Many of the NXP OpenSDA bootloaders are vulnerable to Windows 8.x or Windows 10. Write accesses of Windows can confuse the factory bootloader and make the debug firmware and bootloader useless. In this post, I show how to recover the bootloader using MCUXpresso IDE and the P&E Universal Multilink.

Using P&E Multilink Universal to restore the OpenSDA Bootloader on NXP FRDM-K22F Board

Using P&E Multilink Universal to restore the OpenSDA Bootloader on NXP FRDM-K22F Board

In this post, I show how to re-program the OpenSDA V2.x bootloader with the MCUXpresso IDE V10.0.2 using the P&E Universal Multilink. A JTAG/SWD probe has to be used. It is not possible to reflash and fix the OpenSDA bootloader on the Kinetis K20 without it.

As the board, I’m using the NXP FRDM-K22F board.

Older OpenSDA v1.x (e.g. FRDM-KL25Z) cannot be updated, as the bootloader on these boards use a closed bootloader that cannot be re-programmed.

Bootloader Firmware

The matching bootloader and firmware for your board can be found on http://www.nxp.com/opensda.

The FRDM-K64F board was the first one with an open bootloader (OpenSDA V2.0), and the debug firmware application starts at address 0x5000.

Later boards (as the FRDM-K22F) are using OpenSDA V2.1, where the application starts at address 0x8000.

Both bootloaders expose the Windows 8.x/10 problem. What fixed it for me was using OpenSDA 2.2 Daplink BOOTLOADER for K20DX.bin (Application Base address at 0x8000) on GitHub.

Converting the Bootloader

Because the P&E debugger loader cannot (yet?) load bin (binary) files, we have to convert the file into an S19/S-Record, which is supported. There are multiple ways to do this. One is using the GNU binary utilities, see https://mcuoneclipse.com/2014/08/03/converting-s19-files-into-binary-files-with-gnu-objcopy/.

Below is an example command line (update for your file names):

arm-none-eabi-objcopy.exe --input-target=binary --output-target=srec DAPlink.bin DAPlink.s19

 In MCUXpresso IDE, the objcopy program is found in IDE Installation Path>\ide\tools\bin

 I have uploaded the resulting .s19 file to GitHub: https://github.com/ErichStyger/mcuoneclipse/tree/master/OpenSDA/OpenSDA%20V2.2

Creating the Project

To flash the bootloader, the easiest way is to create a dummy project (which CPU does not really matter) with the MCUXpresso IDE.

 The logical CPU choice for that project would be a 50 MHz K20DX128M5, but because NXP has not produce an SDK with all the files for it, we cannot use it. Instead, create a project e.g. for any CPU for which you have an SDK, e.g. the FRDM-K22F itself. We will have to change the MCU in the debug configuration.

Debug Connection

Connect the P&E Multilink Universal to the debug connector of the K20 (OpenSDA). Check your board schematics and make sure the cable is properly oriented. Typically, it is the SWD header close by the K20 MCU.

Using P&E Multilink Universal to restore the OpenSDA Bootloader on NXP FRDM-K22F Board

Using P&E Multilink Universal to restore the OpenSDA Bootloader on NXP FRDM-K22F Board

Launch Configuration

Then use the context menu on the project to create a new P&E debug connection:

New P&E Probe Connection

New P&E Probe Connection

Double-click on the created debug launch configuration to open it. Use the ‘Select Device’ button in the debug tab of the P&E debug connection to set the device to the K20DX128M5, which is used on the board for the OpenSDA circuit:

Selected K20DX128M5 Device

Selected K20DX128M5 device

In the debug configuration, instead of using the normal .axf, specify the .s19 file. In the example below, I have added that .s19 file to the root folder of the project.

Specified S19 file

Specified S19 file

 I cannot use the ‘Search Project…’ or ‘Browse…’ buttons. Enter the file name directly. Make sure it matches the correct file and path.

Save and close that dialog.

Flashing the S19 File

To download the file to the K20DX128M5, use the ‘Debug as’ context menu on the launch the configuration we have modified:

Debugging with Launch Configuration

Debugging with Launch Configuration

That should download the S19 to the board. The debug session does not show anything useful (because we are debugging with a binary S19 file with no source or debug information), so we can end the debug session.

Terminating Debug Session

Terminating Debug Session

Checking Bootloader Version

Power-on the board with the reset button pressed. The device should enumerate as DAPLINKBOOT device, and the DETAILS.TXT on it should show this:

# DAPLink Firmware - see https://mbed.com/daplink
Unique ID: 0000000026294e45001a000e58a9001d3ee1000097969900
HIC ID: 97969900
Auto Reset: 0
Automation allowed: 1
Daplink Mode: Bootloader
Bootloader Version: 0241
Git SHA: be5afd34db2efe1e08d72fa23b3a68ab2625d9a3
Local Mods: 1
USB Interfaces: MSD
Bootloader CRC: 0x439c8da1
Interface CRC: 0x2e72072e

With the bootloader restored on the board, you can now load the debug firmware (e.g. from SEGGER or P&E, available from http://www.nxp.com/opensda.


It is easy to update the NXP OpenSDA V2.x bootloader with a DAPLink one. This fixes the Windows 8.x/10 problem, which can make the bootloader and debug application useless. All that I need is the binary/s19 file plus a JTAG/SWD debug probe. As the P&E debug connection knows .elf/.axf and S19 files, I have to convert the binary (.bin) into an S19 file first, then specify it in the debug connection, using the K20DX128M5 as a device. With this, I can recover the OpenSDA bootloader.

 The above approach to use a dummy project and then point to the S-Record/S19 file of course can be used for a ‘normal’ project binary too.

Happy Recovering!
