Tutorial: How to Run SQL Queries With Presto on Amazon Redshift

Presto has evolved into a unified SQL engine on top of cloud data lakes for both interactive queries as well as batch workloads with multiple data sources. This tutorial will show how to run SQL queries with Presto (running on Kubernetes) on AWS Redshift.

Presto's Redshift connector allows querying the data stored in an external Amazon Redshift cluster. This can be used to join data between different systems like Redshift and Hive, or between two different Redshift clusters.

Step 1: Setup a Presto Cluster With Kubernetes

Set up your own Presto cluster on Kubernetes using these instructions or you can use Ahana’s managed service for Presto.

Step 2: Setup an Amazon Redshift Cluster

Create an Amazon Redshift cluster from AWS Console and make sure it’s up and running with the dataset and tables.

Below screen shows Amazon Redshift cluster – “redshift-presto-demo”

Further, JDBC URL from Cluster is required to set up a redshift connector with Presto.

You can skip this section if you want to use your existing Redshift cluster, just make sure your redshift cluster is accessible from Presto because AWS services are secure by default. So even if you have created your Amazon Redshift cluster in a public VPC, the security group assigned to the target Redshift cluster can prevent inbound connections to the database cluster. In simple words, the Security Group settings of the Redshift database play a role of a firewall and prevent inbound database connections over port 5439. Find the assigned Security Group and check its Inbound rules.

If your Presto Compute Plane VPC and data sources are in a different VPC then you need to configure a VPC peering connection.

Step 3: Configure Presto Catalog for Amazon Redshift Connector

Essentially, to configure the Redshift connector, create a catalog properties file in, etc/catalog named, for example, redshift.properties, to mount the Redshift connector as the redshift catalog. Create the file with the following contents, replacing the connection properties as appropriate for your setup:

connection-password=secret
connector.name=redshift
connection-url=jdbc:postgresql://example.net:5439/database
connection-user=root

This is how my catalog properties look:

 my_redshift.properties: |
      connector.name=redshift
      connection-user=awsuser
      connection-password=admin1234
connection-url=jdbc:postgresql://redshift-presto-demo.us.redshift.amazonaws.com:5439/dev

Step 4: Check for available datasets, schemas, and tables, etc and run SQL queries with Presto Client to access the Redshift database

After successfully database connection with Amazon Redshift, You can connect to Presto CLI and run the following queries and make sure that the Redshift catalog gets picked up and perform show schemas and show tables to understand available data.

$./presto-cli.jar --server https://<presto.cluster.url> --catalog bigquery --schema <schema_name> --user <presto_username> --password

IN the below example you can see a new catalog for Redshift Database got initiated called “my_redshift. ”

presto> show catalogs;
   Catalog
-------------
 ahana_hive
 jmx
 my_redshift
 system
 tpcds
 tpch
(6 rows)

Query 20210810_173543_00209_krtkp, FINISHED, 2 nodes
Splits: 36 total, 36 done (100.00%)
0:00 [0 rows, 0B] [0 rows/s, 0B/s]

Further,  you can check all available schemas for your Amazon Redshift from Presto to work with.

presto> show schemas from my_redshift;
       Schema
--------------------
 catalog_history
 information_schema
 pg_catalog
 pg_internal
 public
(5 rows)

Query 20210810_174048_00210_krtkp, FINISHED, 3 nodes
Splits: 36 total, 36 done (100.00%)
0:01 [5 rows, 85B] [4 rows/s, 72B/s]

Here, I have used sample data that comes with the Redshift Cluster setup. I have chosen the schema “public” which is a part of the “dev” Redshift Database.

presto> show tables from my_redshift.public;
  Table
----------
 category
 date
 event
 listing
 sales
 users
 venue
(7 rows)

Query 20210810_185448_00211_krtkp, FINISHED, 3 nodes
Splits: 36 total, 36 done (100.00%)
0:03 [7 rows, 151B] [2 rows/s, 56B/s]

