HA and Zone Affinity With Spring Cloud Netflix Eureka

DZone's Guide to

HA and Zone Affinity With Spring Cloud Netflix Eureka

This microservices tutorial will teach you how to set up zone affinity with Spring Cloud Netflix Eureka.

· Microservices Zone ·
Free Resource

Download the  How to Build (and Scale) with Microservices eBook and learn how microservices are rapidly emerging as the architecture of choice. Brought to you in partnership with AppDynamics

This tutorial will guide you through the process to setup zone affinity in Spring Cloud Netflix Eureka.

What You Will Build

You will build three applications:

  1. API Gateway - Spring Cloud Netflix Zuul

  2. Service Registry - Spring Cloud Netflix Eureka

  3. REST Service - Spring Cloud

All those are necessary to make sure that our zone affinity setup is correct. Each of them will be deployed twice, one per zone.

Pre-Req

Zone Affinity

It doesn't matter which kind of architectural style the application is using, it's a common use case to have the same application deployed in different regions/data centers and use some technique to keep the requests within the same zone.

In microservices architecture, there's also a need to achieve the same thing but the technique needs to be applied using the Service Registry Design Pattern.

Spring Cloud Netflix

Spring Cloud Netflix makes it easy to implement the necessary patterns for microservices.

Creating the Applications

In this guide, we'll create three applications, and if you're familiar with spring-cloud, it will be an easy job, all the created applications are nothing more than a simple runnable spring-boot jar.

The main part here is the configuration files that will be shown further on.

Base Dependencies

Add the following dependencies for all the applications. If there's any diff for any specific application, it will be mentioned in each specific thread.

    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>1.5.9.RELEASE</version>
    </parent>

    <dependencyManagement>
        <dependencies>
            <dependency>
                <groupId>org.springframework.cloud</groupId>
                <artifactId>spring-cloud-dependencies</artifactId>
                <version>Edgware.SR2</version>
                <type>pom</type>
                <scope>import</scope>
            </dependency>
        </dependencies>
    </dependencyManagement>

    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>

        <dependency>
            <groupId>org.springframework.cloud</groupId>
            <artifactId>spring-cloud-starter-eureka</artifactId>
        </dependency>

        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
        </dependency>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>
    </dependencies>

    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
            </plugin>
        </plugins>
    </build>


API Gateway

The first application we'll create will be the API Gateway using Spring Cloud Netflix Zuul.

First, add the following dependency in the pom.xml.

<dependency>
    <groupId>org.springframework.cloud</groupId>
    <artifactId>spring-cloud-starter-zuul</artifactId>
</dependency>

Java Configuration

Now just create the main SpringApplication class adding @EnableZuulProxy.

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.client.discovery.EnableDiscoveryClient;
import org.springframework.cloud.netflix.zuul.EnableZuulProxy;

@EnableZuulProxy
@EnableDiscoveryClient
@SpringBootApplication
public class GatewayApplication {

    public static void main(String... args) {
        SpringApplication.run(GatewayApplication.class, args);
    }

}


Service Registry

The second application we'll create will be the Service Registry using Spring Cloud Netflix Eureka.

First, add the following dependency in the pom.xml.

<dependency>
    <groupId>org.springframework.cloud</groupId>
    <artifactId>spring-cloud-starter-eureka-server</artifactId>
</dependency>

Java Configuration

Now just create the main SpringApplication class adding @EnableEurekaServer.

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.netflix.eureka.server.EnableEurekaServer;

@EnableEurekaServer
@SpringBootApplication
public class ServiceDiscoveryApplication {

    public static void main(String... args) {
        SpringApplication.run(ServiceDiscoveryApplication.class, args);
    }
}


Simple REST Service

The third application contains nothing more than a REST endpoint to make sure that each call from each region will remain in the requested region. For this application, there's nothing to add to the base pom.xml.

Java Configuration

To make things easier, I'm creating the main class with a nested RestController, the following controller returns which zone is this application deployed.

import org.springframework.beans.factory.annotation.Value;
import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.client.discovery.EnableDiscoveryClient;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RestController;

import static org.springframework.http.MediaType.APPLICATION_JSON_UTF8_VALUE;

@EnableDiscoveryClient
@SpringBootApplication
public class SimpleService {

    public static void main(String... args) {
        SpringApplication.run(SimpleService.class, args);
    }

    @RestController
    class SimpleController {

        @Value("${eureka.instance.metadataMap.zone}")
        private String zone;

        @GetMapping(value = "/zone", produces = APPLICATION_JSON_UTF8_VALUE)
        public String zone() {
            return "{\"zone\"=\"" + zone + "\"}";
        }

    }
}


Configuration Properties

As it was previously mentioned, each application needs to run twice in order to simulate two distinct regions, to make it easier we'll create the configuration based on profiles, for each application create the following three files:

src/main/resources/application.yml
src/main/resources/application-zone1.yml
src/main/resources/application-zone2.yml

Note: The suffix in the filename will be used as the profile name.

