The Dreaded 418 Error: Monitoring HTCPCP Microservices in IoT Deployments
Microservices are great for scale but post special problems for monitoring. At HTCPCP-enabled devices become more prevalent, let's tackle the challenge.
Join the DZone community and get the full member experience.Join For Free
The Internet of Things is a growing segment of the technology market today. IoT installations can use a variety of popular protocols, including HTTP, HTTP/2, MQTT, and CoAP. We’ve covered the use of our products with HTTP protocols in many blog posts, and MQTT use cases in two recent posts:
- NGINX Plus for the IoT: Load Balancing MQTT
- NGINX Plus for the IoT: Encrypting and Authenticating MQTT Traffic
But NGINX and NGINX Plus are equally suited for special‑purpose protocols such as the Hyper Text Coffee Pot Control Protocol (HTCPCP). This is the first of series of blog posts where we plan to cover development, deployment, and monitoring of HTCPCP applications.
Installation of HTCPCP‑enabled devices is steadily growing every year, with a seasonal spike at the beginning of April.
HTCPCP architecture in a large‑scale installation is different from a standard web application. In a standard web application, we usually see a lightweight client-side communicating with a heavier set of backend applications. The architecture of HTCPCP applications is fundamentally different. In this case, the HTCPCP server is designed to work on the device (namely, a connected coffee pot) and the clients connect to these machines using either special command‑line clients (modified
curl commands) or a proxy infrastructure.
The microservices approach fits HTCPCP deployments very well. Service discovery, load balancing, cloud deployments, and API gateways are all applicable here.
The main parts of a microservices architecture for HTCPCP are DBAs, DPI, and USB.
The Distributed Backend Applications (DBAs) are usually deployed on the coffee‑making devices, and can be implemented in various languages and application platforms. There are multiple commercial and open source examples, including:
- An implementation on Python for Raspberry Pi
- A high‑performance implementation in C
The Distributed Proxy Infrastructure (DPI) in our HTCPCP deployment is NGINX or NGINX Plus instances embedded in the IoT devices. DBAs usually don’t require a DPI in a smaller installation. In a large enterprise, however, the following features are crucial for reliable service in the HTCPCP deployment:
- Rate limiting and overflow protection
- Health checks
- Traffic monitoring and logging
- Traffic encryption and security controls
NGINX Plus is the most popular DPI in enterprise‑class HTCPCP deployments.
In a development system or small‑scale installation (up to five coffee machines), the clients can connect to a DPI instance or even directly to the DBA. In larger enterprises, however, we usually see a Unified Scalable Backend (USB) developed and deployed either on premises or as a scalable cloud service. The USBs usually perform functions like:
- Coffee machine discovery, which is similar to service discovery in conventional microservices (read more about service discovery on our blog).
- Protocol conversion from HTTP to HTCPCP
- Web interface
- End‑user authentication and access control
Most highly loaded web applications today are using NGINX and NGINX Plus as a load balancer, reverse proxy, and cache, and HTCPCP USB is no exception.
Monitoring HTCPCP Applications
A large‑scale installation of HTCPCP requires a set of monitoring tools that have to be more sophisticated than a generic monitoring system for a simple microservice. In an HTCPCP deployment, we see more protocol conversions and more different types of devices where the monitoring agent needs to be deployed. In addition, organizations impose tight SLAs for preparation of a cup of coffee, because this directly impacts the productivity of their employees.
The Infrastructure Department for IoT (IDIoT) at every company is constantly looking for ways to effectively monitor HTCPCP installations.
At NGINX, we developed NGINX Amplify, the monitoring and configuration assistance system that suits an HTCPCP deployment just as well as a complex HTTP deployment.
To start using NGINX Amplify in your infrastructure, you need to install the NGINX Amplify Agent together with your NGINX instance on all DPIs and USBs. The beauty of our solution starts with the fact that it’s absolutely agnostic to the underlying architecture. While USBs might be located on large enterprise servers or containers in the cloud, you usually own the hardware that runs the DBAs and DPIs. NGINX and NGINX Amplify fit equally well in the cloud and on your hardware.
In the screenshot below you can see a small portion of NGINX Inc.’s own HTCPCP installation, with multiple machines connected through various instances of NGINX and NGINX Plus.
NGINX DevOps engineers are dedicated to providing infrastructure that is resilient to any issues with electricity, the network, or grind inconsistency. In our recent blog post, we described how the advanced graphs and dashboards help our own infrastructure team to maintain the highest standards of uptime and reliability.
In addition to standard HTTP monitoring, you can use NGINX Amplify to monitor the specific issues that arise only in an HTCPCP deployment.
NGINX and NGINX Plus produce logs which can be configured to report a lot of internal data. The NGINX Amplify Agent can read those logs, or receive them using the syslog interface. As an example, let’s monitor one of the most devastating status codes that can affect your HTCPCP deployment:
Teapot. This status code is returned if the type of your IoT device is mismatched: the DBA produces tea, but the USB requested a coffee drink.
Fortunately, even in a caffeine‑deprived state it’s easy to create the appropriate NGINX Amplify filter:
- Create a new graph in your custom dashboard
- Select the metric
- Create a filter for
418, optionally with additional criteria
Once the filtered graph is created, the agents start to apply this filter to the logs, and report the resulting metrics to NGINX Amplfiy Cloud.
The following screenshot shows the daily rate of
418 errors across a large corporate office in Europe.
Learn more about NGINX Amplify filters and dashboards on our blog.
