RAMLing Again With API Workbench: From Setup to Design

We will see here how to get started with API Workbench and start designing and developing our APIs with a design-first approach.

Build APIs from SQL and NoSQL or Salesforce data sources in seconds. Read the Creating REST APIs white paper, brought to you in partnership with CA Technologies.

I previously published a blog post on DZone that demonstrated how to design a RAML in API Designer, which is an online cloud editor that uses an in-browser filesystem in HTML5 Local storage. But then I thought of exploring some more options for a tool/editor that can help us to design and code our RAML locally as an IDE (such as Eclipse or Netbean for Java).

Luckily MuleSoft has an integrated development environment (IDE) that makes it possible for developers to build and design RESTful APIs based on a RAML specification called API Workbench that supports both  0.8 and the  1.0 release candidate.

We will see here how to get started with this tool/editor and with the installation details and then apparently start with designing and developing our APIs in it. This will be the design-first approach to APIs.

Features of API Workbench

API Workbench is one of the brilliant tools by MuleSoft that help us to create and consume APIs with RAML easily and efficiently. Here are a few features:

  • It is a Desktop-based IDE that has an interactive and dynamic API console with other features like advanced search, RAML autocomplete, live RAML debugging, RAML refactoring, RAML code validation, etc.
  • It has a powerful Graphical API creation tools and can dynamically generate API mocking service.
  • It has an easy to use wizard and built-in tools for source control and versioning along with tools for testing and use case documentation.

Downloading and Installing

So after going through all these above features, it’s now time to grab the tool/editor and start with it. This API Workbench is actually a plugin for ATOM IDE and we can get it from http://apiworkbench.com/ or from https://github.com/mulesoft/api-workbench .

First we need to install ATOM IDE (Download it if you don’t have with you), and once we are done with our installation, we need to launch the IDE, the first look will be as following:

Image title

Now our prime task will be to install the plugin called  from the setting options. This plugin will help us in designing our APIs!

We need to go into the package menu →settings menu and then the install option under it. We need to search for -workbench in the search box:

Image title

And now we will get our plugin api-workbench as an option to install as a package as follows:

Image title

After we successfully install the dependency package, we will get the notification on the screen:

Image title

So far we are good. Let’s get started with some designing. As the api-workbench is now installed with this IDE, we can get our hands into designing our RAML.

To start we will be going into package menu →API workbench →Create RAML project option:

Image title

We can clearly see we have different options for creating a fresh RAML project and getting an existing API from Popular API community. For now we’ll go for the first option of creating a fresh RAML project.

Getting Started With Designing Our APIs

After selecting the option for creating a fresh RAML project we can start our RAMLing business. We will be greeted with the following screen where we need to provide TitleVersion, and Base uri for our API. This is the first phase of our design and the input we will put here will result in creating a new RAML file with all these details.

Image title

Once done, we will get the following RAML file, which has a sample code in it. We need to modify the file as per our requirements. We can also see here that the RAML file generated contains the TitleVersion, and Base uri for our API we mentioned in the wizard:

Image title

On the right-hand side bottom, we can see a ready-made palette available for the RAML tags which we can use in our design that will reduce our effort in typing. It also has other features like RAML autocomplete that will help to reduce the long typing and other features like a documentation tab which let us add a description automatically with RAML tags:

Image title

The most powerful feature here we can see is the RAML code validation as below which instantly shows up the syntax issue with the line number:

Image title

It performs different types of validations during our API design, which include Structural ValidationReferences ValidationTraits & Resource Type Parameters ValidationSchema ValidationExample Validation and RAML version and fragments validation. Thus we can easily imagine how powerful this IDE is that help us to make our API perfect in both design and functionality!

The API Workbench provides a dynamic API console where we can see our output and structure of our API dynamically. This gives us an idea how our API is going to be. It changes dynamically as our design changes:

Image title

We can create and design our APIs easily by adding different resources with different methods like GETPOSTPUTDELETE, etc., and it can be designed very easily with a palette available for the RAML tags:

Image title

Testing Our API

At this point we are ready to test the design we created in our RAML using the dynamic API console. In the API console we can see the design and structure of our API we created:

Image title

We just need to click the button Make an API request to get the interface where we can test the API.

Here we can see we’ve got the interface and in the place of the Query parameter input box we will place our parameter and then will hit the GET button as follows:

Image title

And at the end we will get the mock status message. This API console window is extremely helpful to check out the API design we just created:

Image title

For now we have designed a simple API with a GET method. We can add other resources, methods, parameters, headers with the API to meet our requirements and standards. We can also add other RAML tags like documentation, traits, securitySchemas, etc. in it to add more description and other features like security and reusable for our API.


This was a small demonstration of setting up our api-workbench IDE and designing our RAML file for creating and consuming RESTful APIs. This IDE will help us in bringing a modern and flexible development environment to design and structure our API based on a RAML specification (for both 0.8 and upcoming 1.0). It helps the API designer and the developer to manage the full API lifecycle in a simple and easy way.

Hope you like the post and please do share your feedback and experiences in the below section for comments after using the IDE.
