In my previous article, I showed you how to use a VPN software solution like OpenVPN to create a secure tunnel to your AWS private resources. In this post, I will walk you through step by step to set up a secure bridge to your remote AWS VPC subnets from your home network with a Raspberry Pi as a Customer Gateway.

Image title

To get started, find your home router's public-facing IP address:

Image title

Next, sign into the AWS Management Console, navigate to the VPC dashboard and create a new VPN Customer Gateway:

Image title

Next, create a Virtual Private Gateway:

Image title

And attach it to the target VPC:

Image title

Then, create a VPN Connection with the Customer Gateway and the Virtual Private Gateway:

Image title

Note: Make sure to add your home CIDR subnet to the Static IP Prefixes section.

Once the VPN Connection is created, click on the “Tunnel Details” tab. You should see two tunnels for redundancy:

Image title

It may take a few minutes to create the VPN connection. When it’s ready, select the connection and choose "Download Configuration." Then, open the configuration file and write down your pre-shared-key and tunnel IP:

tunnel-group 52.47.119.151 type ipsec-l2l
tunnel-group 52.47.119.151 ipsec-attributes
   pre-shared-key irCAIDE1NFxyOiE4w49ijHfPMjTW9rL6


I used a Raspberry Pi 3 (Quad Core CPU 1.2 GHz, 1 GB RAM) with Raspbian, with SSH server enabled (default username & password: pi/raspberry). You can log in and start manipulating the Pi:

Image title

IPsec kernel support must be installed. Therefore, you must install openswan on your Pi:

sudo apt-get install -y openswan lsof


Update the /etc/ipsec.conf file as below:

version 2.0     # conforms to second version of ipsec.conf specification

# basic configuration
config setup
        # Enable core dumps (might require system changes, like ulimit -C)
        dumpdir=/var/run/pluto/
        # NAT-TRAVERSAL support, see README.NAT-Traversal
        nat_traversal=yes
        virtual_private=
        # OE is now off by default. Uncomment and change to on, to enable.
        oe=off
        # which IPsec stack to use. auto will try netkey, then klips then mast
        protostack=netkey

include /etc/ipsec.d/*.conf


Create a new IPsec Connection in /etc/ipsec.d/home-to-aws.conf :

conn home-to-aws
 type=tunnel
 authby=secret
 #left=%defaultroute
 left=192.168.1.81
 leftid=89.95.X.Y
 leftnexthop=%defaultroute
 leftsubnet=192.168.0.0/16
 right=52.47.119.151
 rightsubnet=10.0.0.0/16
 pfs=yes
 auto=start


  • left: Your Raspberry Pi private IP.
  • leftid: Your home router public-facing IP.
  • leftsubnet: CIDR of your home subnet.
  • right: Virtual Private Gateway tunnel IP.
  • rightsubnet: CIDR of your VPC.

Add the tunnel pre-shared key to /var/lib/openswan/ipsec.secrets.inc:

89.95.X.Y 52.47.119.151 : PSK "irCAIDE1NFxyOiE4w49ijHfPMjTW9rL6"


To enable the IPv4 forwarding, edit /etc/sysctl.conf, and ensure the following lines are uncommented:

net.ipv4.ip_forward=1
net.ipv4.conf.all.accept_redirects = 0
net.ipv4.conf.all.send_redirects = 0
net.ipv4.conf.default.send_redirects = 0
net.ipv4.conf.default.accept_redirects = 0


Run sysctl -p to reload it. Then, restart IPsec:

service ipsec restart


Verify if the service is running correctly:

Image title

If you go back to your AWS Dashboard, you should see the 1st tunnel status changed to UP:

Image title

Add a new route entry that forwards traffic to your home subnet through the VPN Gateway:

Image title

Note: Follow the same steps above to set up the 2nd tunnel for resiliency and high availability of VPN connectivity.

Launch an EC2 instance in the private subnet to verify the VPN connection:

Image title

Allow SSH only from your home gateway CIDR:

Image title

Connect via SSH using the instance private IP address:

Image title

Image title

Congratulations! You can now connect securely to your private EC2 instances.

To take it further and connect from other machines in the same home network, add a static route as described below.

Windows:

route add 10.0.0.0 MASK 255.255.0.0 192.168.1.81

Image title

Linux:

sudo up route add -net 10.0.0.0 netmask 255.255.0.0 gw 192.168.31.232


Mac OS X:

sudo route -n add 10.0.0.0/16 192.168.31.232


Test it out:

Image title
