Cascading Dropdown List in Blazor Using EF Core

DZone's Guide to

Cascading Dropdown List in Blazor Using EF Core

In this article, we are going to create a cascading dropdown list in Blazor using the Entity Framework Core database first approach.

· Web Dev Zone ·
Free Resource

Deploying code to production can be filled with uncertainty. Reduce the risks, and deploy earlier and more often. Download this free guide to learn more. Brought to you in partnership with Rollbar.

In this article, we are going to create a cascading dropdown list in Blazor using the Entity Framework Core database first approach. We will create two dropdown lists - Country and City. On selecting the value from the Country dropdown, we will change the value of the City dropdown.

We will be using Visual Studio 2017 and SQL Server 2014.

Let's take a look at the final product.

Prerequisites

  • Install .NET Core 2.1 Preview 2 SDK from here.
  • Install Visual Studio 2017 v15.7 or above from here.
  • Install ASP.NET Core Blazor Language Services extension from here.
  • SQL Server 2008 or above.

Blazor framework is not supported by versions below Visual Studio 2017 v15.7.

Source Code

Before proceeding, I would recommend you to get the source code from GitHub.

Creating Tables

We will be using two tables to store our data.

  1. Country: Used to store the name of countries in our app. It contains two fields - CountryId and CountryName.
  2. Cities: This contains the list of cities for the countries we insert in Country table. It contains three fields - CityIdCountryId, and CityName. The CountryId column is a foreign key referring to CountryId in Country table.

Execute the following commands to create both tables:

CREATE TABLE Country
(
CountryId VARCHAR(5) PRIMARY KEY,
CountryName VARCHAR(20) NOT NULL
)
GO

CREATE TABLE Cities
(
CityId VARCHAR(5) PRIMARY KEY,
CountryId VARCHAR(5) FOREIGN KEY REFERENCES Country(CountryId),
CityName VARCHAR(20) NOT NULL
)
GO

Now we will put some data in both the tables. Open the Country table and execute the following insert statement.

INSERT INTO Country VALUES ('C1', 'India')
INSERT INTO Country VALUES ('C2', 'China')
INSERT INTO Country VALUES ('C3', 'USA')

Execute the following insert statements to insert data into the Cities table.

INSERT INTO Cities VALUES ('P1','C1','New Delhi')
INSERT INTO Cities VALUES ('P2','C1','Mumbai')
INSERT INTO Cities VALUES ('P3','C1','Chennai')
INSERT INTO Cities VALUES ('P4','C1','Hyderabad')
INSERT INTO Cities VALUES ('P5','C1','Bengaluru')
INSERT INTO Cities VALUES ('P6','C2','Beijing')
INSERT INTO Cities VALUES ('P7','C2','Shanghai')
INSERT INTO Cities VALUES ('P8','C2','Hong Kong')
INSERT INTO Cities VALUES ('P9','C2','Macau')
INSERT INTO Cities VALUES ('P10','C3','New York')
INSERT INTO Cities VALUES ('P11','C3','Chicago')
INSERT INTO Cities VALUES ('P12','C3','Las Vegas')

Create a Blazor Web Application

Open Visual Studio and select File >> New >> Project.

After selecting the project, a "New Project" dialog will open. Select .NET Core inside the Visual C# menu from the left-hand panel. Then, select "ASP.NET Core Web Application" from the available project types. Set the name of the project as BlazorDDL and press OK.

After clicking on OK, a new dialog will open asking you to select the project template. You will see two dropdown menus at the top left of the template window. Select ".NET Core" and "ASP.NET Core 2.0" from these dropdowns. Then, select the "Blazor (ASP .NET Core hosted)" template and press OK.

Now, our Blazor solution will be created. You will see a folder structure in Solution Explorer as shown in the below image.

You can observe that we have three project files created inside this solution.

  1. BlazorDDL.Client - It has the client-side code and contains the pages that will be rendered on the browser.
  2. BlazorDDL.Server - It has the server-side code, such as DB related operations and Web API.
  3. BlazorDDL.Shared - It contains the shared code that can be accessed by both the client and server.

Scaffolding the Model to the Application

We are using the Entity Framework core database first approach to create our models. We will create our model class in BlazorDDL.Shared project so that it can be accessible to both the client and server projects.

Navigate to Tools >> NuGet Package Manager >> Package Manager Console. Select "BlazorDDL.Shared" from Default project dropdown. Refer to the image below:

First, we will install the package for the database provider that we are targeting, which is SQL Server in this case. Hence, run the following command:

Install-Package Microsoft.EntityFrameworkCore.SqlServer

Since we are using Entity Framework Tools to create a model from the existing database, we will install the tools package as well. Hence, run the following command:

Install-Package Microsoft.EntityFrameworkCore.Tools

After you have installed both the packages, we will scaffold our model from the database tables using the following command:

Scaffold-DbContext "Your connection string here" Microsoft.EntityFrameworkCore.SqlServer -OutputDir Models -Tables Country, Cities

Do not forget to put in your own connection string (inside the " "). After this command gets executed successfully, you will notice that a Models folder has been created and it contains three class files myTestDBContext.cs, Cities.cs, and Country.cs. And hence we have successfully scaffolded our Models using EF core database first approach.

