What Is CRON and How Can It Help Schedule Cloud Workflow Jobs?

DZone 's Guide to

What Is CRON and How Can It Help Schedule Cloud Workflow Jobs?

This article explains what a CRON expression is and how to create a valid one for Cloud Workflow.

· Integration Zone ·
Free Resource

Introduction

Cloud Workflow presents a scheduler that allows you to automate the execution of a task over time. The corresponding schedule can be defined via a menu, where the user selects the necessary time expression or via a CRON expression.

This article explains what a CRON expression is and how to create a valid one for Cloud Workflow.

What Is CRON?

CRON is a time-based software utility, usually available in Unix-like machines, which can be used to schedule the execution of computer tasks.

According to Wikipedia, the origin of the name cron is from the Greek word for time, χρόνος (chronos).

The Unix version of CRON uses a file named crontab, where all automated tasks are listed, accompanied by a time tag, which defines the execution rule.

Advantages of Using a CRON Expression

Although not always so evident, CRON expressions can be really useful when defining repetitive tasks. The syntax is very simple and gives the user a good command over the automation of tasks.

Even easier, the Cloud Workflow’s Scheduler uses only the time section of a CRON expression.

How to Add a CRON Expression in Cloud Workflow

Adding a CRON expression in Cloud Workflow is straightforward. From the Repeat menu present in the Scheduler, select Cron and then add your CRON expression in the Cron Expression text box.

CRON Expressions

The diagram below summarizes the time section of a CRON expression.

Source: Wikipedia

As you can see, the time section of a CRON expression consists of five fields, representing minutes, hours, day of the month, month, and day of the week, in that order.

The possible values for each field are defined in the figure above. A star or asterisk (*) represents all possible values.

Some examples of the time section of a CRON expression are:

1 0 * * *

With indicates the first minute of the first hour of every day of every month of every day of the week.

1 0 1 * *

The above expression has added 1 to the day of the month field. Thus, it indicates the first minute of the first hour of very first day of each month.

1 0 1 1 *

The above expression has added 1 to the month field. Thus, it indicates the 1st minute of the first hour of the 1stof January.

1 0 1 1 6

The above expression has added 6 to the day of the week field. Thus, it indicates the 1st minute of the first hour of the 1st of January, which must be Saturday.

It should be noticed that the Scheduler accepts standard CRON expressions. Non-standard CRON commands, such as @yearly, are not considered.

Let me know your thoughts in the comments.
