Think in Graphs, Not Just Chains: JGraphlet for TaskPipelines
JGraphlet is a tiny, zero-dependency Java library for building task pipelines. It uses a graph model where you define tasks as nodes and connect them.
Join the DZone community and get the full member experience.
Join For FreeJGraphlet is a tiny, zero-dependency library for building task pipelines in Java. Its power comes not from a long list of features, but from a small set of core design principles that work together in harmony.
At the heart of JGraphlet is simplicity, backed by a Graph. Add Tasks to a pipeline and connect them to create your graph. Each Task has an input and output. A TaskPipeline builds and executes a pipeline while managing the I/O for each Task.
For example, a Map for fan-in, a Record for your own data model, etc. A task pipeline also has a way PipelineContext to share the data between Tasks, and furthermore, tasks can also be cached, so the computation doesn't need to take place again and again. You can choose how your task pipeline flow should be, and you can choose whether it should be a SyncTask or Async. By default, all Tasks are Async.
Let’s dive into the eight core principles that define JGraphlet.
1. A Graph-First Execution Model
JGraphlet treats your workflow as a directed acyclic graph (DAG). You define tasks as nodes and explicitly draw the connections (edges) between them. This makes complex patterns like fan-out (one task feeding many) and fan-in (many tasks feeding one) natural.
Example:
import dev.shaaf.jgraphlet.*;
import java.util.Map;
import java.util.concurrent.CompletableFuture;
try (TaskPipeline pipeline = new TaskPipeline()) {
Task<String, String> fetchInfo = (id, ctx) -> CompletableFuture.supplyAsync(() -> "Info for " + id);
Task<String, String> fetchFeed = (id, ctx) -> CompletableFuture.supplyAsync(() -> "Feed for " + id);
Task<Map<String, Object>, String> combine = (inputs, ctx) -> CompletableFuture.supplyAsync(() ->
inputs.get("infoNode") + " | " + inputs.get("feedNode")
);
pipeline.addTask("infoNode", fetchInfo)
.addTask("feedNode", fetchFeed)
.addTask("summaryNode", combine);
pipeline.connect("infoNode", "summaryNode")
.connect("feedNode", "summaryNode");
String result = (String) pipeline.run("user123").join();
System.out.println(result); // "Info for user123 | Feed for user123"
}2. Two Task Styles: Task<I,0> and SyncTask<I,0>
JGraphlet provides two distinct task types you can mix and match:
- Task<I, O> (Async): Returns a
CompletableFuture<O>. Perfect for I/O operations or heavy computations. - SyncTask<I, O> (Sync): Returns a direct
O. Ideal for fast, CPU-bound operations.
Example:
try (TaskPipeline pipeline = new TaskPipeline()) {
Task<String, String> fetchName = (userId, ctx) ->
CompletableFuture.supplyAsync(() -> "John Doe");
SyncTask<String, String> toUpper = (name, ctx) -> name.toUpperCase();
pipeline.add("fetch", fetchName)
.then("transform", toUpper);
String result = (String) pipeline.run("user-42").join();
System.out.println(result); // "JOHN DOE"
}3. A Simple, Explicit API
JGraphlet avoids complex builders or magic configurations. The API is lean and explicit:
- Create a pipeline:
new TaskPipeline() - Register nodes:
addTask("uniqueId", task) - Wire them up:
connect("fromId", "toId")
Example:
try (TaskPipeline pipeline = new TaskPipeline()) {
SyncTask<String, Integer> lengthTask = (s, c) -> s.length();
SyncTask<Integer, String> formatTask = (i, c) -> "Length is " + i;
pipeline.addTask("calculateLength", lengthTask);
pipeline.addTask("formatOutput", formatTask);
pipeline.connect("calculateLength", "formatOutput");
String result = (String) pipeline.run("Hello").join();
System.out.println(result); // "Length is 5"
}4. A Clear Fan-In Input Shape
A fan-in task receives a Map<String, Object>, where keys are parent task IDs and values are their results.
Example:
try (TaskPipeline pipeline = new TaskPipeline()) {
SyncTask<String, String> fetchUser = (id, ctx) -> "User: " + id;
SyncTask<String, String> fetchPerms = (id, ctx) -> "Role: admin";
Task<Map<String, Object>, String> combine = (inputs, ctx) -> CompletableFuture.supplyAsync(() -> {
String userData = (String) inputs.get("userNode");
String permsData = (String) inputs.get("permsNode");
return userData + " (" + permsData + ")";
});
pipeline.addTask("userNode", fetchUser)
.addTask("permsNode", fetchPerms)
.addTask("combiner", combine);
pipeline.connect("userNode", "combiner").connect("permsNode", "combiner");
String result = (String) pipeline.run("user-1").join();
System.out.println(result); // "User: user-1 (Role: admin)"
}5. A Clear Run Contract
Executing a pipeline is straightforward: pipeline.run(input) returns a CompletableFuture for the final result. You can block with .join() or use async chaining.
Example:
String input = "my-data";
// Blocking approach
try {
String result = (String) pipeline.run(input).join();
System.out.println("Result (blocking): " + result);
} catch (Exception e) {
System.err.println("Pipeline failed: " + e.getMessage());
}
// Non-blocking approach
pipeline.run(input)
.thenAccept(result -> System.out.println("Result (non-blocking): " + result))
.exceptionally(ex -> {
System.err.println("Async pipeline failed: " + ex.getMessage());
return null;
});6. A Built-In Resource Lifecycle
JGraphlet implements AutoCloseable. Use try-with-resources to guarantee safe shutdown of internal resources.
Example:
try (TaskPipeline pipeline = new TaskPipeline()) {
pipeline.add("taskA", new SyncTask<String, String>() {
@Override
public String executeSync(String input, PipelineContext context) {
if (input == null) {
throw new IllegalArgumentException("Input cannot be null");
}
return "Processed: " + input;
}
});
pipeline.run("data").join();
} // pipeline.shutdown() is called automatically
System.out.println("Pipeline resources have been released.");7. Context
PipelineContext is a thread-safe, per-run workspace for metadata.
Example:
SyncTask<String, String> taskA = (input, ctx) -> {
ctx.put("requestID", "xyz-123");
return input;
};
SyncTask<String, String> taskB = (input, ctx) -> {
String reqId = ctx.get("requestID", String.class).orElse("unknown");
return "Processed input " + input + " for request: " + reqId;
};8. Optional Caching
Tasks can opt into caching to prevent re-computation.
Example:
Task<String, String> expensiveApiCall = new Task<>() {
@Override
public CompletableFuture<String> execute(String input, PipelineContext context) {
System.out.println("Performing expensive call for: " + input);
return CompletableFuture.completedFuture("Data for " + input);
}
@Override
public boolean isCacheable() { return true; }
};
try (TaskPipeline pipeline = new TaskPipeline()) {
pipeline.add("expensive", expensiveApiCall);
System.out.println("First call...");
pipeline.run("same-key").join();
System.out.println("Second call...");
pipeline.run("same-key").join(); // Result is from cache
}The result is a clean, testable way to orchestrate synchronous or asynchronous tasks for composing complex flows like parallel retrieval, merging, judging, and guardrails — without bringing in a heavyweight workflow engine. Here are some links if you want to learn more or try it out:
