Neo4j Object Mapping With GORM, Groovy, and Spring Boot

DZone's Guide to

Neo4j Object Mapping With GORM, Groovy, and Spring Boot

Using Groovy with Neo4j is now easier than ever with GORM for Neo4j 6.1. Read on for details and to show you how you can leverage this library in your next app.

· Integration Zone ·
Free Resource

SnapLogic is the leading self-service enterprise-grade integration platform. Download the 2018 GartnerMagic Quadrant for Enterprise iPaaS or play around on the platform, risk free, for 30 days.

Learn how to use GORM, Groovy and Spring Boot for object mapping in Neo4j

Mapping object models to the Neo4j

graph in languages such as Java and Groovy may be immensely convenient when developing your application, but has the danger of obfuscating the power of Neo4j.

With the recently released GORM for Neo4j 6.1 at OCI, the home of the core Grails team, we built a tool that takes advantage of the native features exposed by the Neo4j Bolt Java Driver.

Get Started

If you want to get started immediately, we’ve provided

a detailed tutorial

that walks through all the features that GORM provides for Neo4j.

You’ll use GORM and Grails to develop a simple web application for the built-in movie database. The guide covers the backend with domain model and services, which provide REST endpoints to a JavaScript UI.

A repository with the resulting Grails application

is available here


If you’d rather use Spring Boot with Web-MVC, GORM provides you the same benefits. Here is a repository for an example Spring Boot application that achieves the same thing.

But now, let’s look at GORM for Neo4j in some more detail.

Model Nodes, Relationships, and Paths

GORM for Neo4j allows you to model

not just nodes

, but also to

map Groovy classes to relationships


Combine all of this with the supporting features that you would expect from an object mapping tool, such as:

For example, to map a Groovy class to a graph node simply define a class and annotated it with @Entity:

import grails.gorm.annotation.*
class Movie {
    String title
    String tagline
    int released

Relationships can be modeled by using the



import grails.neo4j.Relationship

class CastMember implements Relationship


       roles = [] }

These can then be queried either natively or using GORM’s

existing rich query API


Later you can use more advanced GORM features like constraints or has-many mappings.

class Movie {
    String title
    String tagline
    int released

    static hasMany = [cast: CastMember]

    static constraints = {
        released min:1900
        title blank:false

Groovy and Neo4j: A Natural Fit

With Neo4j being a schema-less database, Groovy’s ability to simplify dynamic code (whilst still providing support for static compilation) really shines.

You can of course statically declare the properties of your domain class, but if you need to assign dynamic properties to individual objects, that is not a problem with Groovy.

For example, you can read and write dynamic properties using Groovy’s subscript operator, thus not limiting yourself to a statically defined schema:

Movie movie = Movie.findByTitle("The Matrix")
movie["rating"] = 5

println "The movie ${movie} is rated ${movie['rating']}"

Harness the Power of Cypher

GORM for Neo4j provides many

awesome ways to build queries

, though none of these impacts your ability to use the native power of



You can use Cypher for all your queries, or just to solve specific problems, such as finding the shortest path.

You can even get GORM to write your Cypher query logic for you, using

GORM Data Services


For example the following interface uses the @Cypher annotation to automatically implement a method called updatePerson for you.

import grails.gorm.services.Service
import grails.neo4j.services.Cypher

interface PersonService {

    @Cypher("""MATCH ${Person p}
               WHERE ${p.name} = ${name}
               SET ${p.age} = ${age}""")
    void updatePerson(String name, int age)


Compile time checking is applied against the classes and property references including within the Cypher query!

Built for the Real World

Our preference at


is to always build solutions based on real-world experiences, and with GORM for Neo4j that hasn’t changed.

We worked together with Brinqa – a leading provider of unified risk management – to build an object mapping solution for Neo4j that addresses their real-world challenges.

Curious to know more? We have prepared

a detailed tutorial

based on the original Neo4j movies data model that demonstrates building an application with Grails, GORM 6.1 and Neo4j. Please check it out and

let us know if you have any suggestions for improvement


[As community content, this post reflects the views and opinions of the particular author and does not necessarily reflect the official stance of Neo4j.]
