A Hands-On ABAP RESTful Programming Model Guide

In the SAP ABAP world, BAPIs (Business Application Programming Interfaces) have long been the standard for programmatic access to business functionality. These are essentially RFC-enabled function modules representing operations on business objects.

However, with the advent of SAP S/4HANA and the new ABAP RESTful Application Programming Model (RAP), the classic BAPI approach is being phased out in favor of modern, RAP-based APIs. SAP now provides a new generation of released APIs built on RAP, often referred to as RAP BO interfaces or behavior definitions, which align with the clean core and cloud-ready strategy of S/4HANA.

Why Replace BAPIs With RAP-Based APIs?

For expert ABAP developers, the motivation to migrate from BAPIs to RAP interfaces comes down to modernization, maintainability, and future-proofing.

In fact, SAP considers RAP business object interfaces the modern alternative to classic BAPIs. Here are some key reasons to make the switch:

Clean Core and Upgrade Safety

RAP interfaces are part of SAP’s clean core strategy. They are released and maintained by SAP, ensuring that your custom code calls stable, upgrade-safe APIs instead of custom wrappers or unofficial function modules. This means less retrofitting when you upgrade your S/4HANA system.

Cloud Readiness

In SAP S/4HANA Cloud, many traditional BAPIs are not whitelisted or available. RAP-based APIs, on the other hand, are designed for cloud use and adhere to strict SAP release contracts. They can be used in both private and public cloud editions as officially supported integration points.

Modern API Design

RAP uses contemporary ABAP development paradigms, CDS views for data modeling, behavior definitions (BDEF) for business logic, and OData/HTTP exposure by design. Instead of procedural function calls, you interact with entities through a standardized interface. This leads to clearer, more maintainable code and aligns with how SAP Fiori apps communicate. In essence, RAP interfaces provide a modern, RESTful facade over business objects, whereas BAPIs are older RPC-style calls.

Built-in Transaction Handling

Classic BAPIs often require manual transaction control. RAP introduces the Entity Manipulation Language (EML), which handles operations in a transactional context. You can bundle multiple operations on related entities and then perform one commit for all — simplifying the code and reducing errors. We’ll see this in the example below.

Extensibility and Lifecycle Management

RAP business object interfaces allow you to expose only what is needed to consumers, supporting versioning and gradual enhancements. They act as a stable facade while the underlying logic can evolve without breaking external contracts. This is analogous to how BAPIs provided stable interfaces in the past, but RAP makes it more flexible. In short, RAP BO interfaces let you keep your core objects clean and internal, exposing a controlled API layer to the outside world.

Given these benefits, SAP recommends using a released RAP API whenever one is available for your scenario. Next, let's walk through a hands-on example of replacing a common BAPI with an RAP-based API in an S/4HANA 2022 system.

ABAP RAP in S/4HANA 2022 at a Glance

SAP S/4HANA 2022 includes the ABAP Platform 2022, which significantly expands RAP’s capabilities and the number of standard business objects exposed via RAP. Many operations that used to be performed with BAPIs now have equivalent released RAP BO interfaces provided by SAP. These interfaces are essentially pre-built RAP business objects that SAP delivers for developers to use instead of calling older BAPIs. For example:

• Bank creation: BAPI_BANK_CREATE to I_BANKTP (RAP Business Object interface)
• Cost center creation: BAPI_COSTCENTER_CREATE to I_COSTCENTERTP_2 (RAP BO interface)
• Sales order creation: BAPI_SALESORDER_CREATEFROMDAT2 to I_SALESORDERTP (RAP BO interface successor)

These are just a few examples; SAP provides a growing list of such RAP-based APIs for S/4HANA 2022 and beyond. Each interface typically comes with documentation and code snippets to demonstrate how to consume it. If you are unsure whether a particular BAPI has an RAP equivalent, SAP’s Clean Core Object search tool can help identify if a released RAP interface (BDEF) exists for that business object.

Hands-On Example: Modernizing a BAPI to RAP

To make this concrete, let’s walk through replacing a classic BAPI with a RAP-based implementation. We’ll use the task of creating a Sales Order as our example. In the past, an ABAP developer might use the BAPI BAPI_SALESORDER_CREATEFROMDAT2 to programmatically create a sales order in SAP ECC or S/4HANA.