Service Registry

# src/main/resources/application.yml

eureka:
  client:
    register-with-eureka: false
    fetch-registry: false
    region: region-1
    service-url:
      zone1: http://localhost:8761/eureka/
      zone2: http://127.0.0.1:8762/eureka/
    availability-zones:
      region-1: zone1,zone2

spring.profiles.active: zone1

All the following properties are in eureka.client namespace.

Property Description
region

A String containing a name for the region where the application will be deployed

service-url

A Map containing the list of available zones for the given region

availability-zones

A Map containing a comma-separated list of zones for the given region


The properties register-with-eureka and fetch-registry are disabling the Service Registry to be added in the applications list but it's not that important for this setup.

# src/main/resources/application-zone1.yml

server.port: 8761

eureka:
  instance:
    hostname: localhost
    metadataMap.zone: zone1
# src/main/resources/application-zone2.yml

server.port: 8762

eureka:
  instance:
    hostname: 127.0.0.1
    metadataMap.zone: zone2

For the -zone1 and -zone2 profiles the only difference are the server.port, the actual zone configured in eureka.metadataMap.zone, and in this case the hostname, each Eureka Server needs to run in a different hostname; as I'm running both in the same machine I'm naming it as 127.0.01 and localhost.

Note: It's not necessary to add the hostname in case you are running on different machines.

Gateway

# src/main/resources/application.yml

eureka:
  client:
    prefer-same-zone-eureka: true
    region: region-1
    service-url:
      zone1: http://localhost:8761/eureka/
      zone2: http://127.0.0.1:8762/eureka/
    availability-zones:
      region-1: zone1,zone2

spring:
  profiles.active: zone1
  application.name: gateway

management.security.enabled: false

The main difference here is the property eureka.client.prefer-same-zone-eureka, it is telling to the application that whenever it needs to make a call to another EurekaClient it will call it using the same zone where the caller is deployed. In case there's no available client in the same zone, it will call from another zone in which it's available.

# src/main/resources/application-zone1.yml

server.port: 8080

eureka:
  instance:
    metadataMap.zone: zone1
# src/main/resources/application-zone2.yml

server.port: 8081

eureka:
  instance:
    metadataMap.zone: zone2

As before, this per profile configuration only changes the availability zone and the running port.

Simple REST Service

The configuration for the service itself contains the same configuration as the Gateway.

# src/main/resources/application.yml

eureka:
  client:
    prefer-same-zone-eureka: true
    region: region-1
    service-url:
      zone1: http://localhost:8761/eureka/
      zone2: http://127.0.0.1:8762/eureka/
    availability-zones:
      region-1: zone1,zone2

spring:
  profiles.active: zone1
  application.name: simple-service
# src/main/resources/application-zone1.yml

server.port: 8181

eureka:
  instance:
    metadataMap.zone: zone1
# src/main/resources/application-zone2.yml

server.port: 8182

eureka:
  instance:
    metadataMap.zone: zone2


Build & Run

It's time to build the applications; if you are building the application using maven (like I did), just build them executing:

$ mvn clean package

Right after that just run each application adding the specific profile to the command line, e.g:

$ java -jar target/*.jar --spring.profiles.active=zone1

Note: Remember that you need to run each application twice, once each profile: zone1 and zone2.

Validation

To validate if the requests are respecting each zone we need to make a request to the simple-service through each gateway.

$ curl http://localhost:8080/simple-service/zone

{"zone"="zone1"}
$ curl http://localhost:8081/simple-service/zone

{"zone"="zone2"}

Note: The difference between each zone here is the server.port.

Zone Failover Validation

To validate the failover between zones you just need to stop one of the instances and make a request to the opposite zone, e.g:

  1. Stop simple-service on zone2.

  2. Make a request to simple-service through the gateway on zone2.

$ curl http://localhost:8081/simple-service/zone

The expected result now will be a JSON containing {"zone"="zone1"}.

Once the simple-service for zone1 is up, running and registered in Eureka Server the same curl has to respond {"zone"="zone2"}  again.

Note: It takes a while to the simple-service be available in the opposite zone, be patient and have fun!

Summary

Congratulations! You just created and configured an API Gateway, Service Registry and a Simple REST Service that respects zone affinity bringing to your microservices more resilience and HA.
