Blockchain Case Using Kubernetes

This article shows how we used Kubernetes and microservices architecture to build a crypto solution with complex functionality.

Tetiana Stoyko user avatar by
Tetiana Stoyko
·
Sep. 01, 22 · Tutorial
Like (1)
Save
Tweet
Share
6.43K Views

Join the DZone community and get the full member experience.

Join For Free

As an illustration of how Kubernetes is being used, I propose to consider one of our cases. We are going to talk about the application that was developed for the cryptocurrency market. Yet, the technologies used for this app are utilitarian and can be used for other projects as well. In other words, a tech task is a very general solution and mainly adjusted specifically to the Kubernetes and can be used in other industries as well.

Technologies That We Used

The project started as a start-up and had a limited budget. The client paid attention that we will have regular demos for investors where we should regularly show progress in developing new features. Thus, we decided to use such technologies as:

  • Node JS (NestJS framework)
  • PostgreSQL database
  • Kafka JS
  • Kubernetes(k8s) + Helm charts
  • Flutter
  • React

Development Process

For the first stage, our main purpose was to split our application into microservices. In our case, we decided to create 6 microservices.

  1. Admin microservice
  2. Core microservice
  3. Payment microservice
  4. Mails and notifications service
  5. Cron tasks service
  6. Webhooks microservice

It is worth mentioning that while the tech stack is utilitarian and can be used in various cases without changes, the foregoing microservices - are not. They were created specifically to serve the required features in our project. Thus, you can use the same technologies but will have to design new microservices according to your needs.

Let’s find out how to make these microservices on NestJS. We need to make configuration options for the Kafka messages broker. Therefore, we created a shared resources folder for the common modules and configurations of all microservices.

Microservices Configuration Options


import { ClientProviderOptions, Transport } from '@nestjs/microservices';

import CONFIG from '@application-config';

import { ConsumerGroups, ProjectMicroservices } from './microservices.enum';

const { BROKER_HOST, BROKER_PORT } = CONFIG.KAFKA;



export const PRODUCER_CONFIG = (name: ProjectMicroservices): ClientProviderOptions => ({

 name,

 transport: Transport.KAFKA,

 options: {

   client: {

     brokers: [`${BROKER_HOST}:${BROKER_PORT}`],

   },

 }

});



export const CONSUMER_CONFIG = (groupId: ConsumerGroups) => ({

 transport: Transport.KAFKA,

 options: {

   client: {

     brokers: [`${BROKER_HOST}:${BROKER_PORT}`],

   },

   consumer: {

     groupId

   }

 }

});


Let’s connect our Admin panel microservice to Kafka in consumer mode. It will allow us to catch and handle events from topics.

Make the app work in microservice mode for the ability to consume events:

app.connectMicroservice(CONSUMER_CONFIG(ConsumerGroups.ADMIN));  await app.startAllMicroservices();

We can notice that the consumer config includes groupId. It’s an important option that will allow consumers from the same group to get events from topics and distribute them to each other to process them faster.

For example, suppose our microservice receives events faster than it can process them. In that case, we can make autoscaling to spawn additional pods to share loading between them and make the process twice faster.

To make this possible, consumers should be in the group, and after scaling, spawned pods will be in the same group too. So, they will be able to share loading instead of handling the same topic events from different Kafka partitions.

Let’s check an example of how to catch and process Kafka events in NestJS:

Consumer Controller


import { Controller } from '@nestjs/common';

import { Ctx, KafkaContext, MessagePattern, EventPattern, Payload } from '@nestjs/microservices';



@Controller('consumer')

export class ConsumerController {

 @MessagePattern('hero')

 readMessage(@Payload() message: any, @Ctx() context: KafkaContext) {

   return message;

 }



 @EventPattern('event-hero')

 sendNotif(data) {

   console.log(data);

 }

}


Consumers can work in 2 modes. It receives events and processes them without returning any response (EventPattern decorator) or returns the response to the producer after processing an event (MessagePattern decorator). EventPattern is better and should be preferred if possible as it doesn’t contain any additional source code layers to provide request/response functionality.

What About Producers?

For connecting producers, we need to provide producer configuration for a module that will be responsible for sending events.