In S/4HANA 2022, SAP provides the RAP business object interface I_SALESORDERTP as the official successor for this BAPI. We’ll demonstrate how to identify the replacement and implement the create operation using RAP.

Step 1: Identify the RAP Replacement Interface

First, determine if a released RAP API exists for the BAPI in question. In our case, we discovered that I_SALESORDERTP is the released RAP interface corresponding to the Sales Order business object (as a replacement for BAPI_SALESORDER_CREATEFROMDAT2). This interface is delivered by SAP as part of S/4HANA 2022. You can find such mappings via SAP documentation or tools; for instance, SAP's help docs and community posts confirm that I_SALESORDERTP covers create/read/update operations for sales orders via RAP. Once the appropriate interface is identified, you can plan to refactor your code to use it.

Step 2: Review the Classic BAPI Usage (For Comparison)

Let's briefly recap how the classic BAPI would be used to create a sales order. Typically, one would call the function module and then commit the work, for example:

DATA: lt_return TYPE TABLE OF bapiret2.
CALL FUNCTION 'BAPI_SALESORDER_CREATEFROMDAT2'
  EXPORTING
    order_header_in = ls_order_header   " header data structure
  TABLES
    order_items_in  = lt_items          " item lines to create
    return          = lt_return.        " return messages
IF sy-subrc = 0 AND ( NOT line_exists( lt_return[ type = 'E' ] ) ).
  " If no errors, commit the transaction to finalize the create
  CALL FUNCTION 'BAPI_TRANSACTION_COMMIT'
    EXPORTING wait = 'X'.
ENDIF.

In the above pseudocode, we populate structures for the sales order header and items, call the BAPI, then explicitly call BAPI_TRANSACTION_COMMIT to ensure the new order is saved. We also have to check the return table for errors or messages. This imperative style works, but it requires handling commits manually and ensuring the data structures match what the BAPI expects. It also doesn’t automatically integrate with OData or modern Fiori UI frameworks without creating a custom OData service on top.

Step 3: Implement the RAP-Based Create via EML

Now, let's perform the same operation using the RAP interface I_SALESORDERTP and ABAP’s Entity Manipulation Language. With RAP, you don't call a function module; instead, you use EML statements on the interface’s entities. Suppose we want to create a sales order with one line item. We can do it in one shot as follows:

DATA(ls_failed)   = REF #( ).
DATA(ls_reported) = REF #( ).

MODIFY ENTITIES OF i_salesordertp
  ENTITY salesorder
    CREATE FIELDS ( salesordertype salesorganization distributionchannel
                    organizationdivision soldtoparty purchaseorderbycustomer )
    WITH VALUE #( ( %cid = 'H001'       " temporary ID for the new order
                    %data = VALUE #(
                      salesordertype         = 'TA'      " Order type
                      salesorganization      = '1010'    " Sales Org
                      distributionchannel    = '10'      " Distribution Channel
                      organizationdivision   = '00'      " Division
                      soldtoparty            = '0010100001'  " Sold-to Customer ID
                      purchaseorderbycustomer= 'PO-12345'   " Customer PO reference
                    ) ) )
    CREATE BY \_item                            " now specify the item(s)
      FIELDS ( product requestedquantity )
      WITH VALUE #( ( %cid_ref = 'H001'         " link to the order with temp ID
                      %target  = VALUE #( ( %cid = 'I001'   " temp ID for new item
                                           product           = 'MAT-1000'
                                           requestedquantity = 5 ) ) ) )
  FAILED   DATA(ls_failed)
  REPORTED DATA(ls_reported).

In this code snippet, we use the MODIFY ENTITIES OF i_salesordertp statement to perform a deep create of a SalesOrder along with one SalesOrderItem. A few things to note from an engineer’s perspective:

• We specify the fields we want to set for the sales order and its item, similar to filling out the BAPI’s parameters, but here it's done with a structured syntax using WITH VALUE #(...) expressions. This ensures compile-time checking of field names and data types.
• The use of %cid (client ID) and %cid_ref is a mechanism to link the parent and child in one request. We assign a temporary ID 'H001' to the new sales order, and then reference it (%cid_ref = 'H001') when creating the item, so that the framework knows this item belongs to the new order. This allows creating a header and its items together in one call (a deep insert), which is handled seamlessly by RAP.
• The FAILED DATA(ls_failed) and REPORTED DATA(ls_reported) clauses serve to capture any errors or messages from the operation. This is analogous to checking the BAPI return table. If the create fails the ls_failed structure would contain the failed keys and error details. The ls_reported can hold messages or generated keys.

