A Look at the Cognos SDK With Java

DZone's Guide to

A Look at the Cognos SDK With Java

Take a look at some modular code using IBM's Cognos SDK. This setup will help you execute the Cognos report and save the XLS format to your machine.

· Java Zone
Free Resource

Learn how to troubleshoot and diagnose some of the most common performance issues in Java today. Brought to you in partnership with AppDynamics.

A while back, I got the oppurtunity to work with the Cognos SDK and Java. After some exercises, I was able to write some modular code for my project. IBM Cognos SDK has plenty of examples of interacting with the Cognos environment and executing the report, but here, I am providing some better modular code to execute the Cognos report and save the XLS format to your machine.

Let's look at the code snippets of this example:

Cognos POM Dependencies

<dependency>
  <groupId>cognos</groupId>
  <artifactId>cognosClient</artifactId>
  <version>10.0.0</version>
</dependency>
<dependency>
  <groupId>cognos</groupId>
  <artifactId>cognos-axis</artifactId>
  <version>10.0.0</version>
</dependency>
<dependency>
  <groupId>com.ibm.cognos</groupId>
  <artifactId>axisCognosClient</artifactId>
  <version>10.2.1003.17</version>
</dependency>

CognosConnection.properties

cognos.sendpoint=http://localhost:6578/cognos/servlet/dispatch
cognos.namespace=CognosNamespaceServices
cognos.uid=xyz
cognos.pwd=abcd
cognos.report.source.path=/content/folder[@name='Samples']/folder[@name='Models']/package[@name='GO Data']/folder[@name='Report Samples']
cognos.report.source.filename=Sales Report
cognos.report.dest.path=C:\\Arun\\
cognos.report.dest.filename=Sales Report
cognos.report.format=xls

Constant.java

import java.text.SimpleDateFormat;

public interface Constant {

  String STUB_HEADER_NAMESPACE = "http://developer.cognos.com/schemas/bibus/3/";
  String STUB_HEADER_PARTNAME = "biBusHeader";

  String COGNOS_REPORT_CONFIG_SQL = "SELECT REPORT_SOURCE_PATH, REPORT_SOURCE_FILE_NAME, REPORT_DEST_PATH, " +
    "REPORT_DEST_FILE_NAME, FORMAT, BUSINESS_DATE FROM COGNOS_REPORT_CONFIG WHERE CALENDAR_ID='";

  /** Cognos Properties Constant : read from properties file for development purpose **/
  String COGNOS_CONN_INFO_FILE = "/CognosConnection.properties";
  String PROP_SEND_POINT = "cognos.sendpoint";
  String PROP_NAMESPACE = "cognos.namespace";
  String PROP_UID = "cognos.uid";
  String PROP_PASSWORD = "cognos.pwd";
  String PROP_FORMAT = "cognos.report.format";
  String PROP_COGNOS_REPORT_SOURCE_PATH = "cognos.report.source.path";
  String PROP_COGNOS_REPORT_SOURCE_FILENAME = "cognos.report.source.filename";
  String PROP_COGNOS_REPORT_DEST_PATH = "cognos.report.dest.path";
  String PROP_COGNOS_REPORT_DEST_FILENAME = "cognos.report.dest.filename";
}

CognosPropertyReader.java

import java.io.IOException;
import java.sql.SQLException;
import java.util.Properties;
import org.apache.log4j.Logger;
import Constant;

public class CognosPropertyReader implements Constant{

  private static Logger LOG = Logger.getLogger(CognosPropertyReader.class);

  private static String sendPoint;
  public static String namespace;
  private static String cognosUser;
  private static String cognosPwd;
  private static String reportFormat;
  private static String reportDestFolder;

  private static String reportSourcePath;
  private static String reportSourceFileName;
  private static String reportDestPath;
  private static String reportDestFileName;
  private static Properties cognosConnProperty = new Properties();

  static{
    try {
      cognosConnProperty.load(CognosPropertyReader.class.getResourceAsStream(COGNOS_CONN_INFO_FILE));
    } catch (IOException e) {
      e.printStackTrace();
    }
  }

  /**
     * This is simply to keep ready all the required properties for Cognos
     */
  public synchronized static void readProperties() throws SQLException, IOException {

    sendPoint = cognosConnProperty.getProperty(PROP_SEND_POINT);
    namespace = cognosConnProperty.getProperty(PROP_NAMESPACE);
    cognosUser = cognosConnProperty.getProperty(PROP_UID);
    cognosPwd = cognosConnProperty.getProperty(PROP_PASSWORD);

    reportSourcePath = cognosConnProperty.getProperty(PROP_COGNOS_REPORT_SOURCE_PATH);
    reportSourceFileName = cognosConnProperty.getProperty(PROP_COGNOS_REPORT_SOURCE_FILENAME);
    reportDestPath = cognosConnProperty.getProperty(PROP_COGNOS_REPORT_DEST_PATH);
    reportDestFileName = cognosConnProperty.getProperty(PROP_COGNOS_REPORT_DEST_FILENAME);
    reportFormat = cognosConnProperty.getProperty(PROP_FORMAT);

    setReportDestFolder(reportDestPath);

    reportSourcePath += "/report[@name='" + reportSourceFileName +"']";
    reportDestPath += reportDestFileName;
  }

  public static String getSendPoint() {
    return sendPoint;
  }
  public static String getNamespace() {
    return namespace;
  }
  public static String getCognosUser() {
    return cognosUser;
  }
  public static String getCognosPwd() {
    return cognosPwd;
  }
  public static String getReportFormat() {
    return reportFormat;
  }
  public static String getReportSourcePath() {
    return reportSourcePath;
  }
  public static String getReportDestPath() {
    return reportDestPath;
  }
  public static String getReportDestFolder() {
    return reportDestFolder;
  }
  public static void setReportDestFolder(String reportDestFolder) {
    CognosPropertyReader.reportDestFolder = reportDestFolder;
  }
}

CognosConnector.java

import static Constant.STUB_HEADER_NAMESPACE;
import static Constant.STUB_HEADER_PARTNAME;

import java.io.IOException;
import java.net.MalformedURLException;
import java.rmi.RemoteException;
import java.sql.SQLException;

import javax.xml.namespace.QName;
import javax.xml.rpc.ServiceException;

import org.apache.axis.client.Stub;
import org.apache.axis.message.SOAPHeaderElement;
import org.apache.log4j.Logger;

import com.cognos.developer.schemas.bibus._3.BiBusHeader;
import com.cognos.developer.schemas.bibus._3.ContentManagerService_PortType;
import com.cognos.developer.schemas.bibus._3.ContentManagerService_ServiceLocator;
import com.cognos.developer.schemas.bibus._3.ReportService_PortType;
import com.cognos.developer.schemas.bibus._3.ReportService_ServiceLocator;
import com.cognos.developer.schemas.bibus._3.SearchPathSingleObject;
import com.cognos.developer.schemas.bibus._3.XmlEncodedXML;
import CognosPropertyReader;

public class CognosConnector {

  private final static Logger LOG = Logger.getLogger(CognosConnector.class);

  private ContentManagerService_PortType cmService = null;
  private ReportService_PortType reportService = null;

  public CognosConnector(){}

  public CognosConnector() throws SQLException, IOException, {

    CognosPropertyReader.readProperties();
    try {
      java.net.URL endPoint = new java.net.URL(CognosPropertyReader.getSendPoint());

      reportService = new ReportService_ServiceLocator().getreportService(endPoint);

      cmService = new ContentManagerService_ServiceLocator().getcontentManagerService(endPoint);
      LOG.info(quickLogon());
    }
    catch (MalformedURLException e) {
      LOG.error("Malformed URL:\n" + e.getMessage());
    } catch (ServiceException e) {
      LOG.error("ServiceException:\n" + e.getMessage());
    }

