Visual Regression with Galen

DZone's Guide to

Visual Regression with Galen

Galen is an open source tool that simplifies layout testing. This tutorial will help users understand Galen's inner workings.

· DevOps Zone
Free Resource

Download “The DevOps Journey - From Waterfall to Continuous Delivery” to learn about the importance of integrating automated testing into the DevOps workflow, brought to you in partnership with Sauce Labs.

Galen is an open source layout testing tool for software applications, which helps us test the look and feel of the application. The idea behind using Galen is to simplify layout testing where we won’t need to manually test an application for UI based issues. Galen can also be used to automate UI regression.

Currently, Galen is a fully functional testing framework with rich reporting and test management system. It supports both Javascript and Java. It has its own syntax called Galen specs for describing the positioning and alignment of elements on a web page. It uses Selenium to interact with the page objects.

Here's a Galen framework tutorial that'll help make sense of the tool, and all the concepts involved.

Responsiveness of a Browser

The framework is designed to test the responsiveness of an application. It is easy to set up Galen to test the responsiveness of an application for different browsers and for multiple devices. Galen initiates a browser and resizes it to a defined resolution which can be passed as a parameter when writing the tests. It can then test the responsiveness according to the specifications defined.

Runs on Cloud and Selenium

Galen has been made flexible enough to run on third-party cloud services such as BrowserStack and Sauce Labs. The tests can also be run using Selenium Grid. This would help save time when running tests on multiple devices.

Installation Prerequisite

For executing Galen, the Java version should be 1.8.

NPM-Based Installation

For NPM based installation, just type in the command sudo npm install -g Galen framework-cli

Manual Installation

Install on OS X and Linux

  • Download the archive from Download Page and extract it in any directory. Go to the extracted directory of Galen and execute the following command: sudo./install.sh
  • To check whether Galen is successfully installed, execute the following command: galen -v.

The above command should print the installed version of Galen within your system.

Configuring Galen

To configure Galen, create a project directory, and inside that, execute the following command: galen config

This will basically create a galen.config file in your project directory, which will contain the configurational parameters for Galen. You need to configure the Chrome Driver for Chrome and the Gecko Driver for Firefox. To execute your tests in headless mode, you can also execute it using PhantomJs.

To configure the drivers, use the following syntax:

$.webdriver.gecko.driver=Drivers/geckodriver
$.webdriver.chrome.driver=Drivers/chromedriver
$.phantomjs.binary.path=Drivers/phantomjs/bin/phantomjs

Nota Bene

In the case of drivers, instead of using the driver executables for Chrome, PhantomJS, and Firefox, you can also install them in your local machine.
Since I am using a Mac, I will be using Homebrew to install the drivers.

1. To execute your tests on Firefox, you will need Gecko Driver. Gecko Driver can be installed by using brew install geckdriver. This will install the latest stable version of Gecko Driver in your system.
2. To execute your tests on Chrome, you will need the Chrome Driver. Chrome Driver can be installed by using brew install chromedriver. This will install the latest stable version of Chrome Driver in your system.
3. To execute your tests headlessly, you will need the PhantomJS driver, which can be installed in your system using brew install phantomjs.

Once this is done you just need to give the path of the driver in your galen.config file. This will look something like this:

$.webdriver.gecko.driver=/usr/local/bin/geckodriver
$.webdriver.chrome.driver=/usr/local/bin/chromedriver
$.phantomjs.binary.path=/usr/local/bin/phantomjs

galen framework tutorial modus operandiModus Operandi

Galen operates in the following manner: it opens a page in a browser, resizes the browser to a specific size, and tests the layout with Galen specs. In case the page is not directly accessible, Galen allows you to perform some operations on the website first. As it is based on Selenium, all operations related to clicking, typing, and injecting client-side JavaScript can be done very easily.

Galen Specs is the language with which the specifications of responsiveness can be defined as per different devices. The following code snippet will give an idea of how easy it is to implement the page specifications using Galen:

= Main section =
header:
height 100px
inside screen 0px top
width 100% of screen/width

menu:
height 50 to 60px
width 100% of screen/width
below header ~ 0px

search-button:
inside menu 20 to 50px left, 0 to 10px top

@on mobile
search-button:
width 100px

@on desktop
search-button:
width 150px

Project Structure

This is a possible project directory structure:

1. Drivers Directory consists of the browser kits required to execute a browser. This directory includes Gecko Driver, Chrome Driver and PhantomJSDriver.

2. Page Interactions Directory contains all the JavaScript related logic related to page interactions.

3. Reports Directory consists of all the reports executed on Cross Devices, Cross Browsers and specific to only a single device.

  • Cross_Browser_Specs_reports has the reports for Cross Browsing based test executions.
  • Cross_Device_Specs_Reports has the reports for Cross Browsing and Cross Device based test execution.
  • Uni_Specs_Reports has the reports for tests executed specific to a single device.

