Spark PairRDDFunctions—AggregateByKey

Learn about using the Spark framework to easily work with key value pairs and how to group values by key.

· Java Zone

Navigate the Maze of the End-User Experience and pick up this APM Essential guide, brought to you in partnership with CA Technologies

One of the great things about the Spark Framework is the amount of functionality provided out of the box. There is a class aimed exclusively at working with key-value pairs, the PairRDDFunctions class. When working data in the key-value format one of the most common operations to perform is grouping values by key. The PairRDDFunctions class provides a groupByKey function that makes grouping by key trivial. However, groupByKey is very expensive and depending on the use case, better alternatives are available. In a groupByKey call, all key-value pairs will be shuffled accross the network to a reducer where the values are collected together. In some cases the groupByKey is merely a starting point to perform additional operations (sum, average) by key. In other cases, we need to collect the values together in order to return a different value type. Spark provides some alternatives for grouping that can provide either a performance improvement or ease the ability to combine values into a different type. The point of this post is to consider one of these alternate grouping functions.

Alternative Grouping Functions

While there are many funtions in the PairRDDFunctions class, today we are going to focus on aggregateByKey. The aggregateByKey function is used to aggregate the values for each key and adds the potential to return a differnt value type.


The aggregateByKey function requires 3 parameters:

  1. An intitial ‘zero’ value that will not effect the total values to be collected. For example if we were adding numbers the initial value would be 0. Or in the case of collecting unique elements per key, the initial value would be an empty set.
  2. A combining function accepting two paremeters. The second paramter is merged into the first parameter. This function combines/merges values within a partition.
  3. A merging function function accepting two parameters. In this case the paremters are merged into one. This step merges values across partitions.

As an example let’s collect unique values per key. Think of this as an alternative of calling someRDD.groupByKey().distinct() Here’s the code:

val keysWithValuesList = Array("foo=A", "foo=A", "foo=A", "foo=A", "foo=B", "bar=C", "bar=D", "bar=D")
val data = sc.parallelize(keysWithValuesList)
//Create key value pairs
val kv = data.map(_.split("=")).map(v => (v(0), v(1))).cache()

val initialSet = mutable.HashSet.empty[String]
val addToSet = (s: mutable.HashSet[String], v: String) => s += v
val mergePartitionSets = (p1: mutable.HashSet[String], p2: mutable.HashSet[String]) => p1 ++= p2

val uniqueByKey = kv.aggregateByKey(initialSet)(addToSet, mergePartitionSets)

You will notice we are using mutable hashsets in our example. The reason for using mutable collections is to avoid the extra memeory overhead associated with returning new collections each time we add values to or merge collections. (This is explicity stated in the PairRDDFunctions documentation). While using aggregateByKey is more verbose, if your data has many values but only a few are unique this approach could lead to performance improvements.

For our second example, we’ll do a sum of values by key, which should help with performance as less data will be shuffled accross the network. We provide 3 different parameters to our aggregateByKey function. This time we want to count how many values we have by key regardless of duplicates.

val keysWithValuesList = Array("foo=A", "foo=A", "foo=A", "foo=A", "foo=B", "bar=C", "bar=D", "bar=D")
val data = sc.parallelize(keysWithValuesList)
//Create key value pairs
val kv = data.map(_.split("=")).map(v => (v(0), v(1))).cache()

val initialCount = 0;
val addToCounts = (n: Int, v: String) => n + 1
val sumPartitionCounts = (p1: Int, p2: Int) => p1 + p2

val countByKey = kv.aggregateByKey(initialCount)(addToCounts, sumPartitionCounts)

For anyone who has worked with hadoop, this functionality is analogous to using combiners.


Running our examples yields the following results:

Aggregate By Key unique Results
bar -> C,D
foo -> B,A
Aggregate By Key sum Results
bar -> 3
foo -> 5


This concludes our quick tour of the aggregateByKey function. While the use of 3 functions can be a little unwieldly, it is certainly a good tool to have at your disposal. In subsequent posts we will continue coverage of methods in Spark’s PairRDDFunctions class


Thrive in the application economy with an APM model that is strategic. Be E.P.I.C. with CA APM.  Brought to you in partnership with CA Technologies.

spark ,spring framework ,Java

Published at DZone with permission of Bill Bejeck, DZone MVB. See the original article here.

Opinions expressed by DZone contributors are their own.