At this point, the Models folder will have the following structure.

Creating a Data Access Layer for the Application

Right click on BlazorDDL.Server project and then select Add >> New Folder and name the folder as DataAccess. We will be adding our class to handle database related operations inside this folder only.

Right click on DataAccess folder and select Add >> Class. Name your class DataAccessClass.cs. This class will handle our database related operations.

Open DataAccessLayer.cs and put the following code into it.

using BlazorDDL.Shared.Models;
using System;
using System.Collections.Generic;
using System.Linq;
using System.Threading.Tasks;

namespace BlazorDDL.Server.DataAcces
{
    public class DataAccessLayer
    {
        myTestDBContext db = new myTestDBContext();

        public IEnumerable<Country> GetAllCountries()
        {
            try
            {
                return db.Country.ToList();
            }
            catch
            {
                throw;
            }
        }

        public IEnumerable<Cities> GetCityData(string id)
        {
            try
            {
                List<Cities> lstCity = new List<Cities>();
                lstCity = (from CityName in db.Cities where CityName.CountryId == id select CityName).ToList();

                return lstCity;
            }
            catch
            {
                throw;
            }
        }
    }
}

Here we have defined two methods

  1. GetAllCountries - It will fetch all the country data from the country table.
  2. GetCityData - It will fetch the city data corresponding to the country id provided to it.

Hence, our data access layer is complete. Now, we will proceed to create our Web API Controller.

Adding the web API Controller to the Application

Right click on BlazorDDL.Server/Controllers folder and select Add >> New Item. An "Add New Item" dialog box will open. Select ASP.NET from the left-hand panel, then select "API Controller Class" from the templates panel and set the name as CountriesController.cs. Press Add.

This will create our API CountriesController class.

We will call the methods for DataAccess Layer class to fetch data and pass it on the data to the client-side.

Open CountriesController.cs file and put the following code into it.

using System;
using System.Collections.Generic;
using System.Linq;
using System.Threading.Tasks;
using BlazorDDL.Server.DataAcces;
using BlazorDDL.Shared.Models;
using Microsoft.AspNetCore.Mvc;
using Microsoft.AspNetCore.Http;

namespace BlazorDDL.Server.Controllers
{
    public class CountriesController : Controller
    {
        DataAccessLayer objCountry= new DataAccessLayer();

        [HttpGet]
        [Route("api/Countries/GetCountryList")]
        public IEnumerable<Country> GetCountryList()
        {
            return objCountry.GetAllCountries();
        }

        [HttpGet]
        [Route("api/Countries/GetCities/{id}")]
        public IEnumerable<Cities> GetCities(string id)
        {
            return objCountry.GetCityData(id);
        }
    }
}

At this point, our BlazorDDL.Server project has the following structure.

We are done with our backend logic. Therefore, we will now proceed to code our client side.

Adding Razor View to the Application

Right click on BlazorDDL.Client/Pages folder and then select Add >> New Item. An "Add New Item" dialog box will open, select Web from the left-hand panel, then select "Razor View" from the templates panel and name it CountryData.cshtml.

This will add a CountryData.cshtml page to our BlazorDDL.Client/Pages folder.

Open the CountryData.cshtml page and put the following code into it.

@using BlazorDDL.Shared.Models
@page "/country"
@inject HttpClient Http

<h1>Country Data</h1>

<p>This component demonstrates cascading dropdownlist using EntityFrameWork Core</p>
<hr />

@if (countryList == null)
{
    <p><em>Loading...</em></p>
}
else
{
    <div class="row">
        <div class="col-md-4">
            <label for="Country" class="control-label">Country</label>
        </div>
        <div class="col-md-4">
            <label asp-for="Cities" class="control-label">Cities</label>
        </div>
    </div>
    <div class="row" style="padding-top:10px">
        <div class="col-md-4">
            <select class="form-control" onchange="@CountryClicked">
                <option value="">-- Select Country --</option>
                @foreach (var country in countryList)
                {
                    <option value="@country.CountryId">@country.CountryName</option>
                }
            </select>
        </div>
        <div class="col-md-4">
            <select class="form-control" onchange="@CityClicked">
                <option value="">-- Select City --</option>
                @if (cityList != null)
                {
                    @foreach (var city in cityList)
                    {
                        <option value="@city.CityName">@city.CityName</option>
                    }
                }
            </select>
        </div>
    </div>
    <div class="row" style="padding-top:50px">
        <div class="col-md-4">
            <label class="control-label">Country Name: @countryName</label>
        </div>
        <div class="col-md-4">
            <label class="control-label">City Name: @cityName</label>
        </div>
    </div>

