Introduction to the Tower Library
In this post, we have explained what the Tower library is: a Functional Programming library that provides function composition.
Join the DZone community and get the full member experience.Join For Free
One of the components of my OpenTelemetry demo is a Rust application built with the Axum web framework. In its description,
axumdoesn't have its own middleware system but instead uses
tower::Service. This means
axumgets timeouts, tracing, compression, authorization, and more, for free. It also enables you to share middleware with applications written using
So far, I was happy to let this cryptic explanation lurk in the corner of my mind, but today is the day I want to understand what it means. Like many others, this post aims to explain to me and others how to do this.
tower crate offers the following information:
Tower is a library of modular and reusable components for building robust networking clients and servers.
Tower provides a simple core abstraction, the
Servicetrait, which represents an asynchronous function taking a request and returning either a response or an error. This abstraction can be used to model both clients and servers.
Generic components, like timeouts, rate limiting, and load balancing, can be modeled as
Services that wrap some inner service and apply additional behavior before or after the inner service is called. This allows implementing these components in a protocol-agnostic, composable way. Typically, such services are referred to as middleware.
Tower is designed around Functional Programming and two main abstractions,
In its simplest expression, a
Service is a function that reads an input and produces an output. It consists of two methods:
- One should call
poll_ready()to ensure that the service can process requests
call()processes the request and returns the response asynchronously
Because calls can fail, the return value is wrapped in a
Result. Moreover, since Tower deals with asynchronous calls, the
Result is wrapped in a
Future. Hence, a
Service transforms a
Self::Request into a
Response needing to be defined by the developer.
Layer trait allows composing
Here's a slightly more detailed diagram:
Service implementation will wrap an underlying component; the component may be a service itself. Hence, you can chain multiple features by composing various functions.
call() function implementation usually executes these steps in order, all of them being optional:
- Call the wrapped component
For example, a logging service could log the parameters before the call, call the logged component, and log the return value after the call. Another example would be a throttling service, which limits the rate of calls of the wrapped service: it would read the current status before the call and, if above a configured limit, would return immediately without calling the wrapped component. It will call the component and increment the status if the status is valid.
The role of a layer would be to take one service and wrap it into the other.
With this in mind, it's relatively easy to check the axum-tracing-opentelemetry crate and understand what it does. It offers two services with their respective layers: one is to extract the trace and span IDs from an HTTP request, and another is to send the data to the OTEL collector.
Note that Tower comes with several out-of-the-box services, each available via a feature crate:
balance: load-balance requests
buffer: MPSC buffer
discover: service discovery
filter: conditional dispatch
hedge: retry slow requests
limit: limit requests
load: load measurement
retry: retry failed requests
timeout: timeout requests
Finally, note that Tower comes in three crates:
tower is the public crate, while
tower-layer are considered less stable.
In this post, we have explained what is the Tower library: it's a Functional Programming library that provides function composition. If you come from the Object-Oriented Programming paradigm, it's similar to the Decorator pattern. It builds upon two abstractions,
Service is the function and
Layer composes functions.
It's widespread in the Rust ecosystem, and learning it is a good investment.
To go further:
