Using Spring Data With Apache Camel

DZone's Guide to

Using Spring Data With Apache Camel

With Spring Data, you can save quite a bit of time by creating smart DAOs without any code. Here's a breakdown of using Spring Data with Apache Camel, complete with JPA and spring-data dependencies.

· Integration Zone
Free Resource

Learn how API management supports better integration in Achieving Enterprise Agility with Microservices and API Management, brought to you in partnership with 3scale

Spring Data saves you a lot of time by creating smart DAOs that you can basically get for free without writing any code. It basically follows the Repository Pattern from Eric Evans’ DDD book and treats entities as collections. It has a great convention that allows you to specify criteria for complex queries, and even leverage the JPA Criteria API or the QueryDSL fluent APIs for even more complex queries/specifications. The best part is the abstraction works not just for JPA, but many other providers. There are some great examples using Spring Data within the spring ecosystem like Spring Boot but some times you want to use it outside the magical, enchanted world of Spring Boot.

And if you’re doing any serious system integration, you’re probably also using Apache Camel, so in the following quick blog (promise) I’ll show you the salient parts you’ll need when using with Camel… however, there’s nothing too special here. We basically deconstruct some of the magic that Spring Boot otherwise takes care of for you and allows you to understand the constituent pieces that will be necessary to have in place (and this is true if running Tomcat, Dropwizard, Wildfly, or any container).

The sample code for this is located here at my github for some code we were working on.

First step, you’ll want the JPA and spring-data dependencies!

<!-- spring data + JPA -->


This will prep the classpath for us, which should include a JPA API and the entity managers for the provider we’ll use.

Next, we should add the following to the spring-context/bean-factory:

<bean id="dataSource" class="org.apache.commons.dbcp.BasicDataSource" destroy-method="close">
  <property name="driverClassName" value="org.apache.derby.jdbc.EmbeddedDriver"/>
  <property name="url" value="jdbc:derby:memory:orders;create=true"/>
  <property name="username" value=""/>
  <property name="password" value=""/>

<bean id="sessionFactory" class="org.springframework.orm.hibernate4.LocalSessionFactoryBean">
  <property name="dataSource" ref="dataSource"/>

<bean id="entityManagerFactory" class="org.springframework.orm.jpa.LocalContainerEntityManagerFactoryBean">
  <property name="dataSource" ref="dataSource"/>
  <property name="persistenceXmlLocation" value="classpath:/META-INF/persistence.xml"/>
  <property name="persistenceUnitName" value="sample"/>
  <!-- spring based scanning for entity classes>-->
  <property name="packagesToScan" value="org.jboss.fuse.examples.rest"/>

<bean id="transactionManager"
  <property name="sessionFactory" ref="sessionFactory"/>
  <property name="dataSource" ref="dataSource"/>

This is all run of the mill Spring ORM stuff; nothing too fabrcy here, but is the boilerplate stuff that spring-data will need.

To use JPA, we’ll also want an persistence.xml file. If you want to use Mongo or something else, refer to that specific spring-data mdoule for how to do that.

<persistence xmlns="http://java.sun.com/xml/ns/persistence"
             xsi:schemaLocation="http://java.sun.com/xml/ns/persistence http://java.sun.com/xml/ns/persistence/persistence_2_0.xsd"
  <persistence-unit name="sample">
      <property name="hibernate.dialect" value="org.hibernate.dialect.DerbyTenSevenDialect"/>

This should give us the foundation for using spring-data! Now, let’s do some fun stuff. We’ll add a Repository that will allow us to do CRUD operations (and more!) against the database:

package org.jboss.fuse.examples.repositories;

import org.jboss.fuse.examples.rest.Organization;
import org.springframework.data.repository.PagingAndSortingRepository;

 * Created by ceposta
 * <a href="http://christianposta.com/blog>http://christianposta.com/blog</a>.
public interface OrganizationRepository extends PagingAndSortingRepository<Organization, Integer> {


We have our repository but we need to tell spring how to find it and apply some magic. So let’s add it to the spring context like this (and have spring scan a package to discover the repository)

<jpa:repositories base-package="org.jboss.fuse.examples.repositories"/>

Note, this will require the appropriate namespaces (assumption is we’re using the spring XML config; java config is also supported but not shown here):

<beans xmlns="http://www.springframework.org/schema/beans"
          http://camel.apache.org/schema/spring http://camel.apache.org/schema/spring/camel-spring.xsd
          http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd
    http://www.springframework.org/schema/data/jpa http://www.springframework.org/schema/data/jpa/spring-jpa.xsd">

Now let’s inject our repository into our own POJO class from which we can use it! Woah, woah… “we haven’t actually written any code to implement this repository” you say… yes that’s true! Spring-data does that for us!

Let’s inject:

<bean id="orgCollection" class="org.jboss.fuse.examples.rest.OrganizationCollection">
  <property name="repository" ref="organizationRepository"/>

Note the name of the repository organizationRepository is created by convention by spring when it scans the package for repositories, but we can still get a hold of it and use it like any other spring bean in the bean factory. Now, let’s use this wrapper class (OrganizationCollection in this case) in our Camel routes:

<route id="findAll">
  <from uri="direct:findAll"/>
  <bean ref="orgCollection" method="findAll"/>

<route id="orgById">
  <from uri="direct:orgById"/>
  <bean ref="orgCollection" method="findById"/>

<route id="paginate">
  <from uri="direct:paginate"/>
  <bean ref="orgCollection" method="findOrganizationWithPagination"/>

Cool! We have 3 separate routes that use our orgCollection pojo (which in turn uses the organizationRepository that leverages spring-data). Let’s take a look at that POJO:

package org.jboss.fuse.examples.rest;

import org.apache.camel.Header;
import org.apache.camel.language.Simple;
import org.jboss.fuse.examples.repositories.OrganizationRepository;
import org.springframework.data.domain.PageRequest;

public class OrganizationCollection {

    private OrganizationRepository repository;

    public Organization insertNewOrganization(@Simple("body.org_id") Integer id, @Simple("body.org_name") String name) {
        Organization org = new Organization(id, name);
        return repository.save(org);

    public Iterable<Organization> findAll(){
        return repository.findAll();

    public Iterable<Organization> findOrganizationWithPagination(@Header("pageNumber")int pageNum, @Header("pageSize")int size){
        return repository.findAll(new PageRequest(pageNum, size));

    public Organization findById(@Header("id")int id) {
        return repository.findOne(id);

    public OrganizationRepository getRepository() {
        return repository;

    public void setRepository(OrganizationRepository repository) {
        this.repository = repository;

We inject the OrganizationRepository and use it here to query the data store. Notice the parameters have Apache Camel annotations that extract values from the headers and body to use as parameters.