At this point, the sales order is created in memory. To finalize and commit it to the database, we need to execute a commit in the RAP context.

Step 4: Finalize With Commit

In an interactive RAP scenario (like a Fiori app), the commit is managed by the framework when the user saves their changes. But in our manual ABAP code (above), we explicitly trigger the commit. In RAP, this is done using COMMIT ENTITIES rather than the classic BAPI_TRANSACTION_COMMIT. For example:

COMMIT ENTITIES EXPORTING RESPONSE OF i_salesordertp
  FAILED   DATA(ls_save_failed)
  REPORTED DATA(ls_save_reported).
IF sy-subrc <> 0.
  " Handle the error (e.g., log the messages in ls_save_reported)
ENDIF.

COMMIT ENTITIES will finalize all pending changes made by EML statements. Here, we also capture any final errors or messages in ls_save_failed/ls_save_reported for error handling. After this commit, the sales order is persisted, and the actual Sales Order number is available. SAP RAP supports late numbering, meaning the real keys might only be assigned at commit time, a detail to be aware of. You can retrieve the final keys using the CONVERT KEY statement if needed, but for our purposes, assume the commit gives us the new order number in the reported data.

Now we have successfully created a sales order using the RAP API instead of the classic BAPI. The code is more declarative and leverages the RAP framework for integrity checks and relationships. We didn't have to call any function modules directly; everything was done through the RAP interface of the Sales Order business object.

Engineer’s Perspective: Key Takeaways

From the above process, a few important differences stand out when replacing BAPIs with RAP-based APIs:

• Finding the right interface: It may require a bit of research to find the correct RAP interface name for a given legacy BAPI. SAP provides documentation to help with this. Once found, using the RAP interface ensures you are calling an SAP-supported API that will remain stable across updates.
• Refactoring effort: Replacing a BAPI call with a RAP call is not a one-to-one code replacement; it often involves refactoring. You will define data structures according to RAP’s CDS-based types and use EML syntax. There is a learning curve, but the benefit is cleaner ABAP code that is easier to maintain. Tools in ABAP Development Tools (ADT) can help by autocompleting structure components and EML keywords, since the interface and its types are known in the dictionary.
• Behavior and validation: When you use RAP interfaces, you automatically leverage SAP’s implemented behavior logic. For instance, any checks or defaulting logic SAP built into the Sales Order RAP BO will execute. You no longer manually call multiple BAPIs or perform intermediate checks; the RAP framework triggers all the necessary business logic as part of the modify/commit process. This leads to fewer errors and a more consistent outcome with standard SAP behavior.
• Transaction management: As shown, instead of BAPI_TRANSACTION_COMMIT, you use COMMIT ENTITIES. This aligns with the unit of work paradigm in RAP. It also allows bundling multiple operations.
• Upgrade and extensibility: By adopting RAP-based APIs, your custom code is positioned for the future. SAP will continue to enhance these interfaces, and you can opt in to those changes by switching to a new interface version or extending the CDS views. In contrast, classic BAPIs in S/4HANA are largely in maintenance mode; they exist mainly for backward compatibility and might not cover new business scenarios introduced in S/4HANA. Moving to RAP ensures you can take advantage of new SAP innovations with minimal effort.

Conclusion

Replacing BAPIs with RAP-based APIs is a strategic move for any ABAP developer working on S/4HANA 2022 and beyond. It aligns your custom developments with SAP’s modern, cloud-ready programming model.

As we’ve seen, a classic scenario like sales order creation can be accomplished with RAP’s EML in a way that is more in line with modern development practices, yielding cleaner and more robust code. SAP itself positions RAP Business Object interfaces as the evolution of BAPIs, a way to build stable, public APIs that keep the core clean and extensible.

While there is an upfront effort to learn RAP and refactor existing code, the payoff is significant in the long run, with better maintainability, fewer upgrade headaches, and the ability to run your extensions in the cloud. Importantly, whenever SAP provides a released RAP API to replace a classic BAPI, you should take that path. By doing so, you leverage SAP’s latest technology and ensure your solutions remain supported in future releases.