4. Specs Directory consists of the Galen specifications, and has two classifications:

  • Cross_Specs which essentially focuses on the characteristics on multiple devices.
  • Uni_Specs focuses on the characteristics of a single device.

5. Test_Suites Directory consists of the test suites required to execute all the tests and has three classifications:

  • Cross_Browser focuses on tests written for multiple browser and multiple devices.
  • Cross_Devices focuses on tests written for multiple devices only specific to the default browser mentioned in the Galen configuration.
  • Uni_Devices focuses on tests written specific to the device that's specific to the default browser mentioned in the Galen configuration only.

6. galen.config consists of all the configuration related parameters required to execute Galen.

Galen Specs

The Galen Specs language is quite flexible and gives the opportunity to express exactly how you want your website to behave on different devices and on different browsers. There are two main parts in the Page Specs file:

Object Definition

Each Galen spec file normally starts with object definition. It is the place where you give names to page objects and also define the so called locators– the way for Galen to find elements on the test page. The available locators are:

  • id– searches for object by id in DOM.
  • css– uses CSS selectors to find objects.
  • xpath– uses XPathexpressions.

The object definition is defined with an @objects keyword and all objects are declared below it. The object definition can be defined as follows:

@objects
header css div.ss-header-container div.ss-header
header-logo css div.ss-header-left div:nth-child(2) a img.cgu-logo
carousel id hero-carousel-mob

Object Specs

The object specs consist of the specifications of the page object. You can consider your object specs to be an assertion. Object specs are the validation metrics for the page objects. Based on the object specs, the validation for the visual regression is carried out.

header:
height 50px
width 375px
header-logo:
height 33px
width 41px

Sections and Tagging

Sections are declared with = symbol at the beginning and end of the line. Also, in Galen, you can have multiple sections within each other. This allows you to structure your test code so that it is easier to read the specs.

= Header section =
header:
height 50px
width 375px
header-logo:
height 33px
width 41px

Quite often you need to declare different specs for different conditions (e.g. various devices like mobile, tablet, or desktop). You can specify tags in your spec file so that it is easier to manage your layout testing. You can wrap all your checks inside @on statement like this:

@on mobile
header-mobile:
height 50px
width 375 to 410px

@on desktop
header-desktop:
height 40px
width 1024px

Absent

One of the simplest specs in Galen, it doesn’t take any parameters. It is used to check that the element is either missing on page (in HTML code) or it is present but not visible (e.g. style display:none)

hamburger:
absent

Inside

Spec inside verifies that an element is visually inside another element.

site-nav-button:
inside site-nav 10px top

Ranges

The basis for all specs is a so-called “range.” The Range is a format of defining boundaries for any value. With the range, you may express that the expected value should be exactly ‘0’, or greater than ‘0’, less than ‘0’, etc. For example:

# The value between range
width 375 to 400px
# Greater than
width > 40 px
# Less than
width < 40 px
# Greater than or equals
width >= 40 px
# Less than or equals
width <= 40 px
# Approximate
width ~ 100 px

Galen Test Suite

To give more flexibility and maintainability to the user, Galen came up with another simple format for defining test suites. Test suites are just a set of pages that need to be checked with the appropriate test specs, but there is something more in there which gives a lot of power in testing. Apart from this, it also makes the test execution much smoother.

The aim of deploying a test suite is mainly to carry out continuous executions of all the test specifications without human intervention, and Galen provides such ease through its deployment of the test suite. The entire specification of the application can be executed in one go.

Basic Format

The basic format of the test suite looks something like this:

Checking the responsiveness for business section on ${device}
Business section | http://${domain}/business ${resolution}
wait 10s until exist "css: div#nebula_div_btn"
check././Specs/Uni_Specs/CGU_Business.gspec

Defining the basic format of a test suite in Galen takes place in three simple steps:

  • Defining the name of the test. For this test, we have also specified to run these against a specific domain and platform with the browser resize resolution.
  • If there are any conditions that need to be provided or if you need to call an external JavaScript file to define the Page Interactions, that can be written in the second step.
  • In the third step, you define the Page Action, which basically tells to check the page specification for the particular URL defined.

Passing Javascript Variables to a Spec File

You can pass some data from your tests into your spec file so that they are accessible from JavaScript statements. To do this you need to pass it via --VvariableName variableValue argument. For example:

Home page test
http://example.com 1024x768
check homepage.gspec --include desktop --Vusername John

Variables

It is always nice to put commonly used data in variables. For example, we can put the domain name in the variable. This can be done with special instruction: set

@@ set
domain www.cgu.com.au/insurance
resolution 375x667
set device Iphone6

@@ groups Business_Section
Checking the responsiveness for business section on ${device}
Business section | http://${domain}/business ${resolution}
wait 10s until exist "css: div#nebula_div_btn"
check././Specs/Uni_Specs/CGU_Business.gspec
Or you can also use variable reference when defining another variable.