Producer Connection


import { Module } from '@nestjs/common';

import DatabaseModule from '@shared/database/database.module';

import { ClientsModule } from '@nestjs/microservices';

import { ProducerController } from './producer.controller';

import { PRODUCER_CONFIG } from '@shared/microservices/microservices.config';

import { ProjectMicroservices } from '@shared/microservices/microservices.enum';



@Module({

 imports: [

   DatabaseModule,

   ClientsModule.register([PRODUCER_CONFIG(ProjectMicroservices.ADMIN)]),

 ],

 controllers: [ProducerController],

 providers: [],

})

export class ProducerModule {}


Event-Based Producer


import { Controller, Get, Inject } from '@nestjs/common';

import { ClientKafka } from '@nestjs/microservices';

import { ProjectMicroservices } from '@shared/microservices/microservices.enum';



@Controller('producer')

export class ProducerController {

 constructor(

   @Inject(ProjectMicroservices.ADMIN)

   private readonly client: ClientKafka,

 ) {}



 @Get()

 async getHello() {

   this.client.emit('event-hero', { msg: 'Event Based'});

 }

}


Request/Response-Based Producer


import { Controller, Get, Inject } from '@nestjs/common';

import { ClientKafka } from '@nestjs/microservices';

import { ProjectMicroservices } from '@shared/microservices/microservices.enum';



@Controller('producer')

export class ProducerController {

 constructor(

   @Inject(ProjectMicroservices.ADMIN)

   private readonly client: ClientKafka,

 ) {}



 async onModuleInit() {

   // Need to subscribe to a topic

   // to make the response receiving from Kafka microservice possible

   this.client.subscribeToResponseOf('hero');

   await this.client.connect();

 }



 @Get()

 async getHello() {

   const responseBased = this.client.send('hero', { msg: 'Response Based' });

   return responseBased;

 }

}


Each microservice can work in any of two modes(producer/consumer) or both modes(mixed) at the same time. Usually, microservices use mixed mode for load balancing purposes, generating events to the topic and consuming them evenly, sharing the loading.

Kubernetes configuration based on Helm chart templates, implemented for each microservice.

Admin API microservice components and their structure described by Helm charts

The template consists of a few configuration files:

  • deployment
  • hpa(horizontal pod autoscaler)
  • ingress controller
  • service

Let’s look at each configuration file (without Helm templating)

Admin-API Deployment


apiVersion: apps/v1

kind: Deployment

metadata:

 name: admin-api

spec:

 replicas: 1

 selector:

   matchLabels:

     app: admin-api

 template:

   metadata:

     labels:

       app: admin-api

   spec:

     containers:

     - name: admin-api

       image: xxx208926xxx.dkr.ecr.us-east-1.amazonaws.com/project-name/stage/admin-api

       resources:

         requests:

           cpu: 250m

           memory: 512Mi

         limits:

           cpu: 250m

           memory: 512Mi

       ports:

         - containerPort: 80

       env:

         - name: NODE_ENV

           value: production



         - name: APP_PORT

           value: "80"


Deployment can contain more thin configurations like resource limits, health check configuration, update strategy, etc. However, We provide a basic configuration example, which can be extended depending on the needs of any other project.

Admin-API Service


---

apiVersion: v1

kind: Service

metadata:

 name: admin-api

spec:

 selector:

   app: admin-api

 ports:

   - name: admin-api-port

     port: 80

     targetPort: 80

     protocol: TCP

 type: NodePort


We need to expose service to the outside world to use it. Let’s expose our app via a load balancer and provide SSL configuration to use a secure HTTPS connection.

We need to install a load balancer controller on our cluster. Here is the most popular solution: AWS Load Balancer Controller.

Then, we need to create ingress with the following configuration:

Admin-API Ingress Controller


apiVersion: networking.k8s.io/v1

kind: Ingress

metadata:

 namespace: default

 name: admin-api-ingress

 annotations:

   alb.ingress.kubernetes.io/load-balancer-name: admin-api-alb

   alb.ingress.kubernetes.io/ip-address-type: ipv4

   alb.ingress.kubernetes.io/tags: Environment=production,Kind=application

   alb.ingress.kubernetes.io/scheme: internet-facing

   alb.ingress.kubernetes.io/certificate-arn: arn:aws:acm:us-east-2:xxxxxxxx:certificate/xxxxxxxxxx

   alb.ingress.kubernetes.io/listen-ports: '[{"HTTP": 80}, {"HTTPS":443}]'

   alb.ingress.kubernetes.io/healthcheck-protocol: HTTPS

   alb.ingress.kubernetes.io/healthcheck-path: /healthcheck

   alb.ingress.kubernetes.io/healthcheck-interval-seconds: '15'

   alb.ingress.kubernetes.io/ssl-redirect: '443'

   alb.ingress.kubernetes.io/group.name: admin-api

spec:

 ingressClassName: alb

 rules:

   - host: example.com

     http:

       paths:

         - path: /*

           pathType: ImplementationSpecific

           backend:

             service:

               name: admin-api

               port:

                 number: 80


After applying this configuration, a new alb load balancer will be created, and we need to create a domain with the name which we provided in the ‘host’ parameter and route traffic from this host to our load balancer.