  }

  /**
     * This method logs the user to ReportNet
     */
  public String quickLogon() {
    StringBuffer credentialXML = new StringBuffer();

    credentialXML.append("<credential>");
    credentialXML.append("<namespace>").append(CognosPropertyReader.getNamespace()).append("</namespace>");
    credentialXML.append("<username>").append(CognosPropertyReader.getCognosUser()).append("</username>");
    credentialXML.append("<password>").append(CognosPropertyReader.getCognosPwd()).append("</password>");
    credentialXML.append("</credential>");

    String encodedCredentials = credentialXML.toString();

    try {
      getCmService().logon(new XmlEncodedXML(encodedCredentials), new SearchPathSingleObject[]{});

      SOAPHeaderElement temp = ((Stub)cmService).getResponseHeader(STUB_HEADER_NAMESPACE, STUB_HEADER_PARTNAME);
      BiBusHeader cmBiBusHeader = (BiBusHeader)temp.getValueAsType(new QName(STUB_HEADER_NAMESPACE, STUB_HEADER_PARTNAME));
      ((Stub)cmService).setHeader(STUB_HEADER_NAMESPACE, STUB_HEADER_PARTNAME, cmBiBusHeader);
      return ("Logon successful as " + CognosPropertyReader.getCognosUser());
    } catch (RemoteException re) {
      LOG.error(re.getMessage());
    } catch (Exception e) {
      LOG.error(e.getMessage());
    }
  }

  /**
     * To get the ReportService which would be use to run the report
     */
  public ReportService_PortType getReportService(boolean isNewConversation) {

    BiBusHeader bibus = getHeaderObject(((Stub)reportService).getResponseHeader(STUB_HEADER_NAMESPACE, STUB_HEADER_PARTNAME), isNewConversation);

    if (null == bibus) {
      bibus = getHeaderObject(((Stub)cmService).getResponseHeader(STUB_HEADER_NAMESPACE, STUB_HEADER_PARTNAME), true);
    }
    ((Stub)reportService).clearHeaders();
    ((Stub)reportService).setHeader(STUB_HEADER_NAMESPACE, STUB_HEADER_PARTNAME, bibus);
    return reportService;
  }

  /**
     * To get the header object
     */
  public static BiBusHeader getHeaderObject(SOAPHeaderElement SourceHeader, boolean isNewConversation) {
    if (null == SourceHeader){
      return null;
    }
    BiBusHeader bibus = null;
    try {
      bibus = (BiBusHeader)SourceHeader.getValueAsType(new QName(STUB_HEADER_NAMESPACE, STUB_HEADER_PARTNAME));

      /** If the header will be used for a new conversation, clear tracking information **/
      if (isNewConversation){
        bibus.setTracking(null);
      }
    } catch (Exception e) {
      LOG.error(e.getMessage());
    }
    return bibus;
  }

  public ContentManagerService_PortType getCmService() {
    return cmService;
  }

  public void setCmService(ContentManagerService_PortType cmService) {
    this.cmService = cmService;
  }
}

ReportExecutor.java

import java.io.File;
import java.io.FileOutputStream;
import java.io.IOException;
import java.sql.SQLException;
import org.apache.log4j.Logger;
import com.cognos.developer.schemas.bibus._3.AsynchDetailReportOutput;
import com.cognos.developer.schemas.bibus._3.AsynchDetailReportStatus;
import com.cognos.developer.schemas.bibus._3.AsynchDetailReportStatusEnum;
import com.cognos.developer.schemas.bibus._3.AsynchOptionBoolean;
import com.cognos.developer.schemas.bibus._3.AsynchOptionEnum;
import com.cognos.developer.schemas.bibus._3.AsynchReply;
import com.cognos.developer.schemas.bibus._3.AsynchReplyStatusEnum;
import com.cognos.developer.schemas.bibus._3.AsynchSecondaryRequest;
import com.cognos.developer.schemas.bibus._3.BaseClass;
import com.cognos.developer.schemas.bibus._3.Option;
import com.cognos.developer.schemas.bibus._3.Output;
import com.cognos.developer.schemas.bibus._3.Page;
import com.cognos.developer.schemas.bibus._3.ParameterValue;
import com.cognos.developer.schemas.bibus._3.ParmValueItem;
import com.cognos.developer.schemas.bibus._3.PropEnum;
import com.cognos.developer.schemas.bibus._3.QueryOptions;
import com.cognos.developer.schemas.bibus._3.RunOptionBoolean;
import com.cognos.developer.schemas.bibus._3.RunOptionEnum;
import com.cognos.developer.schemas.bibus._3.RunOptionStringArray;
import com.cognos.developer.schemas.bibus._3.SearchPathMultipleObject;
import com.cognos.developer.schemas.bibus._3.SearchPathSingleObject;
import com.cognos.developer.schemas.bibus._3.SimpleParmValueItem;
import com.cognos.developer.schemas.bibus._3.Sort;
import CognosConnector;
import CognosPropertyReader;