}

@functions {

List<Country> countryList = new List<Country>();
List<Cities> cityList = new List<Cities>();

string countryId { get; set; }
string countryName { get; set; }
string cityName { get; set; }

protected override async Task OnInitAsync()
{
    countryList = await Http.GetJsonAsync<List<Country>>("api/Countries/GetCountryList");
}

protected async void CountryClicked(UIChangeEventArgs countryEvent)
{
    cityList.Clear();
    cityName = string.Empty;

    countryId = countryEvent.Value.ToString();
    countryName = countryList.FirstOrDefault(s => s.CountryId == countryId).CountryName;

    cityList = await Http.GetJsonAsync<List<Cities>>("api/Countries/GetCities/" + countryId);
    this.StateHasChanged();
}

void CityClicked(UIChangeEventArgs cityEvent)
{
    cityName = cityEvent.Value.ToString();
    this.StateHasChanged();
}

}

Let's understand this code.

At the top, we have included the BlazorDDL.Shared.Models namespace so that we can use our Country and Cities model classes in this page. We are defining the route of this page using the @page directive. So, in this application, if we append "/country" to the base URL then we will be redirected to this page. We are also injecting the HttpClient service to enable Web API calls.

Then we have defined the HTML section to display two dropdown lists on our web page. We are calling the CountryClicked method on the onchange event of the Country dropdown. This method will call the  GetCites Web API method to fetch the city data from the Cities table corresponding to the CountryId of the selected country. We are also setting the value of the countryName property to the selected country. The StateHasChanged method is invoked to refresh the UI. This will ensure that the City dropdown list will get refreshed on changing the Country dropdown.

Similarly, we have another dropdown list to display city data corresponding to each country. On the onchange event of the Cities dropdown, we are setting the value of the cityName property to the selected city.

We are also displaying the selected country name and city name value on the webpage.

The @functions section has all our properties and methods. We have defined two variables - countryList of type Countryand cityList of type City to handle the country and city data, respectively. We have also declared three properties to handle countryIdcountryName, and cityName data.

Inside the OnInitAsync method, we are calling the GetCountryList Web API method to populate countryList. This variable is used to bind the data to the Country dropdown list on page load.

Adding Links to the Navigation Menu

The last step is to add the link to our "CountryData" page in the navigation menu. Open the BlazorDDL.Client/Shared/NavMenu.cshtml page and put the following code into it.

<div class="top-row pl-4 navbar navbar-dark">
    <a class="navbar-brand" href="/">BlazorDDL</a>
    <button class="navbar-toggler" onclick=@ToggleNavMenu>
        <span class="navbar-toggler-icon"></span>
    </button>
</div>

<div class=@(collapseNavMenu ? "collapse" : null) onclick=@ToggleNavMenu>
    <ul class="nav flex-column">
        <li class="nav-item px-3">
            <NavLink class="nav-link" href="/" Match=NavLinkMatch.All>
                <span class="oi oi-home" aria-hidden="true"></span> Home
            </NavLink>
        </li>
        <li class="nav-item px-3">
            <NavLink class="nav-link" href="/counter">
                <span class="oi oi-plus" aria-hidden="true"></span> Counter
            </NavLink>
        </li>
        <li class="nav-item px-3">
            <NavLink class="nav-link" href="/fetchdata">
                <span class="oi oi-list-rich" aria-hidden="true"></span> Fetch data
            </NavLink>
        </li>
        <li class="nav-item px-3">
            <NavLink class="nav-link" href="/country">
                <span class="oi oi-list-rich" aria-hidden="true"></span> Country
            </NavLink>
        </li>
    </ul>
</div>

@functions {
bool collapseNavMenu = true;

void ToggleNavMenu()
{
    collapseNavMenu = !collapseNavMenu;
}
}

We have now completed our cascading dropdown list application.

Execution Demo

Launch the application.

A web page will open as shown in the image below. The navigation menu on the left shows the navigation link for the CountryData page.

Click on 'Country' in the navigation menu. It will redirect to the CountryData view where you can see two dropdown list - Country and Cities on the page. Notice the URL has "/ country " appended to it as we have defined it using the @page directive.

Here you can see both the dropdown lists. The Country dropdown list is already populated with the country data. If we select any country name from this dropdown, then the City dropdown will also get populated with the corresponding city data. We can also see the selected country and city values in the labels below both dropdown lists.

Hosting the Application

To learn how to host a Blazor application using IIS, refer to Deploying a Blazor Application on IIS.

Conclusion

We have learned how to create cascading dropdown lists in Blazor using the Entity Framework Core database first approach with the help of Visual Studio 2017 and SQL Server 2014. Please get the source code from GitHub and play around to get a better understanding.

You can check my other articles on Blazor here.

You can also find this article at C# Corner.
