Data Transformation: XML to JSON And JSON to XML With Apache Camel

DZone's Guide to

Data Transformation: XML to JSON And JSON to XML With Apache Camel

In this tutorial, you will learn how to achieve data transformation by converting XML to JSON and JSON to XML with Apache Camel.

· Integration Zone
Free Resource

The Integration Zone is brought to you in partnership with Cloud Elements. What's below the surface of an API integration? Download The Definitive Guide to API Integrations to start building an API strategy.

1.0 Overview

Apache Camel provides a rich set of libraries to perform XML to JSON and JSON to XML transformation.

  • marshalling => converting from XML to JSON
  • un-marshaling => converting from JSON to XML.

2.0 Explicitly Instantiating the DataFormat

We need to instantiate the XmlJsonDataFormat from package org.apache.camel.dataformat.xmljson.XmlJsonDataFormat and make sure that camel-xmljson is added in your pom.xml or an installed camel-xmljson feature.

XmlJsonDataFormat xmlJsonFormat = new XmlJsonDataFormat();

2.1 XmlJsonDataFormat Property

XmlJsonDataFormat xmlJsonFormat = new XmlJsonDataFormat();
xmlJsonFormat.setEncoding("UTF-8");
xmlJsonFormat.setForceTopLevelObject(true);
xmlJsonFormat.setTrimSpaces(true);
xmlJsonFormat.setRootName("Employee");
xmlJsonFormat.setSkipNamespaces(true);
xmlJsonFormat.setRemoveNamespacePrefixes(true);
xmlJsonFormat.setExpandableProperties(Arrays.asList("d", "e"));

These properties are not mandatory and can be used when you want to tune the message.

2.2 Marshalling/Unmarshalling

Once XMLJsonDataFormat is instantiated, the next step is to use it as a parameter to  marshal() unmarshal()  DSL elements.

Marshalling (converting from XML to JSON):

from("direct:unMarshalEmployeejson2xml")
                .unmarshal(xmlJsonFormat)
                .to("log:?level=INFO&showBody=true");

Un-Marshalling (converting from JSON to XML):

  from("direct:marshalEmployeexml2json")
                .marshal(xmlJsonFormat)
                .to("log:?level=INFO&showBody=true");

3.0 Defining Data Format In-Line

It is also possible to define the data format inline using the xmljson() DSL element:

  from("direct:unMarshalEmployeejson2xml")
                .unmarshal().xmljson()
                .to("log:?level=INFO&showBody=true");


from("direct:marshalEmployeexml2json")
                .marshal().xmljson()
                .to("log:?level=INFO&showBody=true");

It is also possible to pass Map to the inline method, as shown below.

Map<String, String> xmlJsonOptions = new HashMap<String, String>();

xmlJsonOptions.put(org.apache.camel.model.dataformat.XmlJsonDataFormat.ENCODING, "UTF-8");
xmlJsonOptions.put(org.apache.camel.model.dataformat.XmlJsonDataFormat.ROOT_NAME, "Employee");
xmlJsonOptions.put(org.apache.camel.model.dataformat.XmlJsonDataFormat.SKIP_NAMESPACES, "true");
xmlJsonOptions.put(org.apache.camel.model.dataformat.XmlJsonDataFormat.REMOVE_NAMESPACE_PREFIXES, "true");
xmlJsonOptions.put(org.apache.camel.model.dataformat.XmlJsonDataFormat.EXPANDABLE_PROPERTIES, "d e");

 from("direct:unMarshalEmployeejson2xml")
                .unmarshal().xmljson(xmlJsonOptions)
                .to("log:?level=INFO&showBody=true");

from("direct:marshalEmployeexml2json")
                .marshal().xmljson(xmlJsonOptions)
                .to("log:?level=INFO&showBody=true");

4.0 POM Dependency

We need to add some dependencies into the pom file to perform XML2JSON and JSON2XML transformation.