Further, you can explore tables as “sales” in the below example.

presto> select * from my_redshift.public.sales LIMIT 2;
 salesid | listid | sellerid | buyerid | eventid | dateid | qtysold | pricepaid | commission |        saletime
---------+--------+----------+---------+---------+--------+---------+-----------+------------+-------------------------
   33095 |  36572 |    30047 |     660 |    2903 |   1827 |       2 | 234.00    | 35.10      | 2008-01-01 01:41:06.000
   88268 | 100813 |    45818 |     698 |    8649 |   1827 |       4 | 836.00    | 125.40     | 2007-12-31 23:26:20.000
(2 rows)

Query 20210810_185527_00212_krtkp, FINISHED, 1 node
Splits: 18 total, 18 done (100.00%)
0:03 [18.1K rows, 0B] [6.58K rows/s, 0B/s]

Following are some more complex queries you can run against sample data:

presto:public> -- Find top 10 buyers by quantity
            ->SELECT firstname, lastname, total_quantity
            -> FROM   (SELECT buyerid, sum(qtysold) total_quantity
            ->         FROM  sales
            ->         GROUP BY buyerid
            ->         ORDER BY total_quantity desc limit 10) Q, users
            -> WHERE Q.buyerid = userid
            -> ORDER BY Q.total_quantity desc;
 firstname | lastname | total_quantity
-----------+----------+----------------
 Jerry     | Nichols  |             67
 Armando   | Lopez    |             64
 Kameko    | Bowman   |             64
 Kellie    | Savage   |             63
 Belle     | Foreman  |             60
 Penelope  | Merritt  |             60
 Kadeem    | Blair    |             60
 Rhona     | Sweet    |             60
 Deborah   | Barber   |             60
 Herrod    | Sparks   |             60
(10 rows)

Query 20210810_185909_00217_krtkp, FINISHED, 2 nodes
Splits: 214 total, 214 done (100.00%)
0:10 [222K rows, 0B] [22.4K rows/s, 0B/s]

presto:public> -- Find events in the 99.9 percentile in terms of all time gross sales.
            -> SELECT eventname, total_price
            -> FROM  (SELECT eventid, total_price, ntile(1000) over(order by total_price desc) as percentile
            ->        FROM (SELECT eventid, sum(pricepaid) total_price
            ->              FROM   sales
            ->              GROUP BY eventid)) Q, event E
            ->        WHERE Q.eventid = E.eventid
            ->        AND percentile = 1
            -> ORDER BY total_price desc;
      eventname       | total_price
----------------------+-------------
 Adriana Lecouvreur   | 51846.00
 Janet Jackson        | 51049.00
 Phantom of the Opera | 50301.00
 The Little Mermaid   | 49956.00
 Citizen Cope         | 49823.00
 Sevendust            | 48020.00
 Electra              | 47883.00
 Mary Poppins         | 46780.00
 Live                 | 46661.00
(9 rows)

Query 20210810_185945_00218_krtkp, FINISHED, 2 nodes
Splits: 230 total, 230 done (100.00%)
0:12 [181K rows, 0B] [15.6K rows/s, 0B/s]

Step 5: Run SQL query to join data between different systems like Redshift and Hive

Another great use case of Presto is Data Federation. In this example, I will join the Apache Hive table with the Amazon Redshift table and run the JOIN query to access both tables from Presto.

Here, I have two catalogs “ahana_hive” for Hive Database and “my_redshift” for Amazon Redshift and each database has my_redshift.public.users

 and ahana_hive.default.customer table respectively within their schema.

Following the very simple query to join these tables, the same way you join two tables from the same database.

presto> show catalogs;
presto> select * from ahana_hive.default.customer;
presto> select * from my_redshift.public.users;
presto> Select * from ahana_hive.default.customer x  join my_redshift.public.users y on x.nationkey = y.userid;

And now you should be able to query Amazon Redshift using Presto!
