Loading and Analyzing Strava Runs Using PostgreSQL JSON Data Type

In my last post, I showed how to map Strava runs using data that I’d extracted from their /activities API, but the API returns a lot of other data that I discarded because I wasn’t sure what I should keep.

The API returns a nested JSON structure, so the easiest solution would be to save each run as an individual file. But I’ve always wanted to try out PostgreSQL’s JSON data type and this seemed like a good opportunity.

Creating a JSON-Ready PostgreSQL Table

First up, we need to create a database in which we’ll store our Strava data. Let’s name it appropriately:

CREATE DATABASE strava;
\CONNECT strava;

Now, we can now create a table with one field with the JSON data type:

CREATE TABLE runs (
  id INTEGER NOT NULL,
  DATA jsonb
);

ALTER TABLE runs ADD PRIMARY KEY(id);

Easy enough. Now we’re ready to populate the table.

Importing Strava API

We can partially reuse the script from the last post except rather than saving to CSV file we’ll save to PostgreSQL using the psycopg2 library.

The script relies on a TOKEN environment variable. If you want to try this on your own Strava account you’ll need to create an application, which will give you a key.

import requests
import os
import json
import psycopg2

token = os.environ["TOKEN"]
headers = {'Authorization': "Bearer {0}".format(token)}

with psycopg2.connect("dbname=strava user=markneedham") as conn:
    with conn.cursor() as cur:
        page = 1
        while True:
            r = requests.get("https://www.strava.com/api/v3/athlete/activities?page={0}".format(page), headers = headers)
            response = r.json()

            if len(response) == 0:
                break
            else:
                for activity in response:
                    r = requests.get("https://www.strava.com/api/v3/activities/{0}?include_all_efforts=true".format(activity["id"]), headers = headers)
                    json_response = r.json()
                    cur.execute("INSERT INTO runs (id, data) VALUES(%s, %s)", (activity["id"], json.dumps(json_response)))
                    conn.commit()
                page += 1

Querying Strava

We can now write some queries against our newly imported data.

My Quickest Runs

SELECT id, data->>'start_date' AS start_date,
       (data->>'average_speed')::FLOAT AS speed
FROM runs
ORDER BY speed DESC
LIMIT 5

    id     |      start_date      | speed
-----------+----------------------+-------
 649253963 | 2016-07-22T05:18:37Z | 3.736
 914796614 | 2017-03-26T08:37:56Z | 3.614
 653703601 | 2016-07-26T05:25:07Z | 3.606
 548540883 | 2016-04-17T18:18:05Z | 3.604
 665006485 | 2016-08-05T04:11:21Z | 3.604
(5 ROWS)

My Longest Runs

SELECT id, data->>'start_date' AS start_date,
       (data->>'distance')::FLOAT AS distance
FROM runs
ORDER BY distance DESC
LIMIT 5

    id     |      start_date      | distance
-----------+----------------------+----------
 840246999 | 2017-01-22T10:20:33Z |  10764.1
 461124609 | 2016-01-02T08:42:47Z |  10457.9
 467634177 | 2016-01-10T18:48:47Z |  10434.5
 471467618 | 2016-01-16T12:33:28Z |  10359.3
 540811705 | 2016-04-10T07:26:55Z |   9651.6
(5 ROWS)

Runs This Year

SELECT COUNT(*)
FROM runs
WHERE data->>'start_date' >= '2017-01-01 00:00:00'

 COUNT
-------
    62
(1 ROW)

Runs per Year

SELECT EXTRACT(YEAR FROM to_date(data->>'start_date', 'YYYY-mm-dd')) AS YEAR,
       COUNT(*)
FROM runs
GROUP BY YEAR
ORDER BY YEAR

 YEAR | COUNT
------+-------
 2014 |    18
 2015 |   139
 2016 |   166
 2017 |    62
(4 ROWS)

That’s all for now. Next, I’m going to learn how to query segments, which are stored inside a nested array inside the JSON document. Stay tuned for that in a future post.