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>

    <groupId>com.learncamel</groupId>
    <artifactId>learncamel-transform</artifactId>
    <version>1.0-SNAPSHOT</version>
    <dependencies>
        <dependency>
            <groupId>org.apache.camel</groupId>
            <artifactId>camel-core</artifactId>
            <version>2.19.1</version>
        </dependency>
        <dependency>
            <groupId>org.apache.camel</groupId>
            <artifactId>camel-test</artifactId>
            <version>2.19.1</version>
        </dependency>
        <dependency>
            <groupId>org.apache.camel</groupId>
            <artifactId>camel-xmljson</artifactId>
            <version>2.19.0</version>
        </dependency>
        <dependency>
            <groupId>xom</groupId>
            <artifactId>xom</artifactId>
            <version>1.2.5</version>
        </dependency>

        <dependency>
            <groupId>commons-logging</groupId>
            <artifactId>commons-logging</artifactId>
            <version>1.1.3</version>
        </dependency>

        <dependency>
            <groupId>net.sf.ezmorph</groupId>
            <artifactId>ezmorph</artifactId>
            <version>1.0.6</version>
        </dependency>

        <dependency>
            <groupId>commons-collections</groupId>
            <artifactId>commons-collections</artifactId>
            <version>3.2.1</version>
        </dependency>

        <dependency>
            <groupId>commons-beanutils</groupId>
            <artifactId>commons-beanutils</artifactId>
            <version>1.8.3</version>
        </dependency>

        <dependency>
            <groupId>org.slf4j</groupId>
            <artifactId>slf4j-api</artifactId>
            <version>1.7.12</version>
        </dependency>
        <dependency>
            <groupId>org.slf4j</groupId>
            <artifactId>slf4j-log4j12</artifactId>
            <version>1.7.12</version>
        </dependency>
    </dependencies>
</project>

5.0 Code

5.1 Defining Route

package com.learncamel.route.xml2json;

import org.apache.camel.Route;
import org.apache.camel.builder.RouteBuilder;
import org.apache.camel.dataformat.xmljson.XmlJsonDataFormat;

public class XML2JSONRoute extends RouteBuilder {

    public void configure() throws Exception {

        from("direct:marshalEmployeexml2json")
                .to("log:?level=INFO&showBody=true")
                .marshal().xmljson()
                .to("log:?level=INFO&showBody=true");


        final XmlJsonDataFormat xmlJsonFormat = new XmlJsonDataFormat();
        xmlJsonFormat.setRootName("Employee");

        from("direct:unMarshalEmployeejson2xml")
                //.unmarshal().xmljson()
                .unmarshal(xmlJsonFormat)
                .to("log:?level=INFO&showBody=true");

    }
}

5.2 Unit Test

To test the above routes, you can define unit test cases and you will require the camel-test feature installed, or it can be added into the pom.xml dependency.

package com.learncamel.route.xml2json;

import org.apache.camel.builder.RouteBuilder;
import org.apache.camel.test.junit4.CamelTestSupport;
import org.junit.Test;


public class XML2JSONRouteTest extends CamelTestSupport {

    @Override
    protected RouteBuilder createRouteBuilder() throws Exception {
        return new XML2JSONRoute();
    }

    @Test
    public void marshalEmployeeJSON2XML(){

        String expected = "{\"id\":\"123 \",\"name\":\"ABC\",\"type\":\"senior\"}";
        String request = "<?xml version=\"1.0\" encoding=\"UTF-8\"?>\r\n" +
                "<Employee><id>123 </id><name>ABC</name><type>senior</type></Employee>\r\n";

        final String response = template.requestBody("direct:marshalEmployeexml2json", request, String.class);
        System.out.println("response is : " + response);

        assertEquals(expected, response);

    }

    @Test
    public void unMarshalEmployeeJSON2XML(){

        final String request = "{\"name\":\"ABC\",\"id\":\"123 \",\"type\":\"senior\"}";

        final String response = template.requestBody("direct:unMarshalEmployeejson2xml", request, String.class);
        System.out.println("response is : " + response);
        String expected = "<?xml version=\"1.0\" encoding=\"UTF-8\"?>\r\n" +
                "<Employee><id>123 </id><name>ABC</name><type>senior</type></Employee>\r\n";
        assertEquals(expected, response);

    }
}

Now, you know how to convert XML to JSON and JSON to XML with Apache Camel.