Admin-API Autoscaling Configuration


apiVersion: autoscaling/v2beta1

kind: HorizontalPodAutoscaler

metadata:

 name: admin-api-hpa

spec:

 scaleTargetRef:

   apiVersion: apps/v1

   kind: Deployment

   name: admin-api

 minReplicas: 1

 maxReplicas: 2

 metrics:

   - type: Resource

     resource:

       name: cpu

       targetAverageUtilization: 90


What About Helm?

Helm becomes very useful when we want to reduce the complexity of our k8s infrastructure. Without this tool - we need to write a lot of yml files before we can run it on a cluster.

Also, we should keep in mind relations between applications, labels, names, etc. However, we can make everything simpler with Helm. It works similar to the package manager, allowing us to create a template of the app and then prepare and run it using simple commands.
Let’s use helm to make our templates:

Admin-API Deployment (Helm Chart)


apiVersion: apps/v1

kind: Deployment

metadata:

 name: {{ .Values.appName }}

spec:

 replicas: {{ .Values.replicas }}

 selector:

   matchLabels:

     app: {{ .Values.appName }}

 template:

   metadata:

     labels:

       app: {{ .Values.appName }}

   spec:

     containers:

     - name: {{ .Values.appName }}

       image: {{ .Values.image.repository }}:{{ .Values.image.tag }}"

       imagePullPolicy: {{ .Values.image.pullPolicy }}

       ports:

       - containerPort: {{ .Values.internalPort }}

       {{- with .Values.env }}

       env: {{ tpl (. | toYaml) $ | nindent 12 }}

       {{- end }}


 Admin-API Service(Helm Chart)


apiVersion: v1

kind: Service

metadata:

 name: {{ .Values.global.appName }}

spec:

 selector:

   app: {{ .Values.global.appName }}

 ports:

   - name: {{ .Values.global.appName }}-port

     port: {{ .Values.externalPort }}

     targetPort: {{ .Values.internalPort }}

     protocol: TCP

 type: NodePort


Admin-API Ingress(Helm Chart)


apiVersion: networking.k8s.io/v1

kind: Ingress

metadata:

 namespace: default

 name: ingress

 annotations:

   alb.ingress.kubernetes.io/load-balancer-name: {{ .Values.ingress.loadBalancerName }}

   alb.ingress.kubernetes.io/ip-address-type: ipv4

   alb.ingress.kubernetes.io/tags: {{ .Values.ingress.tags }}

   alb.ingress.kubernetes.io/scheme: internet-facing

   alb.ingress.kubernetes.io/certificate-arn: {{ .Values.ingress.certificateArn }}

   alb.ingress.kubernetes.io/listen-ports: '[{"HTTP": 80}, {"HTTPS":443}]'

   alb.ingress.kubernetes.io/healthcheck-protocol: HTTPS

   alb.ingress.kubernetes.io/healthcheck-path: {{ .Values.ingress.healthcheckPath }}

   alb.ingress.kubernetes.io/healthcheck-interval-seconds: {{ .Values.ingress.healthcheckIntervalSeconds }}

   alb.ingress.kubernetes.io/ssl-redirect: '443'

   alb.ingress.kubernetes.io/group.name: {{ .Values.ingress.loadBalancerGroup }}

spec:

 ingressClassName: alb

 rules:

   - host: {{ .Values.adminApi.domain }}

     http:

       paths:

         - path: {{ .Values.adminApi.path }}

           pathType: ImplementationSpecific

           backend:

             service:

               name: {{ .Values.adminApi.appName }}

               port:

                 number: {{ .Values.adminApi.externalPort }}


Admin-API Autoscaling Configuration (Helm Chart)


{{- if .Values.autoscaling.enabled }}

apiVersion: autoscaling/v2beta1

kind: HorizontalPodAutoscaler

metadata:

 name: {{ include "ks.fullname" . }}

 labels:

