JAX-WS Header: Part 1 the Client Side

Manipulating JAXWS header on the client Side like adding WSS username token or logging saop message.

· Integration Zone

Visually compose APIs with easy-to-use tooling. Learn how IBM API Connect provides near-universal access to data and services both on-premises and in the cloud, brought to you in partnership with IBM.


Manipulating JAXWS header on the client Side like adding WSS username token or logging saop message.


On Telecom IT environment and specially middelware solution, we will rarely do all the work but rather delegate some of business process to other tiers. Web service communications is heavy used between solutions. This tutorial aims to introduce using handler on client side by adding WSS UserToken or logging the soap message on console.

Adding undeclared custom header

Some Ws client needs to add a custom header which are not declared on WSDL. Adding WSS Username Token is like adding this XML snippet on header element:

      <wsse:Security  xmlns:wsse="http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-wssecurity-secext-1.0.xsd" xmlns:wsu="http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-wssecurity-utility-1.0.xsd">
         <wsse:UsernameToken wsu:Id="UsernameToken-1">
            <wsse:Password Type="http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-username-token-profile-1.0#PasswordText">XXXX</wsse:Password>

Unlike LogicalHandler SOAPHandler have access to the entire Soap Message. Let's create an WSSUsernameTokenSecurityHandler Local Stateless Bean extending SOAPHandler to produce the previous header.
Below the WSSUsernameTokenSecurityHandler class

package me.slim.ouertani;

import java.util.Set;
import java.util.TreeSet;
import javax.annotation.Resource;
import javax.ejb.LocalBean;
import javax.ejb.Stateless;
import javax.xml.namespace.QName;
import javax.xml.soap.*;
import javax.xml.ws.handler.MessageContext;
import javax.xml.ws.handler.soap.SOAPHandler;
import javax.xml.ws.handler.soap.SOAPMessageContext;

public class WSSUsernameTokenSecurityHandler implements SOAPHandler<SOAPMessageContext> {

    @Resource(lookup = "login")
    private String login;
    @Resource(lookup = "pwd")
    private String pwd;

    public WSSUsernameTokenSecurityHandler() {

    public boolean handleMessage(SOAPMessageContext context) {

        Boolean outboundProperty =
                (Boolean) context.get(MessageContext.MESSAGE_OUTBOUND_PROPERTY);
        if (outboundProperty.booleanValue()) {

            try {
                SOAPEnvelope envelope = context.getMessage().getSOAPPart().getEnvelope();
                SOAPFactory factory = SOAPFactory.newInstance();
                String prefix = "wsse";
                String uri = "http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-wssecurity-secext-1.0.xsd";
                SOAPElement securityElem =
                        factory.createElement("Security", prefix, uri);
                SOAPElement tokenElem =
                        factory.createElement("UsernameToken", prefix, uri);
                tokenElem.addAttribute(QName.valueOf("wsu:Id"), "UsernameToken-2");
                tokenElem.addAttribute(QName.valueOf("xmlns:wsu"), "http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-wssecurity-utility-1.0.xsd");
                SOAPElement userElem =
                        factory.createElement("Username", prefix, uri);
                SOAPElement pwdElem =
                        factory.createElement("Password", prefix, uri);
                pwdElem.addAttribute(QName.valueOf("Type"), "http://docs.oasis-open.org/wss/2004/01/oasis-200401-wss-username-token-profile-1.0#PasswordText");
                SOAPHeader header = envelope.addHeader();

            } catch (Exception e) {
        } else {
            // inbound
        return true;

    public Set<QName> getHeaders() {
        return new TreeSet();

    public boolean handleFault(SOAPMessageContext context) {
        return false;

    public void close(MessageContext context) {

Next, declare the StatelessBean and inject both Webservice via @WebServiceRef and WSSUsernameTokenSecurityHandler via @EJB. A callback init method will add a HandlerResolver to the service. Below the full implementation

public class WebServiceClientBean {

    private WsService service;
    private WSSUsernameTokenSecurityHandler wSSUsernameTokenSecurityHandler;

    private void init() {
        service.setHandlerResolver( new HandlerResolver() {

            public List<Handler> getHandlerChain(PortInfo portInfo) {
                List<Handler> handlerList = new ArrayList<Handler>();
                return handlerList;

  public WsResponse getService(WsRequest wsRequest) {
        WsPort port = service.getPort();
        return port.invoqueService(wsRequest);


Logging SOAP messages

Logging exchange xml message can be also using handlers, below the scala snippet handler used to log both in and out messages:

class RequestResponsePrinter  extends SOAPHandler[SOAPMessageContext] with LogHelper {

override def getHeaders(): Set[QName] = {
    return new TreeSet();

  override def handleMessage(context: SOAPMessageContext): Boolean = {
    val sb = new ToStringBuilder(this).append("Call operation", "handleMessage");

    val outboundProperty = context.get(MessageContext.MESSAGE_OUTBOUND_PROPERTY).asInstanceOf[Boolean]

      try {
            val msg = context.getMessage()
            val out = new ByteArrayOutputStream();
            val strMsg = new String(out.toByteArray());
            L.debug("outbound  : "+outboundProperty.booleanValue()+" [" + strMsg + "]");

      } catch {
        case e: Exception =>
          L.error(sb.append("EXCEPTION", e.getMessage()), e);

    return true;

  override def handleFault(context: SOAPMessageContext): Boolean = {
    return false;

  override def close(context: MessageContext) {
  • scala version of Handler resolver
new HandlerResolver() {

      override def getHandlerChain(portInfo: PortInfo): java.util.List[javax.xml.ws.handler.Handler[_ <: javax.xml.ws.handler.MessageContext]] = {
        import scala.collection.mutable.ArrayBuffer
        val handlerList = ArrayBuffer[Handler[_ <: javax.xml.ws.handler.MessageContext]]()
        handlerList += new RequestResponsePrinter()
        return handlerList



We have heavily used handler on client side. On the server side things can change a bit, to be continued ...
