With the advent of Continuous Integration and Continuous Delivery, our builds are split into different steps creating the deployment pipeline. Some of these steps can be compiled and run fast tests, run slow tests, run automated acceptance tests, or releasing the application, to cite a few.
Most of us are using
Jenkins/Hudson to implement
Continuous Integration/Delivery, and we manage job orchestration combining some
Jenkins plugins like
downstream-ext. We have to configure all of them which implies polluting the job configuration through multiple jobs, which , makes the system configuration very complex to maintain.
Build Flow enables us to define an upper level flow item to manage job orchestration and link up rules, using a dedicated
Let's see a very simple example:
First step is installing the plugin.
Go to Jenkins -> Manage Jenkins -> Plugin Manager -> Available and find for CloudBees Build Flowplugin.
Then you can go to
Jenkins -> New Job and you will see a new kind of job called
Build Flow. In this example we are going to name it
And now you only have to program using flow
DSL how this job should orchestrate the other jobs.
Define build flow using flow DSL" input text you can specify the sequence of commands to execute.
In current example I have already created two jobs, one executing
clean compile goal (
yy-compile job name) and the other one executing
javadoc goal (
yy-javadoc job name). I know that this deployment pipeline is not real in a true environment but for now it is enough.
Then we want javadoc job running after project is compiled.
To configure this we don't have to create any upstream or downstream actions, simply add next lines at
DSL text area:
Save and execute
build-all-yy job and both projects will be built in a sequential way.
Now suppose that we add a third job called
yy-sonar which runs
sonar goal that generates code quality sonar report. In this case it seems obvious that after project is compiled, generation of javadocs and code quality jobs can be run in parallel. So script is changed to:
This plugin also supports more operations like
retry (similar behaviour of
retry-failed-job plugin) or
guard-rescue, that it works mostly like a try+finally block. Also you can create parameterized builds, accessing to build execution or printing to Jenkins console. Next example will print build number of
yy-compile job execution:
b = build("yy-compile")
And finally you can also have a quick graphical overview of the execution in
Status section. It is true that could be improved more, but for now it is acceptable, and can be used without any problem.
Build Flow plugin is in its early stages, in fact it is only at
version 0.4. But will be a plugin to be considered in future, and I think it is good to know that it exists. Moreover is being developed by
CloudBees folks so it is a guarantee of being fully supported by
We Keep Learning.
Warning: In order to run parallel tasks with the plugin
Anonymous users must have
Read Job access (
Jenkins -> Manage Jenkins -> Configure System). There is an issue already inserted into
Jira to fix this problem.
