds. The IP address of your Kubernetes DNS service might be different. Run this command to learn it:
    $ kubectl get svc kube-dns --namespace=kube-system
  • upstream – Creates an upstream group called backend for the Kubernetes service that we are exposing. We identify the servers in the upstream group with a hostname and include the resolve directive to tell NGINX to re-resolve the hostname at runtime.
  • server (twice) – Define two virtual servers:
    • The first server listens on port 80 and load balances incoming requests for /nginx-service among the pods of our service. We also set up active health checks.
    • The second server listens on port 8080. Here we set up live activity monitoring of NGINX Plus. Later we will use it to check that NGINX Plus was properly reconfigured.
resolver valid=5s;

upstream backend {
    zone upstream-backend 64k;
    server nginx-service.default.svc.cluster.local resolve;

server {
    listen 80;

    status_zone backend-servers;

    location /nginx-service/ {
        proxy_pass http://backend/;

server {
    listen 8080;

    root /usr/share/nginx/html;

    location = /status.html { }

    location /status {

Creating the Replication Controller

Now we’re ready to create the replication controller by running this command on our node:

$ kubectl create -f nginxplus-rc.yaml

To verify the NGINX Plus pod was created, we run:

$ kubectl get pods
NAME                 READY     STATUS    RESTARTS   AGE
nginxplus-rc-0ts5t   1/1       Running   0          17s

We are running Kubernetes on a local Vagrant setup, so we know that our node’s external IP address is and we will use that address for the rest of this example. If you are running Kubernetes on a cloud provider, you can get the external IP address of your node by running:

$ kubectl get nodes node-name -o json | grep -i externalIP -A 1
                "type": "ExternalIP",
                "address": XXX.XXX.XXX.XXX

If you are running on a cloud, do not forget to set up a firewall rule to allow the NGINX Plus node to accept incoming traffic. Please refer to your cloud provider’s documentation.

We can check that our NGINX Plus pod is up and running by looking at the NGINX Plus live activity monitoring dashboard, which is available on port 8080 at the external IP address of the node (so in our case). If we look at this point, however, we do not see any servers for our service, because we did not create it yet.

The NGINX Plus live activity monitoring dashboard before we create the Kubernetes services

Creating a Simple Kubernetes Service

Now it’s time to create a Kubernetes service. Our service consists of two (open source) NGINX servers that serve static web pages.

Creating the Replication Controller for the Service

First we create a replication controller so that Kubernetes makes sure the specified number of NGINX web server replicas (pods) are always running in the cluster. Here is the declaration file (nginx-rc.yaml):

apiVersion: v1
kind: ReplicationController
  name: nginx-rc
  replicas: 2
    app: nginx
        app: nginx
      - name: nginx
        image: nginx
        - containerPort: 80

Our controller consists of two NGINX web servers. We declare a controller consisting of pods with a single NGINX container, exposing port 80. The NGINX image will be pulled from Docker Hub.

To create the replication controller we run the following commands on the node:

$ kubectl create -f nginx-rc.yaml

To check that our pods were created we can run the following command. We use the label selector app=nginx to get only the pods created by the replication controller in the previous step:

$ kubectl get pods -l app=nginx
nginx-rc-544f1   1/1       Running   0          2m
nginx-rc-uk6pm   1/1       Running   0          2m

Creating the Service

Next we create a service for the pods created by our replication controller. We declare the service with the following file (nginx-service.yaml):

apiVersion: v1
kind: Service
  name: nginx-service
  ClusterIP: None
  - port: 80
    targetPort: 80
    protocol: TCP
    app: nginx

Here we are declaring a special headless service by setting the ClusterIP field to None. With this type of service, a cluster IP address is not allocated and the service is not available through the kube proxy. A DNS query to the Kubernetes DNS returns multiple A records (the IP addresses of our pods).

By setting the selector field to app: nginx, we declare which pods belong to the service, namely the pods created by our NGINX replication controller (defined in nginx-rc.yaml).

On the node we run the following command, which creates the service:

$ kubectl create -f nginx-service.yaml

Now if we refresh the dashboard page and click the Upstreams tab in the top right corner, we see the two servers we added.

The NGINX Plus live activity monitoring dashboard after the Kubernetes services are created

We can also check that NGINX Plus is load balancing traffic among the pods of the service. If it is, we see the default NGINX welcome page when we access in a browser.

The welcome page confirms that NGINX Plus is load balancing our Kubernetes services

If we refresh this page several times and look at the status dashboard, we see how the requests get distributed across the two upstream servers.

Scaling the Kubernetes Service

Now let’s add two more pods to our service and make sure that the NGINX Plus configuration is again updated automatically. We run this command to change the number of pods to four by scaling the replication controller:

$ kubectl scale rc nginx-rc --replicas=4

To check that NGINX Plus was reconfigured, we could again look at the dashboard, but this time we use the NGINX Plus status API instead. On our node we run the following command, with being the external IP address of our NGINX Plus node. To format the JSON output, we pipe the output to jq.

$ curl -s | jq .
  "peers": [
      "id": 1,
      "server": "",
      "backup": false,
      "weight": 1,
      "state": "unhealthy",
      "active": 0,
      "requests": 1,
      "responses": {
        "1xx": 0,
        "2xx": 0,
        "3xx": 0,
        "4xx": 0,
        "5xx": 0,
        "total": 0
      "sent": 0,
      "received": 0,
      "fails": 0,
      "unavail": 0,
      "health_checks": {
        "checks": 1,
        "fails": 1,
        "unhealthy": 1,
        "last_passed": false
      "downtime": 33965,
      "downstart": 1445378182275,
      "selected": 1445378131000
      "id": 2,
      "server": "",
      "id": 3,
      "server": "",
      "id": 4,
      "server": "",
  "keepalive": 0

The peers array in the JSON output has exactly four elements, one for each NGINX web server.

Now let’s reduce the number of pods from four to one and check the NGINX Plus status again:

$ kubectl scale rc nginx-rc --replicas=1

$ curl -s | jq .

Now the peers array in the JSON output contains only one element.

Now that we have NGINX Plus up and running, we can start leveraging its advanced features such as session persistence, SSL termination, request routing, advanced monitoring, and more.


The on-the-fly reconfiguration options available in NGINX Plus let you integrate it with Kubernetes with ease: either programmatically via an API or entirely by means of DNS. Using NGINX Plus for exposing Kubernetes services to the Internet provides many features that the current built-in Kubernetes load-balancing solutions lack.