@@ set
domain example.com
base_url http://${domain}/

Home page on a small mobile device
${base_url} 320x600
check homepage.gspec --include "mobile,all" --exclude "nomobile"

Replacing Page URL in Reports

Once the test is done, Galen will generate an HTML report and use the browser factory that you defined in your spec. If you would like to change the way it appears there, you can use ‘|’ symbol like in the following example:

Checking the responsiveness for menu in the business section on ${device}
Breadcrumb in Business section | http://${domain}/business ${resolution}

In the end, Galen will use everything before ‘|’ in the HTML report. Here, only the Breadcrumb in Business section part will be shown.

Parameterization

If you want to run tests against different devices or different browsers, you can write a data table and mark the test with a “parameterized” special instruction. This can be done using the @@ parameterized annotation.

@@ parameterized
| deviceName | tags | size |
| Mobile | mobile | 320x600 |
| Tablet | tablet | 640x480 |
| Desktop | desktop | 1024x800 |
Home page on ${deviceName} device
http://example.com/ ${size}
check homepage.gspec --include "${tags}"

As you can see, we defined a data table where the first row is used as a header with names of parameters. Using the example above, Galen will run test three times with all listed parameters. In the report, you will see the tests runs like this:

Home page on Mobile device
Home page on Tablet device
Home page on Desktop device

We can also parameterize the already existing parameterized tests in the suite. This can be done in the following way:

@@ parameterized
| browser |
| firefox |
| chrome |
| ie |
@@ parameterized
| deviceName | tags | size |
| Mobile | mobile | 320x600 |
| Tablet | tablet | 640x480 |
| Desktop | desktop | 1024x800 |
Home page on ${deviceName} device in ${browser} browser
${browser} http://example.com/ ${size}
check homepage.gspec --include "${tags}"

Tables

Tables come in handy when we want to parameterize all the tests running within the test suite. It would look something like this:

@@ table devices
| deviceName | tags | size |
| Mobile | mobile | 320x600 |
| Tablet | tablet | 640x480 |
| Desktop | desktop | 1024x800 |

@@ parameterized using devices
Home page on ${deviceName} device
http://example.com/ ${size}
check homepage.gspec --include "${tags}"

@@ parameterized using devices
Login page on ${deviceName} device
http://example.com/login ${size}
check login.gspec --include "${tags}"

You can also merge tables inside your parameterization code block:

@@ table deviceList_A
| deviceName | tags | size |
| Mobile | mobile | 320x600 |
| Tablet | tablet | 640x480 |
| Desktop | desktop | 1024x800 |

@@ table deviceList_B
| deviceName | tags | size |
| Mobile 2 | mobile | 360x600 |
| Mobile 3 | mobile | 400x600 |
| Mobile 4 | mobile | 500x600 |

@@ parameterized using deviceList_A, deviceList_B
Login page on ${deviceName} device
http://example.com/login ${size}
check login.gspec --include "${tags}"

Disabling a Test

A test can be disabled in Galen using the @@ disable annotation.

@@ disabled
Home page
http://example.com 640x480
check homepage.gspec

Login page
http://example.com/login 640x480
check homepage.gspec

Test Groups

Since version 1.6, you can tag your tests with groups. This will allow you to group your tests in HTML report and choose which group to run in command line. To mark a specific test as a group, just use the groups keyword:

@@ groups Business_Section
Checking the responsiveness for business section in ${browser} browser on ${deviceName}
selenium ${browser} http://${domain}/business ${size}
wait 10s until exist "css: div#nebula_div_btn"
check././Specs/Cross_Specs/CGU_Business.gspec --include "${tags}"

Waiting for Dynamic Content

There may be a possibility that we have to apply wait for any element to be loaded in the DOM before the test procedure can be carried forward. The timeout can be classified in two ways:

Strict Timeout: You can define timeout in minutes or seconds. For example:

Home page test
http://example.com 640x480
wait 10s
check homepage.gspec

Condition Based Timeout: For this way of waiting, you need to provide a locator (css, xpath or id) for an element and a condition for it. There are four conditions that can be used in wait actions:

  • The element appears in DOM.
  • The element is removed from DOM.
  • An element becomes visible.
  • The element gets hidden.

In case the condition fails, Galen will throw an exception and interrupt the test. For example:

@@ groups Business_Section
Checking the responsiveness for business section in ${browser} browser on
${deviceName}
selenium ${browser} http://${domain}/business ${size}
wait 10s until exist "css: div#nebula_div_btn"
check././Specs/Cross_Specs/CGU_Business.gspec --include "${tags}"
