What Is an IoT Networking Architecture?

DZone 's Guide to

What Is an IoT Networking Architecture?

Learn more about the networking architecture for IoT devices.

· IoT Zone ·
Free Resource

We all have heard of IoT, or the Internet of Things, and many of us even use it on a regular basis. From smart security systems and wearable watches to automatic comfort controls in our homes, IoT has started enabling us with auto-adapting, user-centric devices, pioneering the next stage in the Internet’s evolution.

This is the reason why many companies have started realizing IoT's importance and become keen on investing in connected technology. There are many ways an entity can begin its IoT journey. But the important thing is not to let the perceived complexity of the Internet of Things obscure the possibility to embark on more rewarding projects for companies.

A simple way to do this is to start with laying a robust framework for your IoT system. There is no single architecture that will suit all areas of IoT. However, you can invest in a four-part IoT network architecture that is used today as a support for many IoT systems. Consider these devices as stages in an IoT process. All of them are integrated structures that carry valuable data from different networked ‘things’ to production and IT systems to deliver actionable business insights.

The Architecture of an IoT System

1) Sensors and Actuators

In this stage, sensors collect data from the environment and turn that data into useful information. An example of this is the specialized structures in your cell phone that detect the directional pull of gravity and use that as data to orient the device. Similarly, actuators also intervene to change the physical conditions that generate the data. For example, an actuator shuts off the power supply or adjusts the air flow valve in a system. This sensing or actuating stage covers all sorts of devices, including industrial devices, robotic camera systems, water-level detectors, air quality sensors, and heart-rate monitors.

In reality, data processing takes place in every stage of IoT architecture. However, the data that is processed at the sensor has limited use, as the processing power available on each IoT device is limited. Since data is at the center of IoT network architecture concept, one has to also consider immediacy and depth of insight while processing the data. The faster the information needs to be delivered, the closer to the end devices the processing has to be. Deeper insights require more processing. In this case, the data is moved into a cloud-based system or a data center-based system that accommodates several sources of data altogether.

2) The Internet Gateway

The data that collects in the sensors is in analog form. Hence, it needs to be curated and converted into digital streams for further processing. DAS, or data acquisition systems, perform these data aggregation and conversion processes. DAS connects to the sensor network, collects outputs, and converts the analog data into the digital data. The internet gateway receives the collected and digitized data and sends it to stage 3 systems through Wi-Fi or LAN connections for further processing.

Stage 2 systems often remain close to the sensors and actuators. For example, a pump may contain many sensors and actuators to feed data to the data collection device for digitization. It can be physically attached to the pump. A gateway device close to it then processes the data and forwards it to the next stage system. Intelligent gateways can build on basic gateway functionality, offering capabilities like malware protection, data management services, and analytics. Such systems make it possible to analyze the data in real time.

3) Edge IT

Once the data has been digitized, it can now visit the realm of IT. However, the data may still require some processing before it can enter the cloud or data centre. This is where edge systems come in. Edge systems perform more analysis of the data. They can be placed in remote offices or edge locations but are usually located in the facility closer to the sensors.

Since IoT data can easily consume network bandwidth and swamp your data resources, it is best to have edge systems that are capable of performing analytics, as it will lessen the burden on core IT infrastructure. Still, having infrastructure as this is not easy. If there is just one data pipe carrying the data to the data centre, it has to be of enormous capacity. There will be other concerns as well, like security issues, storage issues, delays in processing the data. By using a staged approach, you can efficiently pre-process the data and generate meaningful results.

For example, rather than sending the raw vibration data for the pumps, you can process the data and pass on the projections only when a device fails or needs servicing.
