Tutorial: Presto + Alluxio + Hive Metastore on Your laptop in 10 Minutes

This tutorial guides users to set up a stack of Presto, Alluxio, and Hive Metastore on their local server. Additionally, it demonstrates how to use Alluxio as the caching layer for Presto queries. In this stack, Presto is the SQL Engine to plan and execute queries, Alluxio is the data orchestration layer to cache hot tables for Presto, and Hive Metastore is the catalog service for Presto to read table schema and location information.

Step1: Download and Launch Alluxio

Go to Alluxio download page, select the latest version (e.g., 2.0.1 when this blog is written), download, and unpack the tarball.

$ tar -xzf alluxio-2.0.1-bin.tar.gz
$ cd alluxio-2.0.1

Start a new deployment with a local master and local worker:

$ bin/alluxio-start.sh local -f

Mount an S3 bucket which has example input data for this tutorial to Alluxio file system. Note that this S3 bucket is a public bucket accessible to all AWS users.

$ bin/alluxio fs mount --readonly /example \
   s3://apc999/presto-tutorial/example-reason/

You may also like: Four Ways to Write to Alluxio.

Step 2: Start Hive Metastore

If it is the first time for you to launch Hive Metastore, initialize a new Metastore

$ ${HIVE_HOME}/bin/schematool -dbType derby -initSchema

Edit ${HIVE_HOME}/conf/hive-env.sh to include Alluxio client jar on the Hive classpath, so Hive Metastore can access files stored on Alluxio.

export HIVE_AUX_JARS_PATH=/path/to/alluxio/client/alluxio-2.0.1-client.jar

Start a Hive Metastore which will run in the background and listen on port 9083 (by default).

$ ${HIVE_HOME}/hcatalog/sbin/hcat_server.sh start

One can check the Hive Metastore logs at ${HIVE_HOME}/hcatalog/var/log/

Step 3: Launch Presto Server

Goto Presto server installation and make a symbol link to make Alluxio client available for Presto Hive Connector.

$ cd ${PRESTO_HOME}
$ ln -s /path/to/alluxio/client/alluxio-2.0.1-client.jar \
  plugin/hive-hadoop2/alluxio-client.jar

Edit etc/config.properties file to include

coordinator=true
node-scheduler.include-coordinator=true
http-server.http.port=8080
discovery-server.enabled=true
discovery.uri=http://localhost:8080

Also edit etc/catalog/hive.properties to point to the Hive Metastore service we just started.

connector.name=hive-hadoop2
hive.metastore.uri=thrift://localhost:9083

Run the Presto server:

$ ./bin/launcher run

Step 4: Launch a Presto CLI and Run Queries

Start a Prest CLI connection to the server started in previous step.

$ ./presto --server localhost:8080  --catalog hive --debug
presto> USE default;
USE

Create a new table based on the file mounted in Alluxio:

presto:default> DROP TABLE IF EXISTS reason;
DROP TABLE
presto:default> CREATE TABLE reason (
  r_reason_sk bigint,
  r_reason_id varchar,
  r_reason_desc varchar
) WITH (
  external_location = 'alluxio://localhost:19998/example',
  format = 'PARQUET'
);
CREATE TABLE

Scan the newly create table:

presto:default> SELECT * FROM reason;
 r_reason_sk |   r_reason_id    |                r_reason_desc
-------------+------------------+---------------------------------------------
           1 | AAAAAAAABAAAAAAA | Package was damaged
           4 | AAAAAAAAEAAAAAAA | Not the product that was ordred
           5 | AAAAAAAAFAAAAAAA | Parts missing
           6 | AAAAAAAAGAAAAAAA | Does not work with a product that I have
           7 | AAAAAAAAHAAAAAAA | Gift exchange
          16 | AAAAAAAAABAAAAAA | Did not fit
          17 | AAAAAAAABBAAAAAA | Wrong size
          18 | AAAAAAAACBAAAAAA | Lost my job
          19 | AAAAAAAADBAAAAAA | unauthoized purchase
          20 | AAAAAAAAEBAAAAAA | duplicate purchase
          21 | AAAAAAAAFBAAAAAA | its is a boy
          22 | AAAAAAAAGBAAAAAA | it is a girl
          23 | AAAAAAAAHBAAAAAA | reason 23
          24 | AAAAAAAAIBAAAAAA | reason 24
          25 | AAAAAAAAJBAAAAAA | reason 25
          26 | AAAAAAAAKBAAAAAA | reason 26
          27 | AAAAAAAALBAAAAAA | reason 27
          28 | AAAAAAAAMBAAAAAA | reason 28
          29 | AAAAAAAANBAAAAAA | reason 29
          30 | AAAAAAAAOBAAAAAA | reason 31
          31 | AAAAAAAAPBAAAAAA | reason 31
          32 | AAAAAAAAACAAAAAA | reason 32
          33 | AAAAAAAABCAAAAAA | reason 33
          34 | AAAAAAAACCAAAAAA | reason 34
          35 | AAAAAAAADCAAAAAA | reason 35
           2 | AAAAAAAACAAAAAAA | Stopped working
           3 | AAAAAAAADAAAAAAA | Did not get it on time
           8 | AAAAAAAAIAAAAAAA | Did not like the color
           9 | AAAAAAAAJAAAAAAA | Did not like the model
          10 | AAAAAAAAKAAAAAAA | Did not like the make
          11 | AAAAAAAALAAAAAAA | Did not like the warranty
          12 | AAAAAAAAMAAAAAAA | No service location in my area
          13 | AAAAAAAANAAAAAAA | Found a better price in a store
          14 | AAAAAAAAOAAAAAAA | Found a better extended warranty in a store
          15 | AAAAAAAAPAAAAAAA | Not working any more
(35 rows)

After a few seconds, you will see the following output:

Query 20191012_010912_00006_9jx7r, FINISHED, 1 node
http://localhost:8080/ui/query.html?20191012_010912_00006_9jx7r
Splits: 17 total, 17 done (100.00%)
CPU Time: 0.4s total,    83 rows/s, 2.35KB/s, 62% active
Per Node: 0.4 parallelism,    37 rows/s, 1.04KB/s
Parallelism: 0.4
Peak Memory: 0B

0:01 [35 rows, 1002B] [37 rows/s, 1.04KB/s]

Summary

In this tutorial, we demonstrated how to run setup Presto, Hive Metastore and Alluxio to run SQL queries. Feel free to ask questions at our Alluxio community slack channel.