public class ReportExecutor {

  private static Logger LOG = Logger.getLogger(ReportExecutor.class);

  private static CognosConnector cognosConn;

  public ReportExecutor() throws SQLException, IOException{
    cognosConn = new CognosConnector();
  }

  /**
     * Check for a secondary request.
     */
  public boolean hasSecondaryRequest(AsynchReply response, String secondaryRequest) {
    AsynchSecondaryRequest[] secondaryRequests = response.getSecondaryRequests();

    for (int i = 0; i < secondaryRequests.length; i++) {
      if (secondaryRequests[i].getName().compareTo(secondaryRequest)== 0) {
        return true;
      }
    }
    return false;
  }

  /**
     * The run will return complete even if the report output is not created this method will
     * check for actual output after the run has returned a complete status.
     */
  public boolean outputIsReady(AsynchReply response) {
    for (int i = 0; i < response.getDetails().length; i++) {
      if ((response.getDetails()[i] instanceof AsynchDetailReportStatus)
          && (((AsynchDetailReportStatus)response.getDetails()[i]).getStatus()
              == AsynchDetailReportStatusEnum.responseReady)
          && (hasSecondaryRequest(response, "getOutput"))) {
        return true;
      }
    }
    return false;
  }

  /**
     * To execute the cognos report for XLS format
     */
  public void executeReport(String date) {

    String textOutput = null;
    String format = "spreadsheetML";

    try {
      /** setup the runOptions for execution of report */
      Option[] runOptions = new Option[4];

      RunOptionBoolean saveOutput = new RunOptionBoolean();
      saveOutput.setName(RunOptionEnum.saveOutput);
      saveOutput.setValue(false);
      runOptions[0] = saveOutput;

      /** Specify the output format */
      RunOptionStringArray outputFormat = new RunOptionStringArray();
      outputFormat.setName(RunOptionEnum.outputFormat);
      outputFormat.setValue(new String[]{format});
      runOptions[1] = outputFormat;

      /** Set the report not to prompt as we pass the parameters if any */
      RunOptionBoolean rop = new RunOptionBoolean();
      rop.setName(RunOptionEnum.prompt);
      rop.setValue(false);
      runOptions[2] = rop;

      /** Set the option to always have the primaryRequest in the response */
      AsynchOptionBoolean includePrimaryRequest = new AsynchOptionBoolean();
      includePrimaryRequest.setName(AsynchOptionEnum.alwaysIncludePrimaryRequest);
      includePrimaryRequest.setValue(true);
      runOptions[3] = includePrimaryRequest;

      SearchPathSingleObject spSingle = new SearchPathSingleObject();
      spSingle.set_value(CognosPropertyReader.getReportSourcePath());
      AsynchReply res = cognosConn.getReportService(true).run(spSingle, this.getReportParameters(date), runOptions);

      /** If response is not immediately complete, call wait until complete */
      if (!res.getStatus().equals(AsynchReplyStatusEnum.complete)) {
        while (!res.getStatus().equals(AsynchReplyStatusEnum.complete)) {
          /** before calling wait, double check that it is okay */
          if (hasSecondaryRequest(res, "wait")) {
            res = cognosConn.getReportService(false).wait(res.getPrimaryRequest(), new ParameterValue[] {}, new Option[] {});
          }
        }

