Introduction to Apache Spark's Core API (Part I)

Hello coders, I hope you are all doing well.

Over the past few months, I've been learning the Spark framework along with other big data topics. Spark is essentially a cluster programming framework. I know that one word can't define the entire framework. So please refer to this Introduction to Apache Spark article for more details.

In this post, I am going to discuss the core APIs of Apache Spark with respect to Python as a programming language. I am assuming that you have a basic knowledge of the Spark framework (tuples, RDD, pair RDD, and data frames) and its initialization steps.

When we launch a Spark shell, either in Scala or Python (i.e. Spark Shell or PySpark), it will initialize assparkContextsc and asSQLContextsqlContext.

• Core APIs
  • sc.textFile(path)
    • This method reads a text file from HDFS and returns it as an RDD of strings.

    ordersRDD = sc.textFile('orders')



  • rdd.first()
    • This method returns the first element in the RDD.

    ordersRDD.first()
    # u'1,2013-07-25 00:00:00.0,11599,CLOSED' - first element of the ordersRDD



  • rdd.collect()
    • This method returns a list that contains all of the elements in the RDD.

    ordersRDD.collect()
    # [u'68882,2014-07-22 00:00:00.0,10000,ON_HOLD', u'68883,2014-07-23 00:00:00.0,5533,COMPLETE']



  • rdd.filter(f)
    • This method returns a new RDD containing only the elements that satisfy a predicate, i.e. it will create a new RDD containing those elements which satisfy the condition given in the argument.

    filterdRDD = ordersRDD.filter(lambda line: line.split(',')[3] in ['COMPLETE'])
    filterdRDD.first()
    # u'3,2013-07-25 00:00:00.0,12111,COMPLETE'



  • rdd.map(f)
    • This method returns a new RDD by applying a function to each element of this RDD. i.e. it will transform the RDD to a new one by applying a function.

    mapedRDD = ordersRDD.map(lambda line: tuple(line.split(',')))
    mapedRDD.first()
    # (u'1', u'2013-07-25 00:00:00.0', u'11599', u'CLOSED')



  • rdd.flatMap(f)
    • This method returns a new RDD by first applying a function to each element of this RDD (same as map method) and then flattening the results.

    flatMapedRDD = ordersRDD.flatMap(lambda line: line.split(','))
    flatMapedRDD.take(4)
    # [u'1', u'2013-07-25 00:00:00.0', u'11599', u'CLOSED']



  • sc.parallelize(c)
    • This method distributes a local Python collection to form an RDD.

    lRDD = sc.parallelize(range(1,10))
    lRDD.first()
    # 1
    lRDD.take(10)
    # [1, 2, 3, 4, 5, 6, 7, 8, 9]



  • rdd.reduce(f)
    • This method reduces the elements of this RDD using the specified commutative and associative binary operator.

    lRDD.reduce(lambda x,y: x+y)
    # 45 - this is the sum of 1 to 9



  • rdd.count()
    • This method returns the number of elements in this RDD.

    lRDD.count()
    # 9 - as there are 9 elements in the lRDD



  • rdd.sortBy(keyFunc)
    • This method sorts this RDD by a givenkeyfunc

    lRDD.collect()
    # [1, 2, 3, 4, 5, 6, 7, 8, 9]

    lRDD.sortBy(lambda x: -x).collect()
    # [9, 8, 7, 6, 5, 4, 3, 2, 1] - can sort the rdd in any manner i.e. ASC or DESC



  • rdd.top(num)
    • This method gets the top N elements from an RDD. It returns the list sorted in descending order.

    lRDD.top(3)
    # [9, 8, 7]



  • rdd.take(num)
    • This method takes the first num elements of the RDD.

    lRDD.take(7)
    # [1, 2, 3, 4, 5, 6, 7]



  • rdd.union(otherRDD)
    • Return the union of this RDD and another one.

    l1 = sc.parallelize(range(1,5))
    l1.collect()
    # [1, 2, 3, 4]

    l2 = sc.parallelize(range(3,8))
    l2.collect()
    # [3, 4, 5, 6, 7]

    lUnion = l1.union(l2)
    lUnion.collect()
    # [1, 2, 3, 4, 3, 4, 5, 6, 7]



  • rdd.distinct()
    • Return a new RDD containing the distinct elements in this RDD.

    lDistinct = lUnion.distinct()
    lDistinct.collect()
    # [2, 4, 6, 1, 3, 5, 7]



  • rdd.intersection(otherRDD)
    • Return the intersection of this RDD and another one, i.e. the output will not contain any duplicate elements, even if the input RDDs did.

    lIntersection = l1.intersection(l2)
    lIntersection.collect()
    # [4, 3]



  • rdd.subtract(otherRDD)
    • Return each value in RDD that is not contained in another one.

    lSubtract = l1.subtract(l2)
    lSubtract.collect()
    # [2, 1]



  • rdd.saveAsTextFile(path, compressionCodec)
    • Save this RDD as a text file.

    lRDD.saveAsTextFile('lRDD_only')
    # this method will save the lRDD under lRDD_only folder under home directory in the HDFS

    lUnion.saveAsTextFile('lRDD_union','org.apache.hadoop.io.compress.GzipCodec')
    # this method will save the lUion compressed with Gzip codec under lRDD_union folder under home directory in the HDFS

    lSubtract.saveAsTextFile('lRDD_union','org.apache.hadoop.io.compress.SnappyCodec')
    # this method will save the lUion compressed with Snappy codec under lRDD_union folder under home directory in the HDFS



  • rdd.keyBy(f)
    • Creates tuples (pair RDD) of the elements in this RDD by applying the function.

    ordersPairRDD = ordersRDD.keyBy(lambda line: int(line.split(',')[0]))
    ordersPairRDD.first()
    # (1, u'1,2013-07-25 00:00:00.0,11599,CLOSED')
    # This way we can create the pair RDD.




For now, these are all the functions or methods for plain RDD, i.e. without the key. In my next post, I will explain the functions or methods with respect to pair RDD with multiple example snippets.

Thanks for reading and happy coding!
