Import and Export Excel Files into Varbinary (Max) in SQL Server

See how to combine a bit of C#, MS SQL, and ASPX to create quick and easy import and export buttons for your database.

Karthik Elumalai user avatar by
Karthik Elumalai
·
Jul. 25, 16 · Database Zone · Tutorial
Like (1)
Save
Tweet
13.55K Views

Join the DZone community and get the full member experience.

Join For Free

introduction

in this article, you will learn how to import and export excel files into varbinary (max) in sql server using asp.net c#

what are the advantages of storing as a varbinary file?

  • we don't need to depend on the file system.
  • it will avoid data risks.

aspx code

just add two buttons:

<asp:button id="btnimportexceltodb" runat="server" text="importexceltodb" onclick="btnimportexceltodb_click" />
<asp:button id="btnexportexcelfromdb" runat="server" text="exportexcelfromdb" onclick="btnexportexcelfromdb_click" />


codebehind code

import code

//button click event for the importexceltodb
protected void btnimportexceltodb_click(object sender, eventargs e)
{
    //specify the filepath where the file exist
    string filename = @ "d:\tpms\uploaded_boq\raveena_boq1.xlsx";

    //pass the filename as a parameter
    this.storeexcelfiletodatabase(filename);
}

// store excel sheet (or any file for that matter) into a sql server table
public void storeexcelfiletodatabase(string excelfilename)
{
    // if file doesn't exist --> terminate (you might want to show a message box or something)
    if (!file.exists(excelfilename))
    {
        return;
    }

    // get all the bytes of the file into memory
    byte[] excelcontents = file.readallbytes(excelfilename);

    // define sql statement to use
    string insertstmt = "insert into dbo.tender_excel_source(filename, filecontent) values(@filename, @binarycontent)";

    // set up connection and command to do insert
    using(sqlconnection connection = new sqlconnection(osmc.constring_property))
    using(sqlcommand cmdinsert = new sqlcommand(insertstmt, connection))
    {
        cmdinsert.parameters.add("@filename", sqldbtype.varchar, 500).value = excelfilename;
        cmdinsert.parameters.add("@binarycontent", sqldbtype.varbinary, int.maxvalue).value = excelcontents;

        // open connection, execute sql statement, close connection again
        connection.open();
        cmdinsert.executenonquery();
        connection.close();
    }
}


export code

protected void btnexportexcelfromdb_click(object sender, eventargs e)
{
    string filepathtostore = @ "d:\tpms\uploaded_boq\raveena_boq_from_db.xlsx";
    retrieveexcelfilefromdatabase(4, filepathtostore);
}

public void retrieveexcelfilefromdatabase(int id, string excelfilename)
{
    byte[] excelcontents;
    string selectstmt = "select filecontent from dbo.tender_excel_source where file_sequence_no = @id";

    using(sqlconnection connection = new sqlconnection(osmc.constring_property))
    using(sqlcommand cmdselect = new sqlcommand(selectstmt, connection))
    {
        cmdselect.parameters.add("@id", sqldbtype.int).value = id;

        connection.open();
        excelcontents = (byte[]) cmdselect.executescalar();
        connection.close();
    }

    file.writeallbytes(excelfilename, excelcontents);
}


database create table script

use [tpms_release1]
go

/****** object: table [dbo].[tender_excel_source] script date: 09-06-16 morning 10:19:05 ******/
set ansi_nulls on
go

set quoted_identifier on
go

set ansi_padding on
go

create table [dbo].[tender_excel_source](
    [fk_tender_id] [int] null,
    [file_sequence_no] [int] identity(1,1) not null,
    [filename] [nvarchar](1024) null,
    [filecontent] [varbinary](max) null
) on [primary] textimage_on [primary]

go

set ansi_padding off
go


output

when you're done, it should look like this:

output


click on the import button, and the excel file will have been converted to a byte file and will be saved like this:

excel file


click on the export button, and the opposite will happen:

excel file



excel file


i hope the above information was useful. kindly leave your feedback or suggestions.