        /** After calling wait() it is necessary to check to make sure
                 * the output is ready before retrieving it */
        if (outputIsReady(res)) {
          res = cognosConn.getReportService(false).getOutput(res.getPrimaryRequest(),
                                                             new ParameterValue[] {}, new Option[] {});
        }
      }

      AsynchDetailReportOutput reportOutput = null;

      for (int i = 0; i < res.getDetails().length; i++) {
        if (res.getDetails()[i] instanceof AsynchDetailReportOutput) {
          reportOutput = (AsynchDetailReportOutput)res.getDetails()[i];

          String[] data = reportOutput.getOutputPages();
          textOutput = data[0];
          /** look for output pages of the excel report. */
          BaseClass bcOutput[] = reportOutput.getOutputObjects();
          Output out = null;

          if (null != bcOutput) {
            for (int k = 0; k < bcOutput.length; k++) {
              if(bcOutput[k] instanceof Output) {
                LOG.info("Found Page in report... saving locally.");
                out = (Output)bcOutput[k];

                PropEnum []page_props = new PropEnum[]{
                  PropEnum.searchPath, PropEnum.defaultName,
                    PropEnum.data, PropEnum.dataType};
                BaseClass []bcPage = cognosConn.getCmService().query(new SearchPathMultipleObject(out.getSearchPath().getValue() + "/page"),
                                                                     page_props, new Sort[]{}, new QueryOptions() );
                if (null != bcPage) {
                  for (int j = 0; j < bcPage.length; j++) {
                    Page g = (Page)bcPage[j];
                    String pageName = g.getDefaultName().getValue();
                    String pageFile = CognosPropertyReader.getReportDestFolder() + "\\" + pageName;
                    /** save html page locally.*/
                    File oFile = new File(pageFile);
                    FileOutputStream fos = new FileOutputStream(oFile);
                    fos.write(g.getData().getValue());
                    fos.flush();
                    fos.close();
                  }
                }
              }
            }
          }

          /** Write the report output to a file */
          File oFile = new File(CognosPropertyReader.getReportDestPath().replaceAll(" ", "-") +".xls");
          FileOutputStream fos = new FileOutputStream(oFile);

          if (null != textOutput) {
            byte binaryOutput[] = null;
            binaryOutput = com.cognos.org.apache.axis.encoding.Base64.decode(textOutput);
            fos.write(binaryOutput);
          }
          fos.flush();
          fos.close();
        }
      }
    }
    catch( Exception ex) {
      LOG.error(ex.getMessage());
    }
  }

  /**
     * To get the Report parameter in form of date
     */
  public ParameterValue[] getReportParameters(String monthYear) {

    ParameterValue[] parameters = new ParameterValue[1];

    SimpleParmValueItem item = new SimpleParmValueItem();
    item.setDisplay(monthYear);
    item.setUse(monthYear);
    item.setInclusive(true);
    ParmValueItem[] pvi = new ParmValueItem[1];
    pvi[0] = item;

    parameters[0] = new ParameterValue();
    parameters[0].setName("date");
    parameters[0].setValue(pvi);
    return parameters;
  }
}

CognosReportExecutorClient.java

import java.io.IOException;
import java.sql.SQLException;
import org.apache.log4j.Logger;
import ReportExecutor;

public class CognosReportExecutorClient{

  private final static Logger LOG = Logger.getLogger(CognosReportExecutorClient.class);

  public static void main(String[] args) throws IOException, SQLException {

    if(null == args[0] || args[0].length() < 1){
      System.exit(1);
    }
    String date = args[0]
      new ReportExecutor().executeReport(date);
  }
}

Update the config info as per your need, and it's all good to go. I hope this will give a better understanding of how to use the Cognos IBM SDK.

Understand the needs and benefits around implementing the right monitoring solution for a growing containerized market. Brought to you in partnership with AppDynamics.

Topics:
cognos ,java ,sdk ,XLS

Opinions expressed by DZone contributors are their own.

{{ parent.title || parent.header.title}}

{{ parent.tldr }}

{{ parent.urlSource.name }}
