In this blog, we are going to embark the journey of how to setup the Hadoop Multi-Node Cluster in a distributed environment. So let's not waste any time! Here are steps you need to perform.

Prerequisite:

  1. Download & install Hadoop for local machine (Single Node Setup) from

    http://hadoop.apache.org/releases.html – 2.7.3

    Use java: jdk1.8.0_111

  2. Download Apache Spark from

    http://spark.apache.org/downloads.html

    Choose Spark release: 1.6.2

Mapping the Nodes

First of all, we have to edit hosts file in /etc/ folder on all nodes, specify the IP address of each system followed by their host names.

# vi /etc/hosts
 enter the following lines in the /etc/hosts file.
 192.168.1.xxx hadoop-master
 192.168.1.xxx hadoop-slave-1
 192.168.56.xxx hadoop-slave-2

Passwordless Login Through ssh

Then we need to setup ssh passwordless login. For this, we need to Configure Key Based Login.

Setup ssh in every node such that they can communicate with one another without any prompt for a password.

# su hduser
 $ ssh-keygen -t rsa
 $ ssh-copy-id -i ~/.ssh/id_rsa.pub hduser@hadoop-master
 $ ssh-copy-id -i ~/.ssh/id_rsa.pub hduser@hadoop-slave-1
 $ ssh-copy-id -i ~/.ssh/id_rsa.pub hduser@hadoop-slave-2

Note: ssh folder should have permission:  700 & authorised_key should have 644  and hduser should have 755 permission in both master & slaves. (This is very important as I wasted a lot of my time trying to figure this out.)

Set up Java Environment for Master and Slave

Folder structure for both Master and Slave must be the same.

Extract your java in /home/hduser/software and set the path in hduser’s .bashrc as:

export JAVA_HOME=/home/hduser/software/jdk1.8.0_111

Configuring Hadoop

  • Install Hadoop in /usr/local
  • Set $HADOOP_HOME in bashrc as:
export HADOOP_HOME=/usr/local/hadoop
export PATH=$PATH:$HADOOP_HOME/bin
  • Create a directory named hadoop_data in opt folder and dfs in $HADOOP_HOME
  • Inside dfs create a directory called name and inside name create a directory named data
  • The permissions for name and dfs should be 777.
  • Make sure that hadoop_data folder in opt folder is owned by hduser and its permissions should be 777
  • Your core-site.xml file should look like:
<configuration>
<property>
<name>hadoop.tmp.dir</name>
<value>/opt/hadoop_data</value>
<description>directory for hadoop data</description>
</property>
<property>
<name>fs.default.name</name>
<value>hdfs://hadoop-master:54311</value>
<description> data to be put on this URI</description>
</property>
<property>
<name>fs.defaultFS</name>
<value>hdfs://hadoop-master:54311</value>
<description>Use HDFS as file storage engine</description>
</property>
<property>
<name>dfs.permissions</name>
<value>false</value>
</property>
</configuration>
  • Your hdfs-site.xml file should look like:
<configuration>
<property>
<name>dfs.replication</name>
<value>1</value>
</property>
<property>
<name>dfs.data.dir</name>
<value>/usr/local/hadoop/dfs/name/data</value>
<final>true</final>
</property>
<property>
<name>dfs.name.dir</name>
<value>/usr/local/hadoop/dfs/name</value>
<final>true</final>
</property>
</configuration>
  • Your mapred-site.xml should look like:
<configuration>
 <property>
 <name>mapred.job.tracker</name>
 <value>hadoop-master:9001</value>
 </property>
</configuration>

  • Your  yarn-site.xml should look like:
<configuration>
<!-- Site specific YARN configuration properties -->
<property>
 <name>yarn.nodemanager.aux-services</name>
 <value>mapreduce_shuffle</value>
</property>
<property>
 <name>yarn.resourcemanager.scheduler.address</name>
 <value>hadoop-master:8030</value>
</property>
<property>
 <name>yarn.resourcemanager.address</name>
 <value>hadoop-master:8032</value>
</property>
<property>
 <name>yarn.resourcemanager.webapp.address</name>
 <value>hadoop-master:8088</value>
</property>
<property>
 <name>yarn.resourcemanager.resource-tracker.address</name>
 <value>hadoop-master:8031</value>
</property>
<property>
 <name>yarn.resourcemanager.admin.address</name>
 <value>hadoop-master:8033</value>
</property>
</configuration>

Now, set JAVA_HOME in hadoop-env.sh

export JAVA_HOME=/home/hduser/software/jdk1.8.0_111

Next, in the master node, set slaves IP address in $HADOOP_HOME/etc/hadoop/slaves file

hadoop-master
hadoop-slave-1
hadoop-slave-2
Remove localhost entry from the above file.

Important Note: Location of Hadoop and Spark should be same in master and slaves.

Configuring Spark

Install Spark in /home/hduser/software

  • Set your $SPARK_HOME in bashrc as:

export SPARK_HOME=/home/hduser/software/spark-1.6.2-bin-hadoop2.6

Add the following line in spark-env.sh

 export SPARK_MASTER_IP=192.168.2.xxx //IP address of master
  • Copy your hdfs-site.xml and core-site.xml file from $HADOOP_HOME/etc/hadoop and put it in $SPARK_HOME/conf folder.

  • In master node, add IP addresses of slaves in slaves file located in $SPARK_HOME/conf.

  • To run Hadoop, go to $HADOOP_HOME in the master and run:  hadoop namenode -format
  • Next, change directory by executing the command: cd $HADOOP_HOME/sbin
  • Run:   start-dfs.sh  followed by  start-yarn.sh

Important Notes:

  1. Start-dfs.sh  will start NameNode, SecondaryNamenode, DataNode on master and DataNode on all slaves node.

  2. Start-yarn.sh  will start NodeManager, ResourceManager on the master node and NodeManager on slaves.

  3. Perform  Hadoop namenode -format  only once otherwise you will get an incompatible cluster_id exception. To resolve this error clear temporary data location for datanode i.e, remove the files present in $HADOOP_HOME/dfs/name/data folder.

Use the following command: rm -rf filename

  • Start spark. Go to $SPARK_HOME/sbin and run start-all.sh
  • Start thrift server and log into beeline using hduser as username and password.
  • To start the thrift server use the following command inside $SPARK_HOME

 ./bin/spark-submit –master spark master IP –conf spark.sql.hive.thriftServer.singleSession=true –class pathOfClassToRun pathToYourApplicationJar hdfs://hadoop-master:54311/pathToStoreLocation

Note:

  • Look for spark master IP in master node at this address- hadoop-master:8080

  • If you face any issue, then refer to the below section.

In case, you spot any of the below issues, see in the Hadoop logs folder located in $HADOOP_HOME/logs

  1. Error for Incompatible cluster ids: Clear temporary data location for datanode

  2. Failed to start database: if you face this problem, then remove metastore _db: org.apache.spark.sql.hive.client.IsolatedClientLoader$$anon$1@7962a746 : remove metastore_db/dbex.l

  3. HiveSQLException: org.apache.hadoop.security.AccessControlException: Permission denied: user=anonymous, access=WRITE : Login to beeline with user as hduser and password as hduser