   {{- include "ks.labels" . | nindent 4 }}

spec:

 scaleTargetRef:

   apiVersion: apps/v1

   kind: Deployment

   name: {{ include "ks.fullname" . }}

 minReplicas: {{ .Values.autoscaling.minReplicas }}

 maxReplicas: {{ .Values.autoscaling.maxReplicas }}

 metrics:

 {{- if .Values.autoscaling.targetCPUUtilizationPercentage }}

   - type: Resource

     resource:

       name: cpu

       targetAverageUtilization: {{ .Values.autoscaling.targetCPUUtilizationPercentage }}

 {{- end }}

 {{- if .Values.autoscaling.targetMemoryUtilizationPercentage }}

   - type: Resource

     resource:

       name: memory

       targetAverageUtilization: {{ .Values.autoscaling.targetMemoryUtilizationPercentage }}

 {{- end }}

{{- end }}


Values for templates are located in “values.yml”, “values-dev.yml”, and “values-stage.yml” files. Which of them will be used depends on the environment. Let’s check examples of some values for dev env.


Admin-API Helm Values-Stage.yml File


env: stage

appName: admin-api

domain: admin-api.xxxx.com

path: /*

internalPort: '80'

externalPort: '80'



replicas: 1

image:

 repository: xxxxxxxxx.dkr.ecr.us-east-2.amazonaws.com/admin-api

 pullPolicy: Always

 tag: latest



ingress:

 loadBalancerName: project-microservices-alb

 tags: Environment=stage,Kind=application

 certificateArn: arn:aws:acm:us-east-2:xxxxxxxxx:certificate/xxxxxx

 healthcheckPath: /healthcheck

 healthcheckIntervalSeconds: '15'

 loadBalancerGroup: project-microservices



autoscaling:

 enabled: false

 minReplicas: 1

 maxReplicas: 100

 targetCPUUtilizationPercentage: 80



env:

 - name: NODE_ENV

   value: stage



 - name: ADMIN_PORT

   value: "80"


To apply the configuration on the cluster, we need to upgrade the chart and restart our deployment.

Let’s check the GitHub Actions steps that are responsible for this.

Apply Helm Configuration in GitHub Actions


env: stage

appName: admin-api

domain: admin-api.xxxx.com

path: /*

internalPort: '80'

externalPort: '80'



replicas: 1

image:

 repository: xxxxxxxxx.dkr.ecr.us-east-2.amazonaws.com/admin-api

 pullPolicy: Always

 tag: latest



ingress:

 loadBalancerName: project-microservices-alb

 tags: Environment=stage,Kind=application

 certificateArn: arn:aws:acm:us-east-2:xxxxxxxxx:certificate/xxxxxx

 healthcheckPath: /healthcheck

 healthcheckIntervalSeconds: '15'

 loadBalancerGroup: project-microservices



autoscaling:

 enabled: false

 minReplicas: 1

 maxReplicas: 100

 targetCPUUtilizationPercentage: 80



env:

 - name: NODE_ENV

   value: stage



 - name: ADMIN_PORT

   value: "80"


Summary

Eventually, we examined how to build microservices with the use of Kubernetes on a specific case. We have clearly skipped other must-have steps and components, transforming code samples into a full-fledged working app. However, the foregoing source code is enough to show and explain how exactly Kubernetes microservices are built.

API Kubernetes kafka Load balancing (computing) microservice

Published at DZone with permission of Tetiana Stoyko. See the original article here.

Opinions expressed by DZone contributors are their own.

Popular on DZone

  • A Beginner's Guide to Infrastructure as Code
  • Fixing Bottlenecks in Your Microservices App Flows
  • Create a CLI Chatbot With the ChatGPT API and Node.js
  • 5 Best Python Testing Frameworks

Comments

Partner Resources

X

ABOUT US

  • About DZone
  • Send feedback
  • Careers
  • Sitemap

ADVERTISE

  • Advertise with DZone

CONTRIBUTE ON DZONE

  • Article Submission Guidelines
  • Become a Contributor
  • Visit the Writers' Zone

LEGAL

  • Terms of Service
  • Privacy Policy

CONTACT US

  • 600 Park Offices Drive
  • Suite 300
  • Durham, NC 27709
  • support@dzone.com
  • +1 (919) 678-0300

Let's be friends:
